- Page 1 Installation Instructions If you have questions, call 800-GE-CARES or visit our website at: www.monogram.com Downdraft Vent systems 36" Wide Models: ZVB36 30" Wide Models: ZVB30 Monogram. ® We bring good things to life.
-
Page 2: Safety Information
Safety Information BEFORE YOU BEGIN WARNING Read these instructions completely To reduce the risk of fire, electric and carefully. shock, or injury to persons, observe the following. IMPORTANT – Save these instructions for A. Use this unit only in the manner intended by the local inspector’s use. -
Page 3: Table Of Contents
Cleaning ................15 MODELS AVAILABLE PRODUCT DIMENSIONS 30” Models 30” 28-1/2” 36” Models 36” 34” ZVB36 36” Wide Downdraft Vent in white, black and stainless steel 27" ZVB30 30” Wide Downdraft Vent 2" in white, black and stainless steel 8-1/2"... -
Page 4: Advance Planning
Design Information ADVANCE PLANNING Before you begin, you must: Remote Switch 1. Review countertop dimension illustrations to be The downdraft vent has a separate raise/lower switch. sure you will have enough flat countertop surface. Plan to install the switch in a convenient location 2. - Page 5 Design Information Clearances Ductwork • The downdraft system with blower, motor and duct Prepare ductwork to vent to the outdoors. work will occupy the cabinet below the countertop • Use the shortest and straightest duct run possible. and cooktop. • The maximum permissible length for duct run is 150 •...
-
Page 6: Installation Preparation
Installation Preparation CUTOUTS AND CLEARANCES • Identify the cutout illustration for the cooktop model • Measure carefully when cutting the countertop. you are installing. Make sure sides of the opening are parallel and rear • Draw lines on the countertop to follow as a cutting and front cuts are exactly perpendicular to sides. -
Page 7: Zeu30R Combination Cutout
Installation Preparation ZEU30R DIGITAL COOKTOPS WITH 30" VENT 2-1/2" to 1-7/8" Cutout 1-3/4" Min. Cooktop Cutout to Rear Vertical Combustible Surface ZEU30 3/4" 29-7/8" (SS) 20-3/8" Thick 1/4" Overlap 29-3/4" (B,W) 3/4" Support Rail 1/8" Gap 23-1/2" (SS) Vent 23-3/8" (B,W) 22-1/4"... -
Page 8: Zgu36Gg Combination Cutout
Installation Preparation ZGU36GG GAS COOKTOPS WITH 36" VENT 2-1/2" to 2-1/4" Min. Cooktop Cutout to Rear 1-7/8" Cutout Vertical Combustible Surface ZGU36 3/4" 36" 1/4" Overlap 20-1/16" Thick 3/4" Support 1/8" Gap Rail 23-1/2" (SS) 21-3/4" 23-3/8" (B,W) Cutout 34" Cooktop and Vent Cutout Vent Total Flat Depth... -
Page 9: Clearances
Installation Preparation CLEARANCES CAUTION Wall coverings, countertops and cabinets should Gas - 6" to 11-9/16" withstand 200° heat generated by any cooktop. Electric - 2" Clearance to Side Walls PRUDENCE Les revêtements muraux, les dessus de comptoir et les armoires de cuisine doivent résister à la température de 95 ºC (200 ºF) créée par toute table de cuisson. -
Page 10: Power Supply
Installation Preparation Do Not Locate Gas or Electrical POWER SUPPLY Connections Within Shaded Area WARNING FOR PERSONAL SAFETY: 29-1/2" Remove house fuse or open circuit breaker before beginning Electrical installation. Outlet 12" Above Do not use an extension cord or Cabinet Floor adapter plug with this appliance. -
Page 11: Venting Options
Installation Preparation Loosen Screws VENTING OPTIONS to Adjust 3-1/2" to Left or Right • The downdraft vent is shipped with the discharge outlet pointing straight down and can be changed to the left or right side. • The blower outlet is sized for 3-1/4” x 10” and can be transitioned to 6”... -
Page 12: Ductwork
* Actual length of straight duct plus duct fitting standards such as equivalent. Equivalent length of duct pieces are based those published by on actual tests conducted by GE Evaluation Engineer- NFPA and ASHRAE. ing and reflect requirements for good venting performance with any downdraft cooktop. -
Page 13: Installation Instructions
Installation Instructions STEP 1 INSTALL DOWNDRAFT STEP 2 INSTALL THE DUCTWORK VENT • The downdraft blower system is designed for use with 3-1/4" x 10" ductwork. It can be transitioned to 6" Place the downdraft vent into the countertop cutout, round. -
Page 14: Step 3 Install Raise/Lower Switch
Installation Instructions STEP 3 INSTALL RAISE/LOWER SWITCH WARNING: AVERTISSEMENT Disconnect electrical power from unit before Il faut débrancher l’alimentation électrique de beginning switch installation. Failure to do so could l’appareil avant de commencer l’installation de result in personal injury or damage to the electrical l’interrupteur. -
Page 15: Step 4 Connect Power
Stainless Steel Magic is available at Ace, True Value, CHECK OPERATION Servistar, HWI and other leading stores. It is also available through GE Parts by calling 1-800-626-2002. Order part number WX10X15. To raise the vent, press the RAISE/LOWER switch. The switch is installed in a separate location. - Page 16 General Electric. Therefore, materials, appearance and specifications are subject to change without notice. Monogram. ® We bring good things to life. GE Consumer Products Pub. No. 49-80185 General Electric Company Louisville, KY 40225 Dwg. No. 164D4290P341 © 2003 General Electric Company (N.D.
