2.10 Installing SODIMMs

Notes
The procedure for installing SODIMMs appears below. Please follow
these steps carefully.
1. Make sure that all power supplies to the system are switched off
2. Install the SODIMM card. Install the SODIMM so that its gold pins
point down into the SODIMM socket.
3. Slip the SODIMM into the socket at a 45 degree angle and care-
fully fit the bottom of the card against the connectors.
4. Gently push the SODIMM into a perpendicular position until the
clips on the ends of the SODIMM sockets snap into place.
5. Check to ensure that the SODIMM is correctly seated and all con-
nector contacts touch. The SODIMM should not move around in its
socket.

2.11 ATX power control Connector (CN5)

The PCI-6881 supports ATX power. CN5 supplies main power (+5 V ,
+12 V , 5 VSB), and it is a 6 x 2 pins power connector, w/Fixed Lock
4200-WS-A1.
Important
PCI-6881 User Manual
The modules can only fit into a socket one way.
The gold pins must point down into the
SODIMM socket.
Make sure that the ATX power supply can take
at least a 10 mA load on the 5 V standby lead
(5 VSB). If not, you may have difficulty power-
ing on your system.
