PCI-6870 series
Socket 370 Pentium
III/Celeron™
®
Half-sized CPU Card with High Speed
PCI Bus, VGA, Fast Ethernet and
CompactFlash Type II card

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCI-6870 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech PCI-6870 Series

Summary of Contents for Advantech PCI-6870 Series

  • Page 1 PCI-6870 series Socket 370 Pentium III/Celeron™ ® Half-sized CPU Card with High Speed PCI Bus, VGA, Fast Ethernet and CompactFlash Type II card...
  • Page 2 UMC is a trademark of United Microelectronics Corporation. All other product names or trademarks are properties of their respective owners. For more information on this and other Advantech products please visit our website at: http://www.advantech.com http://www.advantech.com/epc For technical support and service for please visit our support website at: http://www.advantech.com/support...
  • Page 3 • 1 ea. CD (Driver & utility) • 1 ea. Warranty card Note 1: For detailed contents of the PCI-6870 series, please refer to the enclosed CD-ROM or disk (in PDF format). If any of these items are missing or damaged, contact your distributor or sales representative immediately.

  • Page 4: Table Of Contents

    Contents Chapter 1 General Information ......... 1 1.1 Introduction ................. 2 1.2 Specifications ................3 1.3 Features ..................5 1.4 Board layout: Dimensions ............6 Chapter 2 Installation ............7 2.1 Safety Precautions ..............8 2.2 Jumpers ..................8 2.3 Connectors .................. 9 2.3.1 Locating Jumpers and Connectors ........
  • Page 5 2.6 Adding System Memory (DIMM) ..........21 2.6.1 Installing DIMMs .............. 21 2.7 CPU installation and upgrading ..........22 Chapter 3 Award BIOS Setup .......... 23 3.1 AWARD BIOS Setup ..............24 3.1.1 Entering setup ..............24 3.1.2 Standard CMOS setup ............25 3.1.3 Advanced BIOS Features ..........
  • Page 6 Chapter 6 Audio ..............83 6.1 Introduction ................84 6.2 Installation of audio driver ............84 6.2.1 Installation for Windows 98 and 2000 ........ 85 6.2.2 Installation for Windows NT ..........92 Appendix A Programming the Watchdog Timer ..... 95 A.1 Programming the Watchdog Timer ........

  • Page 7: Chapter 1 General Information

    General Information This chapter gives background information on the PCI-6870. Sections include: • Introduction • Features • Specifications • Board layout and dimensions...

  • Page 8: Introduction

    VGA (AGP) controller, one DIMM slot for up to 512 MB RAM memory and a 10/100Base-T Ethernet controller. In addition, the PCI-6870 series supports a solid state disk (SSD) using a CompactFlash™ Type II disk that is not as vulnerable to the hazards of an industrial computing environment.

  • Page 9: Specifications

    1.2 Specifications Standard SBC functions • CPU: Socket 370 for Intel Pentium III processors up to 1.26 GHz, ® and Celeron™ processor up to 1.2 GHz • BIOS: 2 Mbit Flash BIOS, Supports Plug & Play, APM 1.2 Supports Ethernet Boot ROM Supports boot from USB device Supports boot from CD-ROM Supports boot from LS-120 ZIP™...
  • Page 10 • Watchdog timer: 62 levels timer interval, setup by software, jumperless selection, generates system reset. VGA function AGP SVGA Interface • Chipset: Intel 815E embedded • Display memory: Shares system memory up to 4MB • Display type: CRT • Interface: Direct AGP, Accelerator Graphics Ports 1.0 compliant •...

  • Page 11: Features

    1.3 Features • Supports Socket 370 for Intel Pentium III/Celeron™ ® ® processor • Direct AGP supports 24 bit CRT • USB interface compliant with USB rev. 1.0 • System overheat temperature control • 62-levels Watchdog timer with system reset or IRQ11 •...

  • Page 12: Board Layout: Dimensions

    1.4 Board layout: Dimensions Figure 1-1: PCI-6870 (dimensions) PCI-6870 User's Manual...

  • Page 13: Chapter 2 Installation

    Installation This chapter tells how to set up the PCI-6870 hardware. It includes instructions on setting jumpers, and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation procedure.

  • Page 14: Safety Precautions

    2.1 Safety Precautions Follow these simple precautions to protect yourself from harm and your PC from damage. 1. To avoid electric shock, always disconnect the power from your PC chassis before you work on it. Don't touch any components on the CPU card or other cards while the PC is on.

  • Page 15: Connectors

    2.3 Connectors On-board connectors link the PCI-6870 to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the function of each of the board’s connectors. Table 2-2: Connectors Label Function CompactFlash Type I C N 1 IrDA C N 2...

  • Page 16: Locating Jumpers And Connectors

    2.3.1 Locating Jumpers and Connectors B I O S B I O S B I O S B I O S B I O S Figure 2-1: Locating connectors (component side) PCI-6870 User's Manual...

  • Page 17: Setting Jumpers

    2.4 Setting jumpers You configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To “close”...

  • Page 18: Com2 Settings For Rs-232/422/485 (J3)

    2.4.1 COM2 settings for RS-232/422/485 (J3) Table 2-3: COM2 settings for RS-232/422/485 (J3) *RS-232 RS-422 RS-485 * default setting 2.4.2 CMOS clear function (J4) Warning: To avoid damaging the computer, always turn off the power supply before setting "Clear CMOS". Set the jumper back to normal before turning on the power supply.

  • Page 19: Watchdog Timer Config. (J5)

    2.4.3 Watchdog timer config. (J5) An on-board watchdog timer reduces the chance of disruptions which EMP (electro-magnetic pulse) interference can cause. This is an invaluable protective device for standalone or unmanned applications. Setup involves one jumper and running the control software.

  • Page 20: Ir Connector (Cn1)

    2.5 Installation Caution The following sections tell how to make each connection. In most cases, you will simply need to connect a standard cable. All of the connector pin assignments are shown in Appendix C. Warning! Always completely disconnect the power cord from your chassis whenever you are working on it.

  • Page 21: Connection (Com1-Cn3)

    2.5.3 RS-232 connection (COM1-CN3) Different devices implement the RS-232 standard in different ways. If you are having problems with a serial device, be sure to check the pin assignments for the connector. 2.5.4 Keyboard & PS/2 Mouse Connector (CN4) The PCI-6870 board provides a keyboard connector. A 6-pin mini- DIN connector (CN4) on the card mounting bracket supports single-board computer applications.

  • Page 22: Parallel Port Connector (Cn7)

    2.5.6 Parallel Port Connector (CN7) The parallel port is normally used to connect the CPU card to a printer. The PCI-6870 includes an on-board parallel port, accessed through a 26-pin flat-cable connector, CN7. The card comes with an adapter cable which lets you use a traditional DB-25 connector. The cable has a 26-pin connector on one end and a DB-25 connector on the other, mounted on a retaining bracket.

  • Page 23: Usb Connector (Cn9)

    2.5.8 USB Connector (CN9) The PCI-6870 board provides two USB (Universal Serial Bus) interfaces, which give complete plug and play and also hot attach/detach for up to 127 external devices. The USB interfaces comply with USB specification rev. 1.0 and are fuse protected. The USB interfaces are accessed through a 10-pin flat-cable connector, CN9.

  • Page 24: Ethernet Configuration (Cn14)

    2.5.12 Ethernet Configuration (CN14) The PCI-6870 is equipped with a high performance 32-bit PCI-bus Fast Ethernet interface which is fully compliant with IEEE 802.3u 10/100Base-T specifications. It is supported by all major network operating systems. The medium type can be configured via the RSET8139.EXE program included on the utility disk.

  • Page 25: Serial Irq ???? (Cn16)

    Connect the first hard drive to the other end of the cable. Wire 1 on the cable should also connect to pin 1 on the hard drive connector, which is labeled on the drive circuit board. Check the documentation that came with the drive for more information. Connect the second drive, as described above, on CN15.

  • Page 26: Video Expansion Connector ???? (Cn19)

    Plug the other end of the cable into the Enhanced IDE hard drive, with pin 1 on the cable corresponding to pin 1 on the hard drive. (See your hard drive’s documentation for the location of the connector.) If desired, connect a second drive as described above. Unlike floppy drives, IDE hard drives can connect to either end of the cable.

  • Page 27: Adding System Memory (Dimm)

    2.6 Adding System Memory (DIMM) You can install anywhere from 8 to 512 MB of SDRAM into your PCI-6870 series card. The card is provided with a 168-pin DIMM socket, which accepts 32, 64, 128, 256, or 512 MB 3.3 V power level DIMMs.

  • Page 28: Cpu Installation And Upgrading

    2.7 CPU installation and upgrading 1. If you are upgrading the CPU, remove the old CPU from the socket. If it is difficult to remove, you may find chip lubricant (designed for pin-grid-array devices, PGAs) and a chip puller helpful. Both are available at electronics hobby supply stores. 2.

  • Page 29: Chapter 3 Award Bios Setup

    Award BIOS Setup This chapter describes how to set the card’s BIOS configuration data.

  • Page 30: Award Bios Setup

    3.1 AWARD BIOS Setup The Award BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed RAM so that it retains the Setup information when the power is turned off. 3.1.1 Entering setup Turn on the computer and immediately press <DEL>.

  • Page 31: Standard Cmos Setup

    3.1.2 Standard CMOS setup Choose the “STANDARD CMOS SETUP” option from the INITIAL SETUP SCREEN Menu, and the screen below is displayed. This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory. Figure 3-2: CMOS setup screen Chapter 3 Award BIOS Setup...

  • Page 32: Advanced Bios Features

    3.1.3 Advanced BIOS Features The ADVANCED BIOS FEATURES is a submenu from the initial BIOS setup screen. It allows the user to configure the PCI-6870 according to his particular requirements. Below are some major items that are provided in the ADVANCED BIOS FEATURES SETUP screen: Figure 3-3: Advanced BIOS Features setup screen Virus Warning...
  • Page 33 Quick Power On Self Test This option speeds up the Power-On Self Test (POST) conducted as soon as the computer is turned on. When enabled, BIOS shortens or skips some of the items during the test. When disabled, normal POST procedures assumes.
  • Page 34 Boot Up System Speed High Sets the speed to high Sets the speed to low IDE HDD Block Mode Enabled Enable IDE HDD Block Mode. BIOS will detect the block size of the HDD and send a block command automatically. Disabled Disable IDE HDD Block Mode Gate A20 option...
  • Page 35 System The system will not boot, and access to Setup will be denied if the correct password is not entered at the prompt. Setup The system will boot, but access to Setup will be denied if the correct password is not entered at the prompt. Note: To disable security, select PASSWORD SETTING in the main menu.

  • Page 36: Advanced Chipset Features

    3.1.4 Advanced Chipset Features By choosing the “ADVANCED CHIPSET FEATURES” option from the INITIAL SETUP SCREEN Menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI- 6870. Figure 3-4: Advanced Chipset Features screen PCI-6870 User's Manual...

  • Page 37: Integrated Peripherals

    3.1.5 Integrated Peripherals Choosing the Integrated Peripherals option from the Initial Setup Screen menu should produce the screen below. Here we see the manufacturer’s default values for the PCI-6870 Series. Figure 3-5: Integrated Peripherals Chapter 3 Award BIOS Setup...

  • Page 38: Power Management Setup

    3.1.6 Power management setup The power management setup controls the CPU cards’ “green” features. The following screen shows the manufacturer’s defaults. Figure 3-6: Power management setup screen Power Management This option allows you to determine if the values in power manage- ment are disabled, user-defined, or predefined.

  • Page 39: Pnp Pci Configuration Setup

    3.1.7 PnP PCI configuration setup By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6870 Series. Figure 3-7: PCI configuration screen Chapter 3 Award BIOS Setup...

  • Page 40: Pc Health Status

    3.1.8 PC Health Status The PC Health Status screen looks like this. It displays information such as CPU and motherboard temperatures, fan speeds, and core voltage. Figure 3-8: PC Health Status PCI-6870 User's Manual...

  • Page 41: Frequency/Voltage Control

    3.1.9 Frequency/Voltage Control By choosing the Frequency/Voltage Control option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6870. Figure 3-9: Frequency/Voltage Control Caution Incorrect settings in Frequency/Voltage Control may damage the system CPU, video adapter, or other hardware.

  • Page 42: Load Optimized Defaults

    ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load automatically when you turn the PCI-6870 Series system on. 3.1.11 Set Password To establish, change, or disable the password, choose the “SET PASSWORD”...

  • Page 43: Save & Exit Setup

    Select Save to CMOS and EXIT, type <Y>, then <Enter>. To Disable Password Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,” enter the existing password and press <Enter>. You will see “Confirm Password.”...
  • Page 44 PCI-6870 User's Manual...

  • Page 45: Chapter 4 Agp Svga Setup

    AGP SVGA Setup • Introduction • Installation of SVGA driver for - Windows 98 and 2000 - Windows NT...

  • Page 46: Introduction

    4.1 Introduction The PCI-6870 has an on-board AGP flat panel/VGA interface. The specifications and features are described as follows: 4.1.1 Chipset The PCI-6870 makes use of the display properties of the Intel 815E AGP/SVGA controller. It supports interlaced and non-interlaced analog monitors (color and monochrome VGA) in high-resolution modes while maintaining complete IBM VGA compatibility.
  • Page 47 and graphics on a flat panel and CRT. To set up dual display under Windows 98, follow these steps: 1. Select “Windows98”, “Control panel”, “Display”, “Settings”. 2. Select “1” for current display, or “2” for second display. 3. Enable “Extend my Windows desktop onto this monitor”. 4.

  • Page 48: Installation Of Svga Driver

    4.2 Installation of SVGA driver Complete the following steps to install the SVGA driver. Follow the procedures that apply to the operating system that you are using within your PCI-6870. Important: The following windows illustrations are examples only. You must follow the instructions which appear on your screen.

  • Page 49: Installation For Windows 98 And 2000

    4.2.1 Installation for Windows 98 and 2000 Insert the disk, or otherwise make the files available to the system, and run setup. Then proceed as directed by the prompts. Chapter 4 AGP SVGA Setup...
  • Page 50 PCI-6870 User's Manual...
  • Page 51 Chapter 4 AGP SVGA Setup...
  • Page 52 PCI-6870 User's Manual...
  • Page 53 Chapter 4 AGP SVGA Setup...

  • Page 54: Installation For Windows Nt

    4.2.2 Installation for Windows NT Insert the disk, or otherwise make the files available to the system, and run setup. Then proceed as directed by the prompts. PCI-6870 User's Manual...
  • Page 55 Chapter 4 AGP SVGA Setup...
  • Page 56 PCI-6870 User's Manual...
  • Page 57 Chapter 4 AGP SVGA Setup...

  • Page 58: Further Information

    4.3 Further information For further information about the AGP/SVGA installation in your PCI- 6870, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Trident website: www.trid.com Advantech websites: www.advantech.com www.advantech.com.tw PCI-6870 User's Manual...

  • Page 59: Chapter 5 Pci Bus Ethernet Interface

    PCI Bus Ethernet Interface This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet driver for Windows 98 & 2000 • Installation of Ethernet driver for Windows NT • Further information...

  • Page 60: Introduction

    5.1 Introduction The PCI-6870 is equipped with a high performance Intel 82562ET 32-bit Ethernet chipset. This is a highly integrated Platform LAN Connect (ICH2/3/4) device combining 10BASE-T and 100BASE-TX physical layer capabilities. It is fully compliant with the IEEE 802.3/ 802.3u standard.

  • Page 61: Installation For Windows 98 And 2000

    5.2.1 Installation for Windows 98 and 2000 Insert the disk, or otherwise make the files available to the system, and run the executable. Then proceed as directed by the prompts. Chapter 5 PCI Bus Ethernet Interface...
  • Page 62 PCI-6870 User's Manual...
  • Page 63 Chapter 5 PCI Bus Ethernet Interface...
  • Page 64 PCI-6870 User's Manual...
  • Page 65 Chapter 5 PCI Bus Ethernet Interface...
  • Page 66 PCI-6870 User's Manual...
  • Page 67 Chapter 5 PCI Bus Ethernet Interface...
  • Page 68 PCI-6870 User's Manual...
  • Page 69 Chapter 5 PCI Bus Ethernet Interface...
  • Page 70 PCI-6870 User's Manual...
  • Page 71 Chapter 5 PCI Bus Ethernet Interface...
  • Page 72 PCI-6870 User's Manual...

  • Page 73: Installation For Windows Nt

    5.2.2 Installation for Windows NT Insert the disk, or otherwise make the files available to the system, and run the appropriate executable. Then proceed as directed by the prompts. Chapter 5 PCI Bus Ethernet Interface...
  • Page 74 PCI-6870 User's Manual...
  • Page 75 Chapter 5 PCI Bus Ethernet Interface...
  • Page 76 PCI-6870 User's Manual...
  • Page 77 Chapter 5 PCI Bus Ethernet Interface...
  • Page 78 PCI-6870 User's Manual...
  • Page 79 Chapter 5 PCI Bus Ethernet Interface...
  • Page 80 PCI-6870 User's Manual...
  • Page 81 Chapter 5 PCI Bus Ethernet Interface...
  • Page 82 PCI-6870 User's Manual...
  • Page 83 Chapter 5 PCI Bus Ethernet Interface...
  • Page 84 PCI-6870 User's Manual...
  • Page 85 Chapter 5 PCI Bus Ethernet Interface...
  • Page 86 PCI-6870 User's Manual...
  • Page 87 Chapter 5 PCI Bus Ethernet Interface...

  • Page 88: Further Information

    5.3 Further information Intel website: http://www.intel.com/design/network/products/lan/controllers/82562.htm Advantech website: www.advantech.com www.advantech.com.tw PCI-6870 User's Manual...

  • Page 89: Chapter 6 Audio

    Audio • Introduction • Installation of audio driver for Windows 98 and 2000 • Installation of audio driver for Windows NT...

  • Page 90: Introduction

    Introduction The PCI-6870's on-board audio interface provides high-quality stereo sound and FM music synthesis (ESFM) by using the Cs5530A audio controller from Cyrix Corporation. The audio interface can record, compress, and play back voice, sound, and music with a built-in mixer control.

  • Page 91: Installation For Windows 98 And 2000

    6.2.1 Installation for Windows 98 and 2000 Chapter 6 Audio...
  • Page 92 PCI-6870 User's Manual...
  • Page 93 Chapter 6 Audio...
  • Page 94 PCI-6870 User's Manual...
  • Page 95 Chapter 6 Audio...
  • Page 96 PCI-6870 User's Manual...
  • Page 97 Chapter 6 Audio...

  • Page 98: Installation For Windows Nt

    6.2.2 Installation for Windows NT PCI-6870 User's Manual...
  • Page 99 Chapter 6 Audio...
  • Page 100 PCI-6870 User's Manual...

  • Page 101: Appendix A Programming The Watchdog Timer

    Programming the Watchdog Timer The PCI-6870 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 102: Programming The Watchdog Timer

    A.1 Programming the Watchdog Timer To program the watchdog timer, you must write a program which writes I/O port address 443 (hex). The output data is a value of time interval. The value range is from 01 (hex) to 3E (hex), and the related time interval is 1 sec.
  • Page 103 After data entry, your program must refresh the watchdog timer by rewriting the I/O port 443 (hex) while simultaneously setting it. When you want to disable the watchdog timer, your program should read I/O port 443 (hex). The following example shows how you might program the watchdog timer in BASIC: Watchdog timer example program OUT &H443, data REM...
  • Page 104 PCI-6870 User's Manual...

  • Page 105: Appendix B Filler

    Filler This appendix is supplied so that we can use the old Appendixes C and D, which are perfectly good, without changing all the references to them that appear in the text. We didn't want anyone to think that we forgot Appendix B.
  • Page 106 This page intentionally left pretty much blank. PCI-6870 User's Manual...

  • Page 107: Appendix C Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • CRT display connector • RS-232/422/485 serial port connector • Keyboard and mouse connector • External keyboard connector • Main power connectors (AT/ATX) • IDE connector •...

  • Page 108: Compactflash Card Connector (Sk1)

    * IOCS16 * CD2 * CD1 * CS1 * VS1 * IORD * IOWR * WE INTRQ +5 V * CSEL * VS2 * RESER IORDY * INPACK * REG * DASP * PDIAG * low active PCI-6870 Series Appendix C...

  • Page 109: Ir Connector (Cn1)

    C.2 IR Connector (CN1) Table C-2: IR connector Signal +5 V IRRX IR_RX IR_TX Appendix C Pin Assignments...
  • Page 110 C.3 VGA Display Connector (CN2) Table C-3: CRT display connector Signal Signal GREEN BLUE H-SYNC V-SYNC PCI-6870 Series Appendix C...

  • Page 111: Com1 Rs-232 Serial Port (Cn3)

    C.4 COM1 RS-232 Serial Port (CN3) Table C-4: COM1 RS-232 serial port Signal SOUT Appendix C Pin Assignments...
  • Page 112 C.5 Keyboard and Mouse Connnector (CN4) Table C-5: Keyboard and mouse connector Signal KBCLK KBDATA MSCLK signal MSDATA signal PCI-6870 Series Appendix C...

  • Page 113: Atx Power Connector (Cn6)

    C.6 ATX Power Connector (CN6) Table C-6: ATX power connector Signal 5 V SB PS_ON Appendix C Pin Assignments...

  • Page 114: Printer Port Connector (Cn7)

    C.7 Printer Port Connector (CN7) 25 23 26 24 Table C-7: Parallel port connector Signal * STROBE * AUTOFD * INIT * SLCTINI ACK# BUSY SLCT * low active PCI-6870 Series Appendix C...

  • Page 115: Com2 Rs-422/485 Serial Port (Cn8)

    C.8 COM2 RS-422/485 Serial Port (CN8) Table C-8: COM2 RS-232/422/485 serial port RS-422 port RS-485 port TXD- DATA- TXD+ DATA+ RXD+ RXD- Appendix C Pin Assignments...

  • Page 116: External Keyboard Connector (Cn21)

    C.9 USB1/USB2 Connector (CN9) Table C-9: USB1/USB2 connector USB1 USB2 USBV0 USBV1 USBD0- USBD1- USBDO+ USBD1+ USBG0 USBG1 Chassis GND...

  • Page 117: Ebx Power Connector (Cn11)

    C.10 EBX Power Connector (CN11)

  • Page 118: Atx Power Switch (Cn13)

    C.11 CPU Fan Power Connector (CN12) Table C-10: CPU fan power connector Signal +12 V FAN_DEC PCI-6870 Series Appendix C...

  • Page 119: C.12 Atx Power Switch (Cn13)

    C.12 ATX Power Switch (CN13) Table C-11:ATX power switch Signal Standby 5 V Power ON Appendix C Pin Assignments...

  • Page 120: Cd-Rom In Connector (Cn14)

    C.13 CD-ROM in connector (CN14) Table C-12: CD-ROM connector Signal CD_R CD_L PCI-6870 Series Appendix C...

  • Page 121: Ide Hard Drive Connector (Cn15)

    C.14 IDE Hard Drive Connector (CN15) Table C-13: IDE hard drive connector Signal Signal IDE RESET* DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0...

  • Page 122: Audio Connector (Cn17)

    SPEAKER OUT R+ 2 SPEAKER OUT R- SPEAKER OUT L+ 4 SPEAKER OUT L- LINE OUT R LINE OUT L LINE IN R LINE IN L MIC1 MIC2 C.16 Secondary IDE (ATA33) C.17 Video Expansion Connector (CN19) PCI-6870 Series Appendix C...

  • Page 123: Floppy Drive Connector (Cn20)

    C.18 Floppy Drive Connector (CN20) 33 31 ..3 1 34 32 ..4 2 Table C-15: Floppy drive connector Signal Signal RWC# INDEX# MOA# DSB# DSA# MOB# DIR# STEP# TRAK0# RDATA# HEAD# DSKCHG# * low active Appendix C Pin Assignments...
  • Page 124 PCI-6870 Series Appendix C...

  • Page 125: Appendix D System Assignments

    System Assignments This appendix contains information of a detailed or specialized nature. It includes: • System I/O ports • DMA channel assignments • Interrupt assignments • 1st MB memory map...

  • Page 126: System I/O Ports

    D.1 System I/O Ports Table D-1: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 022-023 Chipset address 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register 0A0-0BF Interrupt controller 2 0C0-0DF...

  • Page 127: Dma Channel Assignments

    D.2 DMA Channel Assignments Table D-2: DMA channel assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available * Audio DMA select 0, 1 or 3 D.3 Interrupt Assignments Table D-3: Interrupt assignments Interrupt# Interrupt source IRQ 0...

  • Page 128: 1St Mb Memory Map

    D.4 1st MB Memory Map Table D-4:1st MB memory map Addr. range (Hex) Device F000h - FFFFh System ROM C800h - EFFFh Expansion ROM C000h - C7FFh System ROM B800h - BFFFh CGA/EGA/VGA text B000h - B7FFh Unused A000h - AFFFh EGA/VGA graphics 0000h - 9FFFh Base memory...
