IPPBX IP02 User Manual
Port
The analog port bound with extension.
Name
A character-based name for this extension, i.e. 'Bob Jones'.
Caller ID
CID showed in the other's phone during a call, default is Extension.
2) Voice Mail
Enable Voice Mail
Check this option to enable voice mail account for the extension. Enabled by default.
Voice Mail Access PIN Code
Password for accessing this voice mail account, default is 123456. It's also the password for extension to login his
administration web page.
3) Mail Setting
Enable Sending Voice Mail
Check this option to enable PBX send new voicemail to Email address below as an attachment.
Email Address
The Email address that new voicemail will be send to when Enable Sending Voice Mail is enabled and PBX
settings -> SMTP settings is right set.
4) Volume Settings
Rxgain
Adjust the volume sent to FXS extension. There are 3 options: 20%,60%,100%.
Txgain
Adjust the volume sent out by FXS extension. There are 3 options: 20%,60%,100%.
5) Flash
Hook Flash Detection Time
Sets the amount of time, in milliseconds, that the hook-flash must remain depressed in order for IPPBX to
consider such an event a valid flash event. The default value of it is 1250 ms and it can be configured in 1 ms
increments.
Sequential Hook Flash Interval
Sets the amount of time, in milliseconds, that must have passed since the last hook-flash event received by
IPPBX before it will recognize a second event. If a second event occurs in less time than defined in here, then
IPPBX will ignore the event. The default value is 750 ms, and it can be configured in 1 ms increments.
6) Follow Me
Follow me is a feature to let an incoming call to a called party to be redirected to a third party, the third party can
be a voicemail box, ring group, mobile telephone and so on.
