  6. Assembly instructions manual

Lifetime 0125 Assembly Instructions Manual

Hide thumbs Also See for 0125:
Table of Contents

Advertisement

Quick Links

Download this manual
30" EXPANSION
KIT
MODEL 0125
BEFORE ASSEMBLY:
• Assemble on a level platform
• 3+ people for setup recommended
For Customer Service in mainland Europe:
E-mail: cs@lifetimeproducts.eu
TOOLS REQUIRED
QUESTIONS?
CONTACT LIFETIME CUSTOMER SERVICE:
Call: 1-800-225-3865
7:00 am–5:00 pm (Monday–Friday) MST
and 9:00 am–1:00 pm Saturday MST
Live Chat: www.lifetime.com
(click on "LIVE CHAT" tab)
Video Instructions:
www.youtube.com/lifetimeproducts
ASSEMBLY INSTRUCTIONS
Pour le français, voir la page 2. Para el español, ver la página 3.
MODEL# AND PRODUCT ID
Model Number: 0125
Product ID:
TABLE OF CONTENTS
Icon Legend...............................4
Warnings & Notices.....................5
Alerts.......................................6
Parts Identifi er............................7
Platform Construction.................8
Shed Disassembly.......................9
Floor Assembly..........................14
Truss Assembly.........................17
Wall & Roof Assembly................22
Warranty.................................29
(both are needed when contacting us)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 0125 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lifetime 0125

Summary of Contents for Lifetime 0125

  • Page 1 Platform Construction....8 Shed Disassembly.......9 Floor Assembly......14 Truss Assembly......17 Wall & Roof Assembly....22 Warranty.........29 QUESTIONS? CONTACT LIFETIME CUSTOMER SERVICE: Live Chat: www.lifetime.com MODEL# AND PRODUCT ID Call: 1-800-225-3865 (both are needed when contacting us) (click on “LIVE CHAT” tab) Model Number: 0125 7:00 am–5:00 pm (Monday–Friday) MST...
  • Page 2 Assemblage des murs et du toit..22 Garantie.........30 ® QUESTIONS ? CONTACTER LES SERVICES À LA CLIENTÈLE DE LIFETIME Entretien en direct: www.lifetime.com N° DE MODÈLE ET RÉFÉRENCE DU PRODUIT Composer le 1-800-225-3865 (il faut avoir les deux au moment de nous contacter) (cliquer sur la languette «...

  • Page 3: Table Of Contents

    Ensamble de los muros y del tejado........22 Garantía.........31 ® ¿PREGUNTAS? PONERSE EN CONTACTO CON LOS SERVICIOS DE CLIENTES LIFETIME Chat en vivo: www.lifetime.com MODEL E ID DEL PRODUCTO Marcar : 1-800-225-3865 (se necesitan los dos al contactarnos) (cliquear en la lengüeta «LIVE CHAT») Número de modelo: 0125...

  • Page 4: Leyenda De Íconos

    ICON LEGEND / LÉGENDE DES ICÔNES / LEYENDA DE ÍCONOS • Indicates special heed should be taken when reading. • Indique qu’une attention spéciale doit être portée à la lecture. • Indica que uno debe prestar atención al leer. • Indicates the parts to be used for a section. •...

  • Page 5: Notifi Caciones Y Avisos

    WARNINGS & NOTICES / AVERTISSEMENTS ET AVIS / ADVERTENCIAS Y AVISOS English: • Failure to follow these warnings may result in serious injury or property damage and will void warranty. • To ensure safety, do not attempt to assemble this product without following the instructions carefully. •...

  • Page 6: Alertas

    ALERTS / ALERTES / ALERTAS English: If you are assembling a new shed: • Check contents of boxes and compare to parts listed on the next page. • Follow instructions that came with your shed, but add the parts that came with this kit at the appropriate points in the assembly, e.g., insert the Floor Panel when assembling the Floor.

  • Page 7: Identifi Cador De Piezas

    PARTS IDENTIDIER / IDENTIFICATEUR DE PIÈCES / IDENTIFICADOR DE PIEZAS HARDWARE BAGS / SACS DE QUINCAILLERIE / BOLSAS DE HERRAJE Hardware Bags / Sacs de quincaillerie Bolsas de herraje PARTS REQUIRED / PIÈCES REQUISES / PIEZAS REQUERIDAS Metal Parts / Pièces en métal Piezas de metal ”...

  • Page 8: Construcción De La Plataforma

    PLATFORM CONSTRUCTION / CONSTRUCTION DE LA PLATE-FORME / CONSTRUCCIÓN DE LA PLATAFORMA REFER TO YOUR CURRENT SHED PLATFORM FOR MATERIALS USED REPORTEZ-VOUS À VOTRE PLATE-FORME ACTUELLE POUR LES MATÉRIAUX UTILISÉS REFIÉRESE A SU PLATAFORMA ACTUAL PARA LOS MATERIALES USADOS • This extension kit adds another 30" to the length of your shed. Before beginning expansion of your shed, be sure that your site can accommodate the new size.

  • Page 9: Desensamble De La Caseta

    SHED DISASSEMBLY / DÉMONTAGE DE L’ABRI / DESENSAMBLE DE LA CASETA HARDWARE REQUIRED / QUINCAILLERIE REQUISE / HERRAJE REQUERIDO Hardware Bag / Sac de quincaillerie Bolsa de herraje PARTS REQUIRED / PIÈCES REQUISES / PIEZAS REQUERIDAS Plastic Parts / Pièces en plastique Piezas de plástico TOOLS REQUIRED / OUTILS REQUIS / INSTRUMENTAL REQUERIDO...
  • Page 10 SECTION 2 (CONTINUED) / SECTION 2 (SUITE) SECCIÓN 2 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / INSTRUMENTAL Y HERRAJE REQUERIDOS OUTILS ET QUINCAILLERIE REQUIS • If you’ve anchored your shed, remove all anchoring hardware before continuing. Save all hardware removed throughout the instructions! •...
  • Page 11 SECTION 2 (CONTINUED) / SECTION 2 (SUITE) SECCIÓN 2 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / INSTRUMENTAL Y HERRAJE REQUERIDOS OUTILS ET QUINCAILLERIE REQUIS • Remove all Screws (x40) securing the Truss to the Wall Paneles and those securing these two Wall Panels together (regular Wall Panels or Window Wall Panels).
  • Page 12 SECTION 2 (CONTINUED) / SECTION 2 (SUITE) SECCIÓN 2 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / INSTRUMENTAL Y HERRAJE REQUERIDOS OUTILS ET QUINCAILLERIE REQUIS • Gently pry the bottom corner of the Panel away from the adjacent Panel. Slide the Wall Panel to the left and remove it.
  • Page 13 SECTION 2 (CONTINUED) / SECTION 2 (SUITE) SECCIÓN 2 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / INSTRUMENTAL Y HERRAJE REQUERIDOS OUTILS ET QUINCAILLERIE REQUIS • Tilt the rear of the shed upward, and slide it backwards to separate it from the front of the shed. •...

  • Page 14: Ensamble Del Piso

    FLOOR ASSEMBLY / ASSEMBLAGE DU PLANCHER / ENSAMBLAJE DEL PISO HARDWARE REQUIRED / QUINCAILLERIE REQUISE / HERRAJE REQUERIDO Hardware Bag / Sac de quincaillerie Bolsa de herraje BQC (x12) ADC (x1) Note: These Screws do not anchor the Floor; they only hold the Panels together. Note : Ces vis n’ancrent pas le plancher ;...
  • Page 15 SECTION 3 (CONTINUED) / SECTION 3 (SUITE) SECCIÓN 3 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS • 1–Hold a Center Floor Panel (AGJ) at an angle and slide the tabs along the edge underneath the other Center Floor Panel (AGJ). The tabs interlock. 2–Lay Panel down fl...
  • Page 16 SECTION 3 (CONTINUED) / SECTION 3 (SUITE) SECCIÓN 3 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS BQC (x6) ADC (x1) Note: These Screws do not anchor the Floor; they only hold the Panels together. ADC (x1) Note : Ces vis n’ancrent pas le plancher ;...

  • Page 17: Ensamble De La Cercha

    TRUSS ASSEMBLY / ASSEMBLAGE DES FERMES / ENSAMBLE DE LOS ARMAZONES HARDWARE REQUIRED / QUINCAILLERIE REQUISE / HERRAJE REQUERIDO Hardware Bag / Sac de quincaillerie Bolsa de quincaillerie ADJ (x10) AAK (x10) AHT (x2) AIP (x1) PARTS REQUIRED / PIÈCES REQUISES / PIEZAS REQUERIDAS Metal Parts / Pièces en métal Piezas de metal...
  • Page 18 SECTION 4 (CONTINUED) / SECTION 4 (SUITE) SECCIÓN 4 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS AIP (x1) • Place a Truss Connector (AIP) down inside the ends of two Truss Gutter Channels (AFH) as shown. •...
  • Page 19 SECTION 4 (CONTINUED) / SECTION 4 (SUITE) SECCIÓN 4 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS 7/16 in/po (x2) (11 mm) (x2) AAK (x2) ADJ (x2) • Insert two (2) Bolts (AAK) through the fi rst Vertical Truss Brace (AFP), the holes in the Truss Gutter Channels, over the Truss Connector, and out through theTruss Gutter Channels and second Vertical Truss Support (AFP).
  • Page 20 SECTION 4 (CONTINUED) / SECTION 4 (SUITE) SECCIÓN 4 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS 7/16 in/po (x2) (11 mm) (x2) AAK (x4) ADJ (x4) • Secure a Horizontal Truss Brace (AFG) to the Channels and the Vertical Truss Braces using four (4) Bolts (AAK) and Cap Nuts (ADJ).
  • Page 21 SECTION 4 (CONTINUED) / SECTION 4 (SUITE) SECCIÓN 4 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS 7/16 in/po (x2) (11 mm) (x2) AAK (x4) ADJ (x4) AHT (x2) • Attach a Wall Support Channel (AFQ) to each end of the Truss Assembly using the hardware indicated.

  • Page 22: Tejado

    WALL & ROOF ASSEMBLY / ASSEMBLAGE DES MURS ET DU TOIT / ENSAMBLE DE LOS MUROS Y EL TEJADO HARDWARE REQUIRED / QUINCAILLERIE REQUISE / HERRAJE REQUERIDO Hardware Bag / Sac de quincaillerie Bolsa de herraje ADZ (x72) AJA (x4) EVC (x6) PARTS REQUIRED / PIÈCES REQUISES / PIEZAS REQUERIDAS Metal Parts /...
  • Page 23 SECTION 5 (CONTINUED) / SECTION 5 (SUITE) SECCIÓN 5 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS ADZ (x48) • Insert a Wall Panel you removed previously as well as the Wall Panel (AHD) included with this kit. Use the Screws you removed previously as well as the Screws (ADZ) included with this kit to secure the Panels together.
  • Page 24 SECTION 5 (CONTINUED) / SECTION 5 (SUITE) SECCIÓN 5 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS ADZ (x32) • Connect the Truss Assembly you removed previously as well as the Truss Assembly you built using this kit to the center of each Wall Panel and Window Wall Panel with the Screws (ADZ) included and the Screws your removed previously.
  • Page 25 SECTION 5 (CONTINUED) / SECTION 5 (SUITE) SECCIÓN 5 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS EVC (x6) ADZ (x84) • Attach the Center Roof Panels and Roof Supports you removed earlier as well as the Center Roof Panels (AGQ) and Roof Supports (AFL) included with this kit using Screws (ADZ), Screws (ACJ), and Washers (AED).
  • Page 26 SECTION 5 (CONTINUED) / SECTION 5 (SUITE) SECCIÓN 5 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS ADZ (x12) • Attach the Center Roof Cap you removed earlier as well as the Center Roof Cap (AFY) included with this kit using Screws (ADZ).
  • Page 27 SECTION 5 (CONTINUED) / SECTION 5 (SUITE) SECCIÓN 5 (CONTINUACIÓN) TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS INSTRUMENTAL Y HERRAJE REQUERIDOS ADZ (x16) AJA (x16) • Fasten the Gutter Channels to the Roof Panels with Screws (ADZ) (Fig. 1). When fi nished, insert the Foam Cubes (AJA) between the Gutter Channels and Roof Panels (Fig.
  • Page 28 NOTES / REMARQUES / NOTAS...
  • Page 29 All merchandise is sold on this condition, and no representative of the company may waive or change this policy. 5. This product is not intended for institutional or commercial use; Lifetime Products, Inc. does not assume any liability for such use. Institutional or commercial use will void the warranty.
  • Page 30 2. Cette garantie n’est pas transférable et est expressément limitée à la réparation ou au remplacement du produit défectueux. © Si le produit est déclaré défectueux selon les termes de cette garantie, Lifetime Products, Inc. réparera ou remplacera les parties défectueuses gratuitement pour l’acheteur. Les frais d’expédition aller et retour de l’usine ne sont pas couverts et sont à...

  • Page 31: Garantía

    NO ESTÁN DISPONIBLES O SON OBSOLETAS. 1. El comprador original recibe la garantía de que las casetas Lifetime estarán libres de defectos de material o de mano de obra por un período de 10 años a contar desde la fecha de la compra original. La palabra “defectos” se defi ne como imperfecciones que perjudican el uso del producto.
  • Page 32 7:00 am–5:00 pm (M–F) MST and 9:00 am–1:00 pm Saturday MST ® AMÉLIORER L’ACHAT LIFETIME EN AJOUTANT DES ACCESSOIRES OU D’AUTRES PRODUITS ® Pour acheter des accessoires ou des autres produits Lifetime , visiter le : www.lifetime.com (Anglais seulement) Ou composer le 1-800-424-3865 Du lundi au vendredi de 7 h à...
