30" Shed Extension Kit 11' Sheds
ASSEMBLY
INSTRUCTIONS AND
OWNER'S MANUAL
Save this instruction in the event you must contact the manufacturer for replacement parts.
INSTRUCTION #1036820
VISIT THE LIFETIME WEB SITE:
WWW.LIFETIME.COM
Call Customer Service at:
1 (800) 225-3865
MODEL #0125
04/21/2008
®
