Charging the battery

6
The scanner battery is charged via the USB interface, so connect the scanner to
the PC and switch the PC on. The charging process is completely controlled by
the scanner, and it will automatically switch off the charging current when the
battery is full.
It takes about 2.5 hours to completely charge an empty battery. While the
battery is being charged, the LED indicator will be red. When the battery is fully
charged, the indicator becomes green.

Buzzer and LED indicators

7
Charge indicators
The descriptions below are indicated when the product is connected to the PC.
Red – Continuous:
The battery is being charged.
Green – Continuous:
The battery is fully charged.
Red / Green flashing:
The battery may be defective. Return the scanner to the nearest Opticon
service centre.
-
