MediaFlex 7811 Access Point and MediaFlex 7111 Adapter User Guide Part number: 800-70163-001 June 2008 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 2
In the interest of improving internal design, operational function, and/or reliability, Ruckus Wireless, Inc. reserves the right to make changes to the products described in this document without notice. Ruckus Wireless, Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
Preface This Ruckus Wireless MediaFlex 7811 Access Point User Guide will help you understand the Ruckus Wireless MediaFlex 7811 Access Point — how to install it, and configure it using the Ruckus Wireless Web Interface. Who Should Use This Guide This User Guide assumes that the reader has basic to intermediate computer and Internet skills.
• Safari 1.0 Support and Warranty Information See the Warranty card for detailed information about contacting Technical Support, and the Warranty terms for your 7811. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Chapter 1: Introduction Congratulations on your purchase of the Ruckus Wireless MediaFlex 7811 Access Point (7811). The 7811 is a device that enables wireless multimedia networking for video, voice and data, without replacing existing routers, network adapters and media receivers.
MediaFlex™ MediaFlex™ MediaFlex™ is Ruckus Wireless, Inc.’s family of purpose-built, multimedia WiFi devices that enable reliable wireless distribution of entertainment-quality, real-time media applications throughout the home. Media applications require consistent and uninterrupted bandwidth; however most wireless LANs (WLANs) cannot provide consistent service because of the variable nature of the wireless medium.
Page 9
• Compatible with the emerging 802.11n WLAN standard • Virtual AP support of one BSSID • HTTPS management • SSH management • Device-specific certificates Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 10
Key Features (This page intentionally left blank.) Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Good signal quality at the service provider WLAN interface. Signal Quality Flashing Green Marginally acceptable signal quality at the service provider WLAN interface. No station associated with service provider WLAN. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Insert the end of a paper clip or pin into the hole and hold it in for at least 8 seconds. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
3. In the Local Area Connection Properties window, select Internet Protocol (TCP/IP) and click Properties. The Internet Protocol (TCP/IP) Properties window (Figure 4) appears. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
2. Connect the CAT5 Ethernet cable to the WAN port on the 7811 and the Ethernet port on your PC. The WAN Connectivity LED should turn steady green. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 17
– Depending on your Service Provider's configuration, the default values might be different from what is stated in this table. 4. The Security Alert window appears (Figure Figure 5—Security Alert window 5. Click Yes. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 18
6. The login screen appears, type the appropriate Username and Password shown in Table 7. Click Login. The Status > Device window appears (Figure Figure 7—Status > Device Window Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
– The value for Wireless Mode is fixed to 5GHz (802.11a/n) and is not configurable. 2. For Channel, choose SmartSelect. 3. When you are finished, click Update Settings. 4. Click Update Settings. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
7. Check the LED status lights to verify correct operation. • Make sure you are using the correct power adapter supplied by Ruckus Wireless. • Make sure the Power LED is lit. If it is not lit, make sure that the power cord is properly connected to the 7811, and that the AC power adapter is properly connected to a functioning power outlet.
Service Provider SSID V54-xxxxxx where xxxxxx are the last six _______________________________ digits of the MAC address. Wireless Mode Not configurable 5GHz (802.11a/n) - Fixed Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Ruckus Wireless Web Interface Menus Ruckus Wireless Web Interface Menus The Ruckus Wireless Web Interface menus are located on the left-hand navigation pane. To select a particular menu, simply click on the menu link. Common Buttons The Ruckus Wireless Web Interface screens contain the following menu buttons (Table Table 6—Wireless Web Interface Menu Buttons...
Page 25
• Home Login Username and Password (plus Password Confirmation) • (Service Providers only) Service Provider Login Username and Password (plus Password Confirmation) 3. Click Update Settings to save your settings. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
To define how the 7811 is configured to the Internet, do the following: 1. Go to Configuration > Internet. The window of Figure 10 appears. Figure 10—Internet Configuration Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 27
Static IP, DHCP or PPPoE. Typically for cable modem access, DHCP is used. For DSL access, PPPoE is used. You must get the PPPoE username and password from your ISP. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
"7811 Default and User Settings Worksheet" on page To configure the Wireless settings, do the following: 1. Go to Configuration > Wireless. Figure 11—Configuration :: Wireless tab Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 29
3. Click the Edit Common Settings button by Advanced Settings. The window of Figure 13 appears. The settings are described in Table Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 30
4. Click Update Settings to save your settings. 5. Once back under the Configuration :: Wireless :: Common settings, click the Video WLAN tab. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 31
The default value is 2346. 6. Click Update Settings to save your settings. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Figure 15—WPA-PSK Wireless Settings 1. Go to Configuration > Wireless. 2. Click the Video WLAN tab. 3. Select WPA-PSK in the Encryption Method drop-down menu. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 33
8 and 32 characters long. 4. In the Configuration > Wireless menu, enter a passphrase. 5. Click Update Settings to save your settings. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
32, and "Local Services Status" on page Device Status The Status page shows current status and configuration information about the Ruckus Wireless Router or Adapter. Figure 16 shows the Device Status window. You can bring up the window by choosing Status >...
Page 35
SSID, security mode and security keys. Only the home user can change this setting. It must be changed using the Configuration > Device Window. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
IP address or hostname of the NTP server which synchronizes time on the 7811 and managed 7111 adapters. Connection Status This indicates the status of the Internet interface, Up or Down. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 37
– When Internet connection type is either DHCP or PPPoE, if the 7811 does not receive the dynamic IP address from DHCP server or PPPoE server, the default IP address for WAN port will be 192.168.2.1. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Note that the common settings are displayed. Figure 18—Status :: Wireless :: Common To view the wireless status of the Video WLAN, click the Video WLAN tab (Figure 19). Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 39
Shows the status as either Up or Down. Broadcast SSID Shows the visibility status of your SSID as enabled (visible to anyone looking for wireless networks) or disabled (not visible). Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
7811’s wireless network. Each service is listed by name, and includes the IP address assigned to the service and the port over which the service operates. Figure 20—Local Services status window Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
If you select “Allow only stations listed in the Access Control Table”, then stations entered into the access-controls table are allowed but all others are disallowed. To add MAC addresses, see "Configuring Access Control" on page Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
35.) The Access Control Table appears [with no entries] Figure 22—Access Control allow settings 3. Click the Add new entry button to add a MAC address to the table. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
OUI, in which case you may need to enter each applicable one. • Remove: Check the 'Remove' box for any row(s) you no longer want used. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
When you click Update, only entries in the table whose “Remove” check box is un-checked will be included in the Access Control table. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
3. Under TFTP Options, enter the IP Address or hostname of the TFTP Server, the listening port (69 by default), and the name of the image control file. Figure 24—Maintenance > Upgrade—TFTP Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 47
– When entering the server name for firmware upgrade, make sure the Fully Qualified Domain Name (FQDN) is entered (for example, fwupdate.ruckuswireless.com). Figure 25—Download Started Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
– When entering the server name for firmware upgrade, make sure the Fully Qualified Domain Name (FQDN) is entered (for example, fwupdate.ruckuswireless.com). Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Device page. You need to know the current software version to verify that the upgrade process was successfully completed. To perform a local firmware upgrade Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 50
Upgrading the Firmware 1. Visit the Ruckus Wireless Web site, and then download the latest firmware for 7811. You can find the 7811 firmware files at http://support.ruckuswireless.com/software/for_product/mf7811. Take note of the version number of the firmware that you are downloading.
Page 51
If it reflects the version number of the firmware that you downloaded earlier, this indicates that the upgrade was completed successfully. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Dome LED on the top of the 7811 will momentarily go out, then light up again. • Click the Reset Now link to reset the device to factory settings; thus, erasing any of your custom settings. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 53
The reboot in progress window appears (Figure 31). Figure 31—Reboot in Progress Window The system notifies you when it is done (Figure 32). Figure 32—Reboot Done Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
• Save to Local Computer: Right-click on the link that appears and save. Navigate to the folder where you want the file saved and click Save. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Predefined network configuration in the system. The 7811 can be preconfigured into a different network profile. Telnet Access Allows you to enable or disable Telnet access to the Ruckus Wireless device. By default, this option is disabled (inactive). Telnet Port Lists the default Telnet port of 23—only if Telnet is active.
Page 56
Table 15—Administration Management Window Parameters (Continued) Field Description SSH Access? Allows you to enable or disable SSH access to the Ruckus Wireless device. By default, this option is enabled (active). SSH Port Specifies the port number for Telnet access. The default port number is...
Page 57
Administration Information Figure 35—TR069 Management Options and TR069 Status Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
3. To use the traceroute command, enter the IP address you wish to trace and click Run test. The results appear in the Traceroute results window. – It may take some time before the results are displayed. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Administration Information Administration Log The current log screen shows the log messages kept by the Ruckus Wireless Router since it was last rebooted. The log has limited size: the oldest messages are replaced as new messages arrive. It also sends the messages to a server (the Syslog server) that you designate. To configure the administrator log: 1.
Page 60
Administration Information (This page intentionally left blank.) Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Chapter 5: 7111 Adapter Setup, Provisioning, and Management This chapter shows you how to set up and provision the Ruckus Wireless MediaFlex 7111 Adapter with the Ruckus Wireless MediaFlex 7811 Access Point. Topics covered in this chapter include • Packing List ..............56 •...
10. Turn on the 7111. 11. Turn on the set-top box. 12. Check the LED status lights to verify correct operation (Figure 38). Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Signal Quality 13. Make sure you are using the power adapter supplied by Ruckus Wireless. 14. Make sure the Power LED is lit. If it is not lit, make sure that the power cord is properly connected to the 7111, and that the power supply adapter is properly connected to a functioning power outlet.
8. If the 7811 and the 7111 are correctly auto provisioned and associated, the right two LEDs of the 7111 should show constant green. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
If you want to retain the parameters from the AP, you must repeat the auto provisioning process described above. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
7111 to configure the adapter. To login to the 7111 and enable adapter management, see Enabling Adapter Management on page Figure 39—Viewing the adapter management status of a 7111 via the 7811 Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
6. In the 7111 Web user interface, go to Administration :: Management. Note that the Link-Local Adapter Management? field shows “Enabled”. 7. Click the Disabled radio button at Link-Local Adapter Management. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
6. In the 7111 Web user interface, go to Maintenance :: Upgrade. 7. Follow the instructions in the 7111 user guide to perform the firmware upgrade. Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
30Mbps-40Mbps sustainable throughout a typical 2500 ft (300 m ) home Number of simultaneous video streams The aggregated throughput of multiple video streams can reach up to 30Mbps-40Mbps Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Voice, Video, Best Effort and Background Number of hardware queues Number of software queues Management Configuration and monitoring interface Ruckus Wireless Web User Interface (WebUI), Telnet Login Service Provider Username: super Statistics Wireless and associated stations Accessible via Ruckus Wireless Web Interface...
SSID___________________________________________________________ Encryption Method If using WPA-PSK, write down the passphrase. The WPA-PSK passphrase is case-sensitive. WPA Version:______________________________________ WPA Algorithm____________________________________ WPA Passphrase: ________________________________ Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
Page 72
Service Provider SSID V54-xxxxxx where xxxxxx are the last six _______________________________ digits of the MAC address. Wireless Mode Not configurable 5GHz (802.11a/n) - Fixed Ruckus Wireless MediaFlex 7811 Access Point 4Gon www.4Gon.co.uk info@4gon.co.uk Tel: +44 (0)1245 808295 Fax: +44 (0)1245 808299...
