Table Of Contents; Design Information; Models Available; Accessories - GE Monogram ZVB36 Installation Instructions Manual

Design information
Design Information
Models Available ............................................................... 3
Accessories ....................................................................... 3
Product Dimensions ..........................................................3
Advance Planning .........................................................4, 5
Installation Preparation
ZEU769 Combination Cutout ............................................6
ZEU30R Combination Cutout ............................................7
ZEU36R Combination Cutout ............................................7
ZGU36GG Combination Cutout ........................................ 8
ZGU375 Combination Cutout ............................................8
Clearances ......................................................................... 9
Parts Supplied ....................................................................9
Tools and Materials Required .........................................9
Remove Packaging ...........................................................9
Power Supply ...................................................................10
Venting Options ................................................................11
Ductwork
Duct Fittings .....................................................................12
Installation Instructions
Step 1, Install Downdraft Vent ...................................... 13
Step 2, Install the Ductwork .......................................... 13
Step 3, Install Raise/Lower Switch .............................. 14
Step 4, Connect Power ...................................................15
Step 5, Install Filters, Check Operation ....................... 15
Cleaning ............................................................................15
MODELS AVAILABLE
ZVB36
36" Wide Downdraff Vent
in white, black and stainless steel
ZVB30
30" Wide Downdraff Vent
in white, black and stainless steel
ACCESSORIES
JXRB67 - Optional accessory for indoor remote
location of the blower/motor assembly. Use this kit
when the blower and motor assembly will be located
outside of the cabinet, such as belowthe cabinet
floor.
JXBC67 - Optional outdoor cover accessory for
remote installation of blower and motor assembly on
an outside wall.
PRODUCT DIMENSIONS
A B
30" Models 30" 28-1/2"
36" Models 36" 34"
: 8-1/2
7-1/2" I 24/4"
27"
3
