  • Page 1 Gas Dryer DGGX1US Installation instructions...
  • Page 2: What To Do If You Smell Gas

    For your safety the information in this manual must be followed to minimize the risk of death, personal injury, fire, explosion, or property damage. Do not store or use gasoline or other flammable vapors and liquids near this or any other appliance.
  • Page 3: Important Safety Instructions

    Important safety instructions WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. Read all instructions before using the appliance. 2. Installation and service must be performed by a qualified installer, service agency or the gas supplier.
  • Page 4: Tools Required

    Read this before you start installing your dryer This is the safety alert symbol. This symbol alerts you to hazards that can kill or hurt you and others. The safety alert symbol and the word DANGER or WARNING will precede all safety messages. These words mean: DANGER WARNING All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell...
  • Page 5: Location Requirements

    To the installer The correct installation of the dryer is your responsibility. Be sure you read the following instructions carefully before you start to install the dryer. These instructions should be left with the home owner for future reference. It is your responsibility to: Observe all governing codes and ordinances.
  • Page 6: Alcove Or Closet Installation

    The area in which the dryer is located must be kept clear and free from combustible materials, gasoline and other flammable vapours and liquids. A dryer produces combustible lint so the area around the dryer must be cleaned regularly to keep it free of lint. This dryer can only be vented from the rear and must be exhausted to the outdoors.
  • Page 7 Dimensions Lid clearance Check that there is enough clearance for the lid to fully open. � ��� ������� �� � � ������� �� Exhaust outlet location Exhaust outlet " (352mm) " (333mm)
  • Page 8: Mobile Home Installation

    Mobile home installation The installation of the dryer in a mobile home must conform to the Manufactured Home Construction and Safety Standard Title 24 CFR, Part 32-80 {formerly the Federal Standard for Mobile Home Construction and Safety, Title 24 HUD (Part 280), 1975} for the United States. When installing a dryer in a mobile home, provisions for anchoring the dryer to the floor must be made.
  • Page 9: Fire Hazard

    Exhausting The dryer must be exhausted to the outdoors. This will prevent the build up of lint and moisture in the room in which it is located and reduce the risk of fire. This appliance must always be vented to the outdoors. Exhaust ducting products can be purchased from your local Appliance store or Hardware store.
  • Page 10: Mobile Home Installations

    To reduce condensation, insulate any ducting which passes through unheated areas. Slope the duct gently downwards to the hood, to drain condensation and reduce lint build up. Avoid sag or loops in the duct as they may collect and store water and accumulate lint. Before using an existing exhaust duct system for a dryer ensure that: No plastic or other potentially combustible duct or flexible metal foil ducting has been used.
  • Page 11: Maximum Length Of Exhaust Duct

    Choose a route that will provide the straightest and most direct path outdoors. Plan the installation to use the fewest number of elbows and turns. When using elbows (rigid duct) or making turns (thick wall flexible metal duct), allow as much room as possible.
  • Page 12 Number of 90˚ elbows/bends Number of 90˚ elbows/bends For exhaust systems not covered by the exhaust duct length charts (such as multiple unit hook-ups, plenums, and power-assist fans), call our Customer Care Center: TOLL FREE 888 9FNP USA (888 936 7872). Preferred 4”...
  • Page 13: Alternative Installation For Close Clearances

    Alternative installation for close clearances Venting systems come in many varieties. Select the type best for your installation. A close-clearance installation is shown. The maximum length using a 2” x 6” (5cm x 15cm) rectangular duct with two elbows and a 2 1⁄2”(6.3cm) exhaust hood is 8ft (2.4m).
  • Page 14: Exhaust Venting

    Exhaust venting 1. Read the exhaust section (page 9–13) before installing the exhaust system to determine the maximum allowable exhaust duct length. Do not use sheet metal screws when assembling ducting. Always use suitable duct tape. Never use plastic or thin metal foil flexible exhaust material. 2.
  • Page 15: Installation

    Installation Parts and literature are packaged inside the dryer drum. Only remove the packaging at the customer’s premises. This will ensure the appliance arrives in pristine condition and reduces the risk of damage when transporting to the customer’s home. Unpacking Make sure dryer is in a suitable location for installation.
  • Page 16 Fitting the front feet Note: Dryer is usually supplied with feet fitted and protruding the correct distance. 1. Tilt the dryer back using a hand trolley and making sure the trolley and dryer are secure. 2. Fit a rubber insert to each plastic foot as shown. 3.
  • Page 17: Electrical Requirements

    Electrical requirements Grounding instructions This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This dryer is manufactured with a cabinet grounding conductor and plug. The plug must be plugged into the correct type of outlet which has been properly installed and grounded in accordance with local codes and ordinances.
  • Page 18: Gas Requirements

    Gas requirements The installation must conform with Local Codes, or in the absence of Local Codes, to the National Fuel Gas Code ANSI/Z223.1, Latest Revision (for the United States). Gas type Your dryer must have the correct burner for the type of gas in your home. Burner information is located on the rating plate located on the back splash.
  • Page 19: Connecting To The Gas Supply

    Connecting gas to your dryer Use compound or thread tape appropriate to the gas type that is to be used (Natural or LP Gas), on the male threads of all non-flared connections. Never use an open flame to test for gas leaks. This dryer will operate satisfactorily up to altitudes of 6500ft (2000m) above sea level at the BTU rating indicated on the model/serial plate.
  • Page 20 Connecting to the dryer 4. To connect the dryer to the gas supply, a number of options and types of connections can be used, such as rigid piping or tubing, or if local codes permit, new flexible tubing. 5. If flexible tubing is used, an elbow should be installed on the pipe at the back of the dryer for the flexible tube to be connected to.
  • Page 21 Level machine...
  • Page 24 Copyright Reserved © Fisher & Paykel 2004. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Customer Care Center to ensure this booklet correctly describes the product currently available.
