  • Page 1 USER MANUAL SEDEO LITE / PRO 1011651D...
  • Page 3 Sedeo Lite ..................4 Sedeo Pro..................31...
  • Page 4 The information provided is valid for the product in its standard version. Handicare can therefore not be held liable for any damage resulting from specifi cations of the product deviating from the standard confi...

  • Page 5: Table Of Contents

    2.1 Temperature 2.2 Indications on the seating system General description 3.1 Description of Sedeo Lite 4.1 Adjustment of the seating system (by the user/attendant) 4.2 Getting into and out of the wheelchair (forward transfer) 4.3 Getting into and out of the wheelchair (sideways transfer) 4.4 Options / accessories...

  • Page 6: Introduction

    Pointing out possible problems to the user. This user manual will help you to use and maintain your seating system safely This user Caution! manual is a supplement to Handicare’s general Advice for the user to prevent damage to the wheelchair user manual. product.

  • Page 7: Safety

    Safety | 7 Safety 2.2 Indications on the seating system Warning! Always follow the instructions given next to The wheelchair must not be lifted the warning symbols! Failure to follow these up by the armrests assembly, instructions may result in physical injury, complete and/or legrests.

  • Page 8: General Description

    8 | General description General description 3.1 Description of Sedeo Lite The wheelchair is fi tted with a Sedeo Lite seating system. The Sedeo Lite seating system provides good support for the head, torso, arms and legs. Optimal body support ensures maximum independence for the wheelchair user.

  • Page 9: Use

    Use | 9 4.1 Adjustment of the seating system (by the user/attendant) Manually elevating legrest knee angle Note! Legrests can be adjusted individually. 1. Pull (A) towards you. 2. (B) moves upwards. Alternatively, push (B) downwards. Sedeo g 50-A Note! Keep (A) pressed.

  • Page 10: Getting Into And Out Of The Wheelchair (Forward Transfer)

    10 | Use 4.2 Getting into and out of the wheelchair (forward transfer) Warning! Do not stand on the footplates. Putting your full weight on the footplates may lead to wheelchair damage and to hazardous situations, including the wheelchair tipping Flip up the footplate.

  • Page 11: Options / Accessories

    Use | 11 4.4 Options / accessories Removing/positioning the headrest 1. Loosen (A) by two turns. 2. Slide (B) up or down. 3. When replacing the headrest, tighten (A) by two turns. Note! Always slide the headrest until it comes to a stop in the bracket.

  • Page 12: Reducing The Seating System In Size For Transportation Purposes

    12 | Use Sedeo g 49-A 4.5 Reducing the seating system in size for transportation purposes A Seat (0,5 kg) Warning! B Backrest The wheelchair can be reduced in size for C Armrest assembly (1,8 kg) transportation without a passenger. Any D Legrest (1,2 kg) components of the seating system that can be E Headrest (1,3 kg)
  • Page 13 Use | 13 Removing the seat 1. Pull (A) loose from the board. Sedeo g 41-A 2. Pull (B) upwards and forwards. Sedeo g 42-A Folding the backrest fully forward 1. Loosen (A) by two turns. Note! Do not remove (A). 2.

  • Page 14: Setting Up The Seating System Following Transportation

    14 | Use Removing the standard legrests 1. Push (A) forwards and keep (A) pressed. 2. Swing (B) to the side. 3. Remove (B). Sedeo g 38-A Removing the armrest assembly 1. Loosen (A) by one turn. 2. Remove (B). Sedeo g 39-A 4.6 Setting up the seating system following transportation...
  • Page 15 Use | 15 Positioning the standard legrest 1. Slide (A) completely into (B). 2. Pivot (A) inwards until hearing a click. Warning! After hearing a click, the legrest is locked into place. Sedeo g 45-A Positioning the backrest for use 1.
  • Page 16 16 | Use 5. Position (A) on (B). Sedeo g 48-A...

  • Page 17: Seating System Adjustments (To Be Carried Out By A Professional)

    Seating system adjustments (to be carried out by a professional) | 17 Seating system adjustments (to be carried out by a professional) 5.1 Seat depth Backrest adjustment 1. Unscrew (A) completely and remove (A). 2. Adjust (B) to the desired position. 3.

  • Page 18: Backrest Angle

    18 | Seating system adjustments (to be carried out by a professional) 5.3 Backrest angle 1. Loosen (A) by two turns. 2. Lift (B) and push (B) forwards and downwards. Sedeo i 69-A 3. Loosen (A) completely. 4. Move (A) to the desired position. 5.

  • Page 19: Armrest Assembly

    Seating system adjustments (to be carried out by a professional) | 19 Standard legrest lower leg length 1. Unscrew (A) completely and remove (A). 2. Slide (B) into the desired position. 3. Replace (A) and tighten (A). Note! Ensure that there is suffi cient free space under (B) for the wheelchair to drive over obstacles.
  • Page 20 20 | Seating system adjustments (to be carried out by a professional) Armrest width 1. Loosen (A). 2. Remove (B) Sedeo i 86-A 3. Loosen (C) by one turn. 4. Remove (D) Sedeo i 87-A To position: 1. Slide (A) together with (B) or (C) onto (D). Note! Ensure that the ridge on the terminal block falls into the opening.

  • Page 21: Adjusting The Centre Of Gravity

    Seating system adjustments (to be carried out by a professional) | 21 Side panel height 1. Loosen 2x (A) by one turn. 2. Adjust (B) to the desired position. 3. Tighten 2x (A). Sedeo i 74-A 5.6 Adjusting the centre of gravity Warning! The stability of the wheelchair is infl...
  • Page 22 22 | Seating system adjustments (to be carried out by a professional) Adjusting the memory setting 1. Loosen (C) by one turn. 2. Slide (D) as far down as possible. 3. Tighten (C). Sedeo i 76-A Headrest position 1. Loosen (A) by one turn. 2.

  • Page 23: Fixed / Swing Away Controller Bracket

    Seating system adjustments (to be carried out by a professional) | 23 5.8 Fixed / swing away controller bracket Depth 1. Loosen (A) by one turn. 2. Slide (B) into the desired position. 3. Tighten (A). Sedeo i 89-A Height (1) 1.

  • Page 24: Attaching The Lap Strap

    24 | Seating system adjustments (to be carried out by a professional) 5.9 Attaching the lap strap 1. Attach (A), using (B), to the frame 2. Fasten (B) with (C) to the frame Sedeo i 82-B Warnings Ensure that the lap strap is adjusted to the wheelchair user.

  • Page 25: Maintenance

    Maintenance | 25 Maintenance It is recommended that you have your wheelchair serviced by your dealer once a year or, in the case of Stoff / Material: intensive use, once every six months. 100% Polyamid Skum / Foam: 6.1 Cleaning the upholstery 100% Polyurethane Str./Size Clean the upholstery using a damp cloth and household...

  • Page 26: Troubleshooting

    26 | Troubleshooting Troubleshooting If there is a problem with your seating system, contact you dealer.

  • Page 27: Specifi Cations

    Specifi cations | 27 Specifi cations 8.1 CE declaration of conformity The product is in conformity with the provisions of the Medical Devices Directive and carries the CE mark. The product also meets the following requirements and standards. This has been verifi ed by independent test organizations.
  • Page 28 28 | Specifi cations Headrest Headrest height (memory) 170 mm Headrest depth 180 mm Headrest vertical angle -45° - 45° Controller bracket Controller bracket height 60 mm Controller bracket depth 35 mm Controller bracket swing away Controller bracket height 50 mm Controller bracket depth 35 mm Controller position angle...

  • Page 29: Provisions Of Warranty

    Provisions of warranty | 29 Provisions of warranty The provisions of warranty and liability applicable to the seating system are identical to those incorporated in the wheelchair manual.  Wheelchair)
  • Page 30 30 |...
  • Page 31 The information provided is valid for the product in its standard version. Handicare can therefore not be held liable for any damage resulting from specifi cations of the product deviating from the standard confi...
  • Page 32 32 | Introduction 1.1 This manual 1.2 Symbols used in this manual Safety 2.1 Temperature 2.2 Indications on the seating system General description 3.1 Sedeo Pro product description 4.1 Adjustment of the seating system (by the user/attendant) 4.2 Getting into and out of the wheelchair (forward transfer) 4.3 Getting into and out of the wheelchair (sideways transfer) 4.4 Options / accessories 4.5 Reducing the seating system in size for transportation purposes...

  • Page 33: Introduction

    Pointing out possible problems to the user. This user manual will help you to use and maintain your seating system safely This user Caution! manual is a supplement to Handicare’s general Advice for the user to prevent damage to the wheelchair user manual. product.

  • Page 34: Safety

    34 | Safety Safety 2.2 Indications on the seating system Warning! Always follow the instructions given next to The wheelchair must not be lifted the warning symbols! Failure to follow these up by the armrests assembly, instructions may result in physical injury, complete and/or legrests.

  • Page 35: General Description

    General description | 35 General description Tools supplied A T30 Torx key is supplied with the seating 3.1 Sedeo Pro product description system. This can be used by a professional for adjusting all of the seating system settings. The The wheelchair is fi tted with a Sedeo Pro T30 Torx key (A) can be found on the frame at seating system.

  • Page 36: Use

    36 | Use 4.1 Adjustment of the seating system (by the user/attendant) Manually recling backrest (by attendant) 1. Squeeze (A). 2. Adjust (B) to the desired position. Note! Keep squeezing (A). 3. Release (A). Manually recling backrest (by user) 1. Squeeze (A). 2.
  • Page 37 Use | 37 Sedeo Original central leg rest gas spring adjustment knee angle 1. Press gas spring handle (C). 2. Adjust the leg rest to the desired position. 3. Release the gas spring (C). Moving the controller bracket inwards 1. Push (A) inwards until hearing a click. Swing away the controller bracket 1.
  • Page 38 38 | Use Push handle height 1. Loosen (A) by one turn. 2. Slide (B) into the desired position. 3. Tighten (A). Sedeo g 7 Angle adjustable push bar 1. Loosen (A) by one turn. 2. Slide (B) into the desired position. 3.

  • Page 39: Getting Into And Out Of The Wheelchair (Forward Transfer)

    Use | 39 4.2 Getting into and out of the wheelchair (forward transfer) Warning! Do not stand on the footplates. Putting your full weight on the footplates may lead to wheelchair damage and to hazardous situations, including the wheelchair tipping Sedeo Original standard legrest 1.

  • Page 40: Options / Accessories

    40 | Use Folding back the armrest assembly 1. Press (A). 2. Fold (B) to the rear. Caution! Remove the tray before folding back the armrest assembly. Warning! Do not lean on the armrest when folded back. 4.4 Options / accessories Removing/positioning the headrest 1.
  • Page 41 Use | 41 Folding back the thoracic support 1. Press (A) to fold back (B). Removing the thigh support 1. Loosen (A) by one turn. 2. Remove (B).

  • Page 42: Reducing The Seating System In Size For Transportation Purposes

    42 | Use 4.5 Reducing the seating system in size for transportation purposes Warning! A. Seat (2,5 kg) The wheelchair can be reduced in size for B. Backrest (2,5 kg) transportation without a passenger. Any C. Armrest assembly (2 kg) components of the seating system that can be D.
  • Page 43 Use | 43 Removing the seat 1. Pull (A) upwards and forwards. Removing the back cushion 1. Turn (A) and (B). 2. From the bottom, pull (C) forwards and upwards and remove. Folding the backrest fully forward 1. Loosen (A). Note! Do not remove (A).

  • Page 44: Setting Up The Seating System Following Transportation

    44 | Use Removing the Sedeo Original standard legrest 1. Loosen the calf band. 2. Push the catch (A) to the rear in order to unlock the leg rest. 3. Swing the leg rest outwards. 4. Remove the leg rest (B) from its bracket by lifting. You should hear a click when replacing the leg rest.
  • Page 45 Use | 45 Positioning the backrest for use 1. Fold (A) upwards and backwards. 2. Tighten (B). Sedeo g 23 Positioning the back cushion 1. Hook (A) behind (B). 2. Turn (C). Caution! Ensure that the back cushion is fi rmly in position (handles upwards).

  • Page 46: Seating System Adjustments (To Be Carried Out By A Professional)

    46 | Seating system adjustments (to be carried out by a professional) Seating system adjustments (to be carried out by a professional) Note! There are calibration marks on various parts of the seating system. The ex-factory settings are indicated. 5.1 Seat depth Backrest adjustment 1.

  • Page 47: Backrest Angle

    Seating system adjustments (to be carried out by a professional) | 47 5.3 Backrest angle 1. Turn (A) in order to adjust (B). 5.4 Backrest height 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3. Tighten (A). 5.5 Standard and manually elevating legrest Legrest width...

  • Page 48: Comfort Legrest

    48 | Seating system adjustments (to be carried out by a professional) Lower leg length 1. Loosen the setscrew (A) a few turns with a 4 mm Allen key. 2. Slide the footplate (B) in the desired position. 3. Tighten the setscrew (A) securely. Caution! Ensure that there is suffi...

  • Page 49: Central Legrest

    Seating system adjustments (to be carried out by a professional) | 49 5.7 Central legrest Lower leg length A L+R 1. Loosen (A) by one turn. 2. Slide (B) into the desired position. 3. Tighten (A). Caution! Ensure that there is suffi cient free space under (B) for the wheelchair to drive over obstacles.

  • Page 50: Central Legrest Gas Spring Adjustment

    50 | Seating system adjustments (to be carried out by a professional) Calf pad height 1. Loosen (A) by one turn. 2. Slide (B) into the desired position. 3. Tighten (A). A L+R 5.8 Central legrest gas spring adjustment Lower leg length 1.
  • Page 51 Seating system adjustments (to be carried out by a professional) | 51 Armrest depth 1. Loosen (A) by one turn. 2. Slide (B) into the desired position. 3. Tighten (A). Note! Position the armrest further back in order to obtain more space for transfers.
  • Page 52 52 | Seating system adjustments (to be carried out by a professional) 3. If applicable, loosen (C) by one turn. 4. Remove (D) if applicable. 5. Loosen (E) by one turn. 6. Remove (F). To position: 1. Slide (A) together with (B) or (C) onto (D). Note! Ensure that the ridge on the terminal block falls into the opening...

  • Page 53: Adjusting The Centre Of Gravity

    Seating system adjustments (to be carried out by a professional) | 53 2. Adjust the depth of (A) and tighten (E). 3. Position the controller bracket. 4. Position the armrest. Side panel height 1. Loosen (A) by one turn. 2. Adjust (B) to the desired position. 3.

  • Page 54: Headrest

    54 | Seating system adjustments (to be carried out by a professional) 5.11 Headrest Headrest height 1. Lift (A). 2. Slide (B) into the desired position. 3. Push (A) down. Adjusting the memory setting 1. Loosen (C) by one turn. 2.

  • Page 55: Fixed / Swing-Away Controller Bracket

    Seating system adjustments (to be carried out by a professional) | 55 Headrest cushion width 1. Loosen (A) by one turn. 2. Slide (B) into the desired position. 3. Tighten (A). 5.12 Fixed / swing-away controller bracket Depth 1. Loosen (A) by one turn. 2.

  • Page 56: Abduction Support

    56 | Seating system adjustments (to be carried out by a professional) Height (2) 1. Loosen (C) by one turn. 2. Slide (D) into the desired position. 3. Tighten (C). 5.13 Abduction support Adjust the abduction support as follows: 1. Loosen the Torx screw. 2.

  • Page 57: Thoracic Support

    Seating system adjustments (to be carried out by a professional) | 57 5.15 Thoracic support Adjust the thoracic support as follows: 1. Loosen the Torx screw. 2. Adjust the part to the desired position. 3. Tighten the Torx screw. A/a. Rough adjustment of width B/b.

  • Page 58: Thigh Support

    58 | Seating system adjustments (to be carried out by a professional) 5.16 Thigh support Adjust the thigh support as follows: 1. Loosen the Torx screw. 2. Adjust the part to the desired position. 3. Tighten the Torx screw. A/a. Depth adjustment B/b.
  • Page 59 Seating system adjustments (to be carried out by a professional) | 59 Attaching to the seating frame 1. Attach (A) to the seating frame using a screw on the left and on the right. Sedeo i 63 Warning! Ensure that the lap strap is adjusted to the wheelchair user.

  • Page 60: Maintenance

    60 | Maintenance Maintenance It is recommended that you have your wheelchair serviced by your dealer once a year or, in the case of Stretch Rubber intensive use, once every six months. 58% Knitted Polyester 42 % FR Polyurethane 6.1 Cleaning the upholstery Fabric Backing 100% Polyester Clean the upholstery using a damp cloth and household...

  • Page 61: Troubleshooting

    Troubleshooting | 61 Troubleshooting If there is a problem with your seating system, contact you dealer.

  • Page 62: Specifi Cations

    62 | Specifi cations Specifi cations 8.1 CE declaration of conformity The product is in conformity with the provisions of the Medical Devices Directive and carries the CE mark. The product also meets the following requirements and standards. This has been verifi ed by independent test organizations.
  • Page 63 Specifi cations | 63 Manually elevating central legrest Lower leg length 430 - 550 mm Knee angle 35 - 95° Standard legrest (set) Lower leg length 360 - 530 mm Knee angle 70° Ankle angle 0 - 180° Elevating and electrical elevating legrest (set) Lower leg length 360 - 540 mm Knee angle...

  • Page 64: Provisions Of Warranty

    64 | Provisions of warranty Provisions of warranty The provisions of warranty and liability applicable to the seating system are identical to those incorporated in the wheelchair manual.  Wheelchair)
  • Page 65 | 65...
  • Page 68 Dealer: Serial number:...
