Key Combinations
+ Press the UP and DOWN arrow
buttons simultaneously to lock and
unlock the keyboard.
SET +
Press the SET and DOWN arrow
buttons simultaneously to enter
programming mode.
SET +
Press the SET and UP arrow
buttons simultaneously to return
to room temperature display.
NOTE: Dependent on the model and confi guration,
the controllers have been programmed to only
allow a temperature adjustment within a specifi ed
range. See the following chart for the specifi ed
range allowed for your unit.
Signature Series – HP15 Models
Min Temp
Model Set
HP15RS 30° F
HP15BS 30° F
HP15WS 40° F
Signature Series – HP24 Models
Min Temp
Model Set
HP24RS 30° F
HP24FS -10° F
HP24BS 30° F
HP24WS 40° F
Signature Series – HP48 Models
Min Temp
Model Set
-10° F
HP48FR
30° F
HP48RR 30° F
HP48RB 30° F
30° F
HP48RW
40° F
HP48WO 40° F
HP48WW 40° F
Printed in USA
Max Temp Factory
Set Temperature
Setpoint
42° F 38° F
48° F 42° F
68° F 45° F
Max Temp Factory
Set Temperature
Setpoint
42° F 38° F
10° F 0° F
48° F 42° F
68° F 45° F
Max Temp Factory
Set Temperature
Setpoint
Freezer
10° F 0° F
Refrigerator
42° F
38° F
42° F 38° F
42° F 38° F
Refrigerator
42° F
38° F
Wine Reserve
68° F
55° F
68° F 45° F
68° F 45° F
LED Functions
The following table describes the LED functions.
LED Mode
ON
\ Flashing
ON
ON
!
°F Flashing
Dial Temperature Control (C-Series,
ADA- Compliant & Shallow-Depth)
3
2
1
Figure 3. Temperature Controller C-Series
Use a straight slot screwdriver to adjust the dial
temperature control. The control is located at
the top rear panel of the cabinet. Approximate
temperature ranges are as follows:
C-Series
HC24RB
HC24BB
HC24WB
ADA Compliant
HA24FB
HA24RB
HA24BB
HA24WB
5
Use and Care Guide
Function
Compressor is on.
Anti-short cycle delay is on.
Defrost is on.
An alarm is on.
You are in the process of
programming the unit.
4
5
ADJUSTING
SCREW
6
COLD
OFF
Factory
Temperature
Setpoint
38° F
42° F
55° F
Factory
Temperature
Setpoint
0° F
38° F
42° F
55° F
