150-GALLON (567 L)
DECK BOX
MODEL 60340U
ITM./ART. 1902297
BEFORE ASSEMBLY:
• Assemble on a level surface
• At least 2 people are recommended for setup
THIS ITEM IS INTENDED FOR OUTDOOR DOMESTIC USE ONLY! NOT FOR
COMMERCIAL USE.
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
TOOLS REQUIRED
(Not included-unless otherwise indicated*)
7/16" (≈11 mm)
QUESTIONS?
Call: 1-800-225-3865
(English, French, Spanish)
1/2" (≈13 mm)
3/8" (≈10 mm), 7/16" (≈11 mm),
CONTACT LIFETIME CUSTOMER SERVICE:
Live Chat:
www.lifetime.com/customerservice/home
(click on "LIVE CHAT" tab)
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
1/2" (≈13 mm)
For Customer Service in mainland
Europe and the United Kingdom:
E-mail: csinternational@lifetime.com

TABLE OF CONTENTS

Icon Legend...............................4
Warnings & Notices.....................5
Parts Identifi er............................6
Box Assembly.............................7
Lid Assembly............................13
Additional Warnings..................23
Cleaning & Care........................26
Registration...........................27
Warranty..............................28
Model Number: 60340U
Product ID:
