Connect the second monitor
2
If your second monitor uses a DVI
connector, connect it directly to the
secondary connector (
card.
If your second monitor uses an HD-15
connector, you can use a dual-monitor cable
(included with certain Matrox products) or
a DVI-to-HD15 adapter. To use 3 monitors
at a time, a dual-monitor cable is required.
If you use a dual-monitor cable, connect it
to the secondary connector on your graphics
card, then connect your monitor to
connector
you're going to connect the TV output
adapter, connect your computer monitor to
connector
Connect the third monitor
3
If you want to use 3 computer monitors at a
time and your Matrox product supports it,
your second and third monitors must use
HD-15 connectors. Connect your third
monitor to connector
cable.
Note:
and, through Matrox PowerDesk software, you can re-order your displays to match your
Windows desktop. For more information, see Matrox PowerDesk help.
Note:
card, you need a TV output adapter (included with
certain Matrox products). The TV output adapter
connects to connector
a DVI-to-HD15 adapter. For more information,
output", page
8 Matrox graphics card – User Guide
) of your graphics
B
on the dual-monitor cable. If
1
instead.
2
on the dual-monitor
2
The left-to-right order of your displays isn't dependent on your connection setup
To connect a TV or video recorder to your graphics
on your dual-monitor cable or to
1
13.
Monitor connector (DVI)
Monitor connector (HD-15)
Monitor connector (HD-15)
see "TV
TV output adapter
