Summary of Contents for Fisher & Paykel smartload DGGX1US
-
Page 2: What To Do If You Smell Gas
For your safety the information in this manual must be followed to minimize the risk of death, personal injury, fire, explosion, or property damage. Do not store or use gasoline or other flammable vapors and liquids near this or any other appliance. -
Page 3: Important Safety Instructions
Important safety instructions To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. Read all instructions before using the appliance. 2. Installation and service must be performed by a qualified installer, service agency or the gas supplier. -
Page 4: Parts Supplied
Read this before you start installing your dryer you and others. The safety alert symbol and the word DANGER or WARNING will This is the safety alert symbol.This symbol alerts you to hazards that can kill or hurt precede all safety messages.These words mean: You can be killed or seriously injured if you don't immediately follow instructions. -
Page 5: Location Requirements
To the installer The correct installation of the dryer is your responsibility. Be sure you read the following instructions carefully before you start to install the dryer. These instructions should be left with the home owner for future reference. It is your responsibility •... -
Page 6: Alcove Or Closet Installation
The area in which the dryer is located must be kept clear and free from combustible materials, gasoline and other flammable vapours and liquids. A dryer produces combustible lint so the area around the dryer must be cleaned regularly to keep it free of lint. This dryer can only be vented from the rear and must be exhausted to the outdoors. -
Page 7: Exhaust Outlet
©imensions Lid clearance Check that there is enough clearance for the lid to fully open. 27 9/16" (700ram) 27" (685mm) Exhaust outlet location Exhaust outlet 13 7/s" (352mm) 13 l/s" (333mm) -
Page 8: Mobile Home Installation
Mobile home installation The installation of the dryer in a mobile home must conform to the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 32-80 {formerly the Federal Standard for Mobile Home Construction and Safety, Title 24 HUD (Part 280), 1975} for the United States. When installing a dryer in a mobile home, provisions for anchoring the dryer to the floor must be made. - Page 9 Exhausting The dryer must be exhausted to the outdoors. This will prevent the build up of lint and moisture in the room in which it is located and reduce the risk of fire. Fire Hazard The dryer must be vented to the outdoors.
- Page 10 To reduce condensation, insulate any ducting which passesthrough unheated areas. Slope the duct gently downwards to the hood, to drain condensation and reduce lint build up. Avoid sag or loops in the duct asthey may collect and store water and accumulate lint. Before using an existing exhaust duct system for a dryer ensure that: •...
-
Page 11: Maximum Length Of Exhaust Duct
Choose aroute that w ill p rovide thestraightest and most direct path outdoors. Plan t he installation touse the fewest number ofelbows and turns. When using elbows (rigid duct) or making turns (thick wall flexible metal duct), allow as much room as possible. - Page 12 Maximum length of4" diameter metal duct. Thick Wall Flexible Metal Number of 90 ° Rigid (fully extended) elbows/bends 64ft 19.5m 36ft 10.9m 54ft 16.5m 31ft 9.4m 44ft 13.4m 27ft 8.2m 35ft 10.6m 25ft 7.6m 27ft 8.2m 23ft 7.0m jmr,.Pu_w Maximum length of 4"...
- Page 13 Alternative installation for chose clearances Venting systems come in many varieties. Select the type best for your installation. A close-clearance installation is shown. sections separate, beveled edges allow corner installations The maximum length using a 2"x 6" (Scm x 15cm) rectangular duct with two elbows and a 2 YZ'(6.3cm)exhaust hood is 8ft (2.4m).
-
Page 14: Exhaust Venting
Exhaust venting Fire Hazard Use heavy metal exhaust duct. Do not use a plastic exhaust duct. Do not use thin metal foil exhaust duct. Failure to do so can result in death or fire. 1. Read the exhaust section (page 9-13) before installing the exhaust system to determine the maximum allowable exhaust duct length. -
Page 15: Installation
Installation Parts and literature are packaged inside the dryer drum. Excess Weight Hazard Use two or more people to move and install the dryer. Failure to do so can result in back or other injury. Only remove the packaging at the customer's premises. - Page 16 Fitting the front feet Note: Dryer is usually supplied with feet fitted and protruding the correct distance. 1. Tilt the dryer back using a hand trolley and making sure the trolley and dryer are secure. 2. Fit a rubber insert to each plastic foot as shown. 3.
- Page 17 EHectricaH requirements Electrical Shock Hazard Plug into a grounded 3-prong outlet. Do not remove ground prong. Do not use an adaptor. Do not use an extension lead. Failure to follow these instructions can result in death, fire, or electrical shock. Grounding instructions This appliance...
-
Page 18: Gas Requirements
Gas requirements The installation must conform with Local Codes, or in the absence of Local Codes, to the National Fuel Gas Code ANSI/Z223.1, Latest Revision (for the United States). Explosion Hazard Use a new AGA or CSA approved gas supply line. install a shut-off valve. -
Page 19: Connecting To The Gas Supply
Cor necting gas to your dryer Usecompound or thread tape appropriate to the gas type that is to be used (Natural or LP Gas), on the male threads of all non-flared connections. Never use an open flame to test for gas leaks. This dryer will operate satisfactorily up to altitudes of 650Oft (2000m) above sea level at the... - Page 20 Cor r ecting to the dryer 4. To connect the dryer to the gas supply, a number of options and types of connections can be used, such as rigid piping or tubing, or if local codes permit, new flexible tubing. 5.
-
Page 21: Final Installation
Leven machine Check the dryer is level, and make necessary adjustments to the front levelling feet. The rear levelling feet are self adjusting. Final installation check Hist Check that: No plastic or flexible metal foil is used in the exhaust ducting. Exhaust is rigid ducting or thick wall flexible metal ducting.
