temperature will be displayed.
Changing the Lower Compartment
Temperature
1. Press and hold the SET button until the display
shows St1 with "F" fl ashing.
2. Press SET again to display the lower
compartment's current temperature ("F" will
continue to fl ash).
3. Use the UP or DOWN arrow button to scroll
to the desired temperature. The controller will
memorize the new temperature.
Changing the Upper Compartment
Temperature
1. Press and hold the SET button until the display
shows St1 with "F" fl ashing. Press the DOWN
arrow button once; the display will read St2.
2. Press SET again to display the upper
compartment's current temperature ("F" will
continue to fl ash).
3. Use the UP or DOWN arrow key to scroll to
the desired temperature. The controller will
memorize the new temperature.
NOTE: Dependent on the model and confi guration,
the controllers have been programmed to only
allow a temperature adjustment within a specifi ed
range. See the chart below for the specifi ed range
allowed for your unit.
Signature Series – Dual-Zone Units
Model Factory
Temperature
Setpoint
Lower/Upper
HP24Z 0°F / 38°F
HP24C 38°F / 55°F
HP24D 55°F / 65°F
Dual Zone Temperature Scale
To change F to C, press and hold the down
arrow for 3 seconds.
Printed in USA
Range
-10° - 10° / 30° - 42°
30° - 42° / 40 -68°
40° - 68° / 40° - 68°
4
Digital Temperature Control
(Signature Series – 15", 24" & 48" Single
Zone)
!
SET
Figure 2. Digital Temperature Controller
To Set Target Temperature
SET
Press and release the SET button. Display
will show the current temperature setpoint.
To Change Setpoint Temperature
1. Press and hold the SET button until the display
shows the current setpoint temperature with
"F" fl ashing.
2. Use the UP or DOWN arrow button to scroll
to the desired temperature. The controller will
memorize the new setpoint temperature.
To Start A Manual Defrost (Freezers Only)
Press the defrost button.
To Set Maximum Stored Temperature
Press the UP arrow button to see the
maximum stored temperature. To reset the
maximum stored temperature, while displayed,
press and hold the SET button until 'rst' fl ashes
in the display.
To Set Minimum Stored Temperature
Press the DOWN arrow button to see the
minimum stored temperature. To reset the
minimum stored temperature, while displayed,
press and hold the SET button until 'rst' fl ashes
in the display.
On/Off
Press to turn the unit on or off.
Use and Care Guide
C
