Summary of Contents for KOBE CH-30 Series
- Page 1 KOBE Brand Range Hood Model No. CH-30 Series INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
-
Page 2: Table Of Contents
[ENGLISH] - READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..................1 COMPONENTS OF PACKAGE....................3 INSTALLATION .......................... 4 OPERATION INSTRUCTIONS....................9 MAINTENANCE ........................10 SPECIFICATIONS ........................11 MEASUREMENTS & DIAGRAMS .....................12 PARTS LIST ..........................14 CIRCUIT DIAGRAM ........................17 TROUBLE SHOOTING ......................14 DISCLAIMER ..........................19 WARRANTY ..........................20 PRODUCT REGISTRATION .....................22... -
Page 3: Important Safety Instructions
KOBE RANGE HOODS authorized agents. KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 4 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 5: Components Of Package
{D} Round Exhaust Plate with damper – 1 {E} Rectangular Exhaust Plate with damper – 1 Light bulb – 2 {G} Parametric Panel – 1 FOR MORE INFORMATION, PLEASE VISIT OUR W EBSITE www.KOBERangeHoods.com CONTACT KOBE RANGE HOODS AT (626) 775-8880. -
Page 6: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1. (All calculation in inches.) - FOR UNDER THE CABINET - TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended 27”... -
Page 7: Figure
Figure 1 Preparation before Installation NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. • Decide the location of the venting pipe from the hood to the outside. Refer to Figure 1. • A straight, short venting run will allow the hood to perform more efficiently. -
Page 8: Screws (Provided). Refer To Figure
Figure 7 Vent option installation 1. Choose the require vent option. NOTE: If the hood is to be installed as ductless application, please do not remove any duct knockout located at the top or the back of the hood. 2. For 7” Round vent installation only: Using a flat-head screwdriver to remove the 7”... -
Page 9: Figure
Figure 12 Wiring to Power Supply SAFETY WARNING RISK OF ELECTRICAL SHOCK. THIS RANGE HOOD MUST PROPERLY GROUNDED. MAKE SURE THIS IS DONE SPECIALIZED ELECTRICIAN ACCORDANCE WITH APPLICABLE NATIONAL LOCAL ELECTRICAL CODES. BEFORE CONNECTING WIRES, SWITCH POWER OFF AT SERVICE PANEL Figure 13 AND LOCK SERVICE PANEL TO PREVENT POWER... - Page 10 Figure 14 Final Assembly 7. To install the parametric panel: Align the parametric panel at the back of the unit. Refer to Figure 14. Push the unit upward, and slide the parametric panel forward into the notch to secure the panel. Refer to Figure 15.
-
Page 11: Operation Instructions
OPERATION INSTRUCTIONS For models equipped with Rotary Switch: To operate the fan function • Turn the Speed Control clockwise to choose speed. • Turn the Speed Control counterclockwise to “OFF”. To operate the light function • Turn the Light Control clockwise to turn on the light. -
Page 12: Maintenance
MAINTENANCE SAFETY WARNING NEVER PUT YOUR HAND INTO AREA HOUSING THE FAN WHILE THE FAN IS OPERATING. Cleaning Hood Surface CAUTION NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. DO NOT USE PAPER TOWEL ON STAINLESS STEEL. For optimal operation, clean range hood and all baffle/spacer/filter/oil tunnel/oil container regularly. *** Regular care will help preserve the appearance of the hood. -
Page 13: Specifications
SPECIFICATIONS Series CH30 Series CONSUMPTION / AMPERE 0.82 Ampere VOLTAGE 120V 60Hz NUMBER OF MOTORS DESIGN 20-Gauge Seamless / Satin Finish with Glass Parametric panel or Stainless Steel Parametric panel EXHAUST Top 7” Round with damper Top 3-1/4” x 10” Rectangular with damper Rear 3-1/4”... -
Page 14: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS All measurements in ( ) are millimeters. All inch measurements are converted from millimeters. Inch measurements are estimated. - FOR TOP VENTING - - FOR REAR VENTING -... - Page 15 - DIMENSIONS OF THE MODEL-...
-
Page 16: Parts List
PARTS LIST For models equipped with Push Button: HOOD DESCRIPTION MODEL /SIZE PART NO. Motor Mounting Plate K-Y21-2355-P CH3030PD (30”) K-Y20-1248-Q Hood Frame CH3036PD (36”) K-Y20-1219-Q Recirculating Box K-Y36-0228 Light socket K-GF F005-00000 Push Button Control K-Y50-0087 Light Support K-Y20-1273-P CH3030PD (30”) K-Y20-1278-Q Light / Control Panel... - Page 17 HOOD DESCRIPTION MODEL /SIZE PART NO. Motor Mounting Plate K-Y21-2355-P CH3030RD (30”) K-Y20-1248-Q Hood Frame CH3036RD (36”) K-Y20-1219-Q Recirculating Box K-Y36-0228 Light socket K-GF F005-00000 Speed Control K-Y50-0085 Light Control K-Y50-0084 Light Support K-Y20-1273-P CH3030RD (30”) K-Y20-1249-P Light / Control Panel CH3036RD (36”) K-Y20-1220-P Light fixture...
- Page 18 For models equipped with Slide Switch: HOOD DESCRIPTION MODEL /SIZE PART NO. Motor Mounting Plate K-Y21-2355-P CH3030SD (30”) K-Y20-1248-Q Hood Frame CH3036SD (36”) K-Y20-1219-Q Recirculating Box K-Y36-0228 Light socket K-GF F005-00000 Light Support K-Y20-1273-P CH3030SD (30”) K-Y20-1296-Q Light / Control Panel CH3036SD (36”) K-Y20-1297-Q Light fixture...
-
Page 19: Circuit Diagram
CIRCUIT DIAGRAM For models equipped with Push Control: For models equipped with Rotary Switch: For models equipped with Slide Switch:... -
Page 20: Trouble Shooting
TROUBLE SHOOTING Issue Possible Cause Solution After Installation, The power is not on. Make sure the circuit breaker and the unit’s power is both motors and ON. Use a voltage meter to check the power supply. lights are not The wire connection is not secure. Check and tighten wire connection. -
Page 21: Disclaimer
2. PLEASE INSPECT CONTENTS OF PACKAGE(S) CAREFULLY UPON RECEIVING! We must be notified in writing of any damages and/or missing parts within the allocated days upon your receipt of package(s). Contact your local KOBE dealer or distributor or call KOBE for the time limit. -
Page 22: Warranty
Any covered failure occurring within one year of original purchase arising from defective workmanship or material in manufacture will be at our discretion, replaced free of charge by KOBE Range Hoods as applicable. Keep proof of purchase (or original invoice) handy for inspection. - Page 23 Some states do not allow limitations on the duration of implied warranties. This warranty gives you specific legal rights, and may also have rights, which vary from state to state. SERVICE For service contact: KOBE Range Hoods 11775 Clark Street Arcadia, CA 91006 U.S.A.
-
Page 24: Product Registration
Any covered failure occurring within one year of original purchase arising from defective workmanship or material in manufacture will at our discretion, replaced free of charge by KOBE Range Hoods as applicable. Keep proof of purchase (original invoice) handy for inspection. - Page 25 Arcadia, CA 91006 USA http://www.KOBERangeHoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
