10 SymSafe/SymSafe Pro
User Manual

Front Panel Controls and Features

Figure 3. SymSafe 16 front panel
Table 3. Front panel controls
Control
Alarm button
Menu menu
Arrow buttons
Enter button
Search button
Live button
Replay button
Fast reverse button
Play reverse button
Pause button
Play forward button
Fast forward button
Jog/Shuttle
Use
LED glows red to indicate an alarm condition. Push to silence current alarm.
Press to enter OSD and enter Setup mode. In Setup mode, Press to discard changes and return to the
next highest level menu or exits OSD.
Use to navigate menus.
In Setup mode toggles in and out of editable fields. In Live and Playback mode starts Cameo mode.
Press to display the Search and Disk Analysis screen.
Press to stop all video playback and return to showing live video.
Press to jump the play marker back x seconds. Configured in
Press to play video in reverse. Press again to increase speed.
Press to play video in reverse at 1X speed.
Press to freeze all video at the current play marker.
Press to play video at 1X speed.
Press to play video. Press again to increase speed.
During playback, rotate the shuttle (the outer dial) to increase playing speed. Use the jog to pause and
view video frame by frame.
Front Panel on page 71.
