mnstaJiation Preparation
CUTOUTS AND CLEARANCES
* Measure carefully when cutting the countertop.
Make sure sides of the opening are parallel and rear
and front cuts are exactly perpendicuBr to sides.
* Measure to be sure there is room for clearances to
the front edge of the countertop.
* Refer to cooktop installation instructions to be sure
that models fit into the base cabinets being used.
* Identify the cutout illustration for the cooktop model
you are installing.
* Draw Bines on the countertop to follow as a cutting
guide, Measure and marl< cooktop and vent overBaps
to be sure there is enough flat countertop depth,
ZEU769 ELECTRIC COOKTOPS WITH 36" VENT
1-3/4" Min. Cooktop Cutout to Rear
Vertical Combustible Surface
t
21-3/4"
Cutout
Depth
I_ 36" ___/1/4" Overlap
Gap
22-1/2"
_34" Cool<topand Vent Cutout_ Total Flat
' Surface
i
,, Required
i
i
5/8" Cool<topOverlap
2-1/2" Min. Clearance to Cutout
f
Front Edge
of Countertop 2" Min. Cutout
to Side Walls
2-1/2" to
_22" to Support Rail_
I
* 24-3/4" *1
Countertop Cutout: Requires 22-1/2" flat countertop surface
and 24-3/8" total countertop depth.
Cabinet: Requires 22-1/2" inside
cabinet depth. Remove rear
support rail,
6
