1. Hold down the Enter button on the KTD-405.
2. Enter programming code: 1-4-7-6-seq.
3. Press the fast forward button until you get to the Program Soft Keys option.
4. Press the + button.
5. When it says Press key to program, press the magnifying glass icon.
6. Move the joystick up until you reach the ALT option.
7. Press the Enter and the + button to confirm the change.
8. Press the Seq button to exit programming mode.
9. You should now be able to select the IP camera by pressing the magnifying glass icon.

KTD-405 keypad mapping to SymSafe front panel

Figure 9. KTD-405 panel buttons
Table 12. KTD-405 to SymSafe front panel mapping
KTD-405 Keypad SymSafe front panel function
Replay button: In playback mode, touch to jump the play marker back x seconds.
Play forward button: plays video at 1x speed.
Live button: Stops video playback and returns to showing live video.
Pause button: Freezes all video at the current play marker.
Fast forward button: In playback mode, increases play speed.
