CLEAnInG AnD CArE
Ensure the appliance is off and cool before cleaning.
Enamel (on burner skirts and trivets)
persistent stains may require rubbing with a nylon
scourer or creamed powder cleansers. Household
instructions in their use. Harsh abrasive cleaners,
powder cleaners, steel wool or wax polishes should
not be used.
(Models with Stainless Steel hob)
Simply wipe with a soft cloth using warm water and a mild
detergent and rinse with clean water. Where stainless steel
steel cleaner – but be sure to follow the brushing lines.
Do noT use abrasive cleaners or harsh solvents.
Scrapers are to be used on ceramic models only
(on models with glass hob)
the specially treated glass in the product is
manufactured using the latest technology to the highest
possible standards for both safety and reliability.
the ceramic glass hob use a soft cloth or sponge with
detergent and warm water.
immediately to avoid the possibility of electric shock.
If the hob is very soiled:
1. remove soilage using the razor blade scraper.
2. use a hob cleaner product after there has been
bottle and apply a small quantity of cleaner directly
onto the hob. rub clean using a damp cloth or
3. use a damp cloth to remove all remaining traces of the
is next used. Wipe the hob dry.
Use the scraper supplied to remove spillages
immediately, while the hob is still hot! Especially
sugar and foods with a high sugar content (eg. jam),
melted plastics and foil, all of which can damage
the hob if left.
razor blade scraper
use the scraper to remove spillages from the ceramic hob.
How to use the razor blade scraper:
1. pull back the protective cover until the blade is visible.
2. make sure that the razor blade is clean and not worn.
hob. new razor blades can be bought
3. Angle scraper at approx. 45° and scrape away the
spillage. the razor blade can be pressed down hard
onto the hob without causing any damage.
4. Carefully clean the blade by wiping it with a
5. W henyouhavefinished,presstheprotectivecover
forwards as far as it will go. Keep the scraper out of
the reach of children.
Changing the razor blade:
1. open the scraper by completely unscrewing the screw
and then place the new razor blade at the front edge.
2. put the scraper together again and screw the screw
back into place.
3. press the protective cover forwards as far as it will go
to cover the razor blade.
THE raZor BLaDE SCraPEr SHoULD
BE KEPT WELL oUT oF THE rEaCH oF
CHILDrEn. Use the razor blade scraper
carefully, as the razor blade is extremely sharp.
Trivets and burners
these can all be lifted off and removed for separate
NOTE! When refitting the burners, ensure that they are
Ensure burners are thoroughly dried after cleaning or
flame ports are free of any blockage (refer to figure
to clear ports. the outer surface of the burner caps
to avoid scratching this surface during cleaning. In
a non-abrasive cleaning compound and rub with a cloth
NOTE! DO NOT place trivets or burners in the
Ignition spark plug and flame safeguard sensor
GEnTLY clean the ignition spark plug and flame
safeguard sensor with a damp cloth to avoid lighting
Ensure the injector remains free of any foreign material.
