PCI-6886
®
®
PCI Intel
Celeron
M 600MHz
0L2 Half-sized SBC with VGA/
LVDS/LAN/USB2.0/SATA and
SDD
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCI-6886F-M0A1 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech PCI-6886F-M0A1

Summary of Contents for Advantech PCI-6886F-M0A1

  • Page 1 PCI-6886 ® ® PCI Intel Celeron M 600MHz 0L2 Half-sized SBC with VGA/ LVDS/LAN/USB2.0/SATA and User’s Manual...
  • Page 2 Copyright This document is copyrighted, © 2005. All rights are reserved. The origi- nal manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of the original manufacturer.

  • Page 3: Packing List

    Packing List Before you begin installing your card, please make sure that the following materials have been shipped: • 1 PCI-6886 all-in one single board computer • 1 startup manual • 1 CD-ROM or disks for utility, drivers, and manual (in PDF format) •...
  • Page 4 Model No. List Description PCI-6886F-M0A1 PCI Celeron M 600M 0L2 Slot PC W/852GM PCI-6886FG-M0A1 PCI Celeron M 600M 0L2 Slot PC W/852GM,Giga LAN Additional Information and Assistance Visit the our website at www.emacinc.com where you can find the latest information about the product.
  • Page 5 This device complies with the requirements in part 15 of the FCC rules: Operation is subject to the following two conditions: 1.This device may not cause harmful interfer- ence, and 2. This device must accept any interference received, including interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class A digital device,...
  • Page 6 PCI-6886 User’s Manual...

  • Page 7: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Features ................2 Specifications ..............3 1.3.1 Standard SBC Functions..........3 1.3.2 Display Interface............. 4 1.3.3 DVI ................. 4 1.3.4 Solid State Disk .............. 4 1.3.5 PCI bus Ethernet interface ..........4 1.3.6 Mechanical and Environmental ........
  • Page 8 2.19 Front Panel Connector (CN1) ......... 19 2.19.1 Reset (Pin7&Pin8) ............19 2.19.2 HDD LED (Pin1&Pin2)..........19 2.19.3 Power LED (Pin 3 & Pin 4) .......... 20 2.19.4 Suspend LED(Pin 5 & Pin 6)........20 2.19.5 Power Button (Pin 9 & Pin10)........20 2.20 COM port connector (CN8,CN13,CN14) .......
  • Page 9 4.2.13 Exit Without Saving............41 Figure 4.13:Quit without saving ........41 Chapter 5 PCI SVGA Setup ..........44 Introduction ..............44 5.1.1 Chipset ................44 5.1.2 Display memory............44 5.1.3 Display types..............44 Installation of the SVGA Driver ........45 5.2.1 Installation for Windows 2000/XP .......
  • Page 10 Table B.9:LCD INV power connector (CN20) .... 72 B.10 DIO connector(CN2)............73 Table B.10:DIO connector(CN2) ......... 73 B.11 LVDS connector(CN15) ..........74 Table B.11:LVDS connector (CN15) ......74 B.12 LPT connector(CN6)............75 Table B.12:LPT connector(CN6) ......... 75 B.13 COM 1, 2 Connector (CN13, CN14) ......76 Table B.13:COM connector (CN 13, CN14)....
  • Page 11 General Information This chapter gives background information on the PCI-6886. Sections include: • Introduction • Features • Specifications • Board layout and dimensions Chapter 1 General Information...

  • Page 12: Chapter 1 General Information

    1.2 Features • Intel new generation Celeron M 600MHz 0L2 cache Processor Embedded • Fanless operation at 0~60°C (PCI-6886F-M0A1 & PCI-6886FG- M0A1) • On board PCI VGA/LVDS/DVI display • 1000BASE-T Ethernet on board(PCI-6886FG-M0A1) • Supports 2 SATA...

  • Page 13: Specifications

    • Supports 4 x USB2.0 port • Supports 2 Channel 36bits LVDS for LCD • Supports 400MHz Front Side Bus • Supports 200-MHz, and 266-MHz DDR SDRAM 1.3 Specifications 1.3.1 Standard SBC Functions • CPU:Intel Celeron M 600MHz(0 KB) onboard:(PCI-6886F- M0A1,PCI-6886FG-M0A1).

  • Page 14: Display Interface

    1.3.2 Display Interface • Chipset: Intel 852GM • Memory size: Optimized Shared Memory Architecture,supports up to 64 MB frame buffer using system memory • Display modes: CRT Modes: up to 1600 x 1200 @32bpp (85Hz); LCD Modes: up to UXGA panel resolutipn with frequency range from 25-MHz to 112-MHz •...

  • Page 15: Board Layout: Dimensions

    1.4 Board layout: dimensions Figure 1.1: Board layout: dimensions (component side) Chapter 1 General Information...
  • Page 16 Figure 1.2: Board layout: dimensions (solder side) PCI-6886 User’s Manual...
  • Page 17 Installation This chapter explains the setup procedures of PCI-6886 hardware, including instruc- tions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all safety precautions before you begin the installation procedure. Chapter 2 Installation...

  • Page 18: Chapter 2 Installation

    Chapter 2 Installation 2.1 Jumpers The PCI-6886 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers Label Function COM2 RS232/422/485 Selection CMOS Clear LVDS Panel Power Selection PCI Card Power Selection...

  • Page 19: Connectors

    2.2 Connectors On-board connectors link the PCI-6886 to external devices such as hard disk drives, a keyboard, or floppy drives. The table below lists the func- tion of each of the board’s connectors. Table 2.2: Connectors Label Function Front Pannel Connector Digital I/O Connector Primary IDE Connector Floppy Connector...

  • Page 20: Locating Connectors(Component Side)

    2.3 Locating Connectors(component side) Figure 2.1: Jumper&Connector Locations PCI-6886 User’s Manual...

  • Page 21: Locating Connectors(Solder Side)

    2.4 Locating Connectors(solder side) Figure 2.2: Connectors (component side) Chapter 2 Installation...

  • Page 22: Setting Jumpers

    2.5 Setting Jumpers You may configure your card to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric cir- cuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 23: Com2 Rs232/422/485 Select(Jp1)

    2.6 COM2 RS232/422/485 Select(JP1) Table 2.3: COM2 RS232/422/485 Select *1-2 RS232 RS422 RS485 * : Default setting 2.7 Clear CMOS (JP2) Warning! To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS.” Before turning on the power supply, set the jumper back to “3.0 V Battery On.”...

  • Page 24: Lvds Panel Power Select(Jp3)

    2.8 LVDS Panel Power Select(JP3) Table 2.5: LVDS Panel Power Select Function +3.3V 2.9 PCI Card Power Select(JP4) Table 2.6: PCI Card Power Select Function *1-2 +3.3V * : Default setting 2.10 Installing SODIMMs Notes The modules can only fit into a socket one way. The gold pins must point down into the SODIMM socket.

  • Page 25: Atx Power Control Connector (Cn5)

    point down into the SODIMM socket. 3. Slip the SODIMM into the socket at a 45 degree angle and care- fully fit the bottom of the card against the connectors. 4. Gently push the SODIMM into a perpendicular position until the clips on the ends of the SODIMM sockets snap into place.

  • Page 26: Printer Port Connector (Cn6)

    2.12 Printer port connector (CN6) Normally, the parallel port is used to connect the card to a printer. The PCI-6886 includes a multi-mode (ECP/EPP/SPP) parallel port accessed via CN6 and a 26-pin flat-cable connector. You will need an adapter cable if you use a traditional DB-25 connector.

  • Page 27: Ide Connector(Cn3,Cn7)

    If you are connecting a 5.25” floppy drive, line up the slot in the printed circuit board with the blocked-off part of the cable connec- tor. If you are connecting a 3.5” floppy drive, you may have trouble determin- ing which pin is number one. Look for a number printed on the circuit board indicating pin number one.

  • Page 28: Vga/Lvds Interface Connections

    2.16 VGA/LVDS interface connections The PCI-6886’s display interface can drive conventional CRT displays and is capable of driving a wide range of LVDS flat panel displays as well. The board has two display connectors: one for standard CRT VGA monitors, and one for LVDS flat panel displays. 2.16.1 CRT display connector (CN11) CN11 is a standard 15-pin connector used for conventional CRT displays.

  • Page 29: Ethernet Configuration

    use a standard USB connector. The adapter cable has a 5 x 2-pin connec- tor on one end and a USB connector on the other. The USB interfaces can be disabled in the system BIOS setup. 2.18 Ethernet configuration The PCI-6886 is equipped with a high performance 32-bit PCI-bus Ether- net interface which is fully compliant with IEEE 802.3U 10/100Mbps CSMA/CD standards.

  • Page 30: Power Led (Pin 3 & Pin 4)

    The HDD LED indicator would light when HDD works. 2.19.3 Power LED (Pin 3 & Pin 4) Pin 3 & Pin4 The Power LED indicator would light when the power is on. 2.19.4 Suspend LED(Pin 5 & Pin 6) Pin5&Pin6 The Suspend LED indicator would light when the computer is suspend.

  • Page 31: Ac'97 Interface Connector (Cn17)

    2.23 AC'97 interface Connector (CN17) PCI-6886 can support separate independent PCI functions for Audio and Modem, which is compliant to AC'97 Version 2.2 standard. The AC'97 interface is a 5 x 2 pin box header. The PCI-6886 can support Audio with the addition of optional PCM-231A-00A1. Detailed pin assignment refer to Appendix B.
  • Page 32 PCI-6886 User’s Manual...
  • Page 33 Software Configuration This chapter details the software con- figuration information. It shows you how to configure the card to match your application requirements. Award System BIOS will be covered in Chapter 4. Sections include: • Introduction • VGA display software configuration...

  • Page 34: Chapter 3 Software Configuration

    Chapter 3 Software Configuration 3.1 Introduction The system BIOS and custom drivers are located in a 512 KB, 32-pin (JEDEC spec.) Flash ROM device, designated U10. A single Flash chip holds the system BIOS, VGA BIOS, and network Boot ROM image. The display can be configured via software. This method minimizes the number of chips and eases configuration.

  • Page 35: Figure 3.1:Vga Setup Screen

    At the prompt, type AWDFLASH.EXE and press <Enter>. The VGA configuration program will then display the following: Figure 3.1: VGA setup screen At the prompt, enter the new BIN file which supports your display. When you are sure that you have entered the file name correctly press <Enter>.
  • Page 36 PCI-6886 User’s Manual...

  • Page 37: Award Bios Setup

    Chapter 4 Ducks that Need Love! Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 38: Chapter 4 Award Bios Setup

    Chapter 4 Award BIOS Setup 4.1 System test and initialization These routines test and initialize board hardware. If the routines encoun- ter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal.

  • Page 39: Award Bios Setup

    4.2 Award BIOS setup Award’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. 4.2.1 Entering setup Power on the computer and press <Del>...

  • Page 40: Standard Cmos Features Setup

    4.2.2 Standard CMOS Features setup When you choose the Standard CMOS Features option from the Initial Setup Screen menu, the screen shown below is displayed. This standard Setup Menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is high- lighted, on-line help information is displayed in the right top of the Menu screen.

  • Page 41: Advanced Bios Features Setup

    4.2.3 Advanced BIOS Features setup By choosing the Advanced BIOS Features Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Series. Figure 4.3: Advanced BIOS Features setup...

  • Page 42: Advanced Chipset Features Setup

    4.2.4 Advanced Chipset Features setup By choosing the Advanced Chipset Features option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Series. Figure 4.4: Advanced Chipset Features setup PCI-6886 User’s Manual...

  • Page 43: Integrated Peripherals

    4.2.5 Integrated Peripherals Choosing the Integrated Peripherals option from the Initial Setup Screen menu should produce the screen below. Here we see the manufacturer’s default values for the PCI-6886 Series. Figure 4.5: Integrated Peripherals...

  • Page 44: Power Management Setup

    4.2.6 Power Management Setup By choosing the Power Management Setup option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Series. Figure 4.6: Power Management Setup PCI-6886 User’s Manual...

  • Page 45: Pnp/Pci Configurations

    4.2.7 PnP/PCI Configurations By choosing the PnP/PCI Configurations option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Series. Figure 4.7: PnP/PCI Configurations...

  • Page 46: Pc Health Status

    4.2.8 PC Health Status The PC Health Status option displays information such as CPU and moth- erboard temperatures, fan speeds, and core voltage. Figure 4.8: PC Health Status PCI-6886 User’s Manual...

  • Page 47: Frequency/Voltage Control

    4.2.9 Frequency/Voltage Control By choosing the Frequency/Voltage Control option from the Initial Setup Screen menu, the screen below is displayed. This sample screen contains the manufacturer’s default values for the PCI-6886 Figure 4.9: Frequency/Voltage Control Caution Incorrect settings in Frequency/Voltage Control may damage the system CPU, video adapter, or other hardware.

  • Page 48: Load Optimized Defaults

    4.2.10 Load Optimized Defaults Load Optimized Defaults loads the default system values directly from ROM. If the stored record created by the Setup program should ever become corrupted (and therefore unusable), these defaults will load auto- matically when you turn the PCI-6886 Series system on. Figure 4.10: Load BIOS defaults screen 4.2.11 Set Password Note...

  • Page 49: Figure 4.11:Set Password

    Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,” enter the desired password and press <Enter>. At the “Confirm Password” prompt, retype the desired password, then press <Enter>. Select Save to CMOS and EXIT, type <Y>, then <Enter>. Figure 4.11: Set password To Change Password Choose the Set Password option from the CMOS Setup Utility...

  • Page 50: Save & Exit Setup

    Select Save to CMOS and EXIT, type <Y>, then <Enter>. To Disable Password Choose the Set Password option from the CMOS Setup Utility main menu and press <Enter>. When you see “Enter Password,” enter the existing password and press <Enter>. You will see “Confirm Password.”...

  • Page 51: Exit Without Saving

    If you select this option and press <Y> then <Enter>, the values entered in the setup utilities will be recorded in the chipset’s CMOS memory. The microprocessor will check this every time you turn your system on and use the settings to configure the system. This record is required for the system to operate.
  • Page 52 PCI-6886 User’s Manual...
  • Page 53 PCI SVGA Setup Introduction Installation of SVGA drivers -for Windows 2000/XP Further information...

  • Page 54: Chapter 5 Pci Svga Setup

    Chapter 5 PCI SVGA Setup 5.1 Introduction The board has an onboard interface. The specifications and features are described as follows: 5.1.1 Chipset The PCI-6886 uses a Intel 852GM + 6300ESB chipset for its graphic con- troller. It supports LVDS LCD displays, conventional CRT monitors. 5.1.2 Display memory The 852GM chip with optimized Shared Memory Architecture, supports up to 64 MB frame buffer using system memory to provide LVDS mode...

  • Page 55: Installation Of The Svga Driver

    5.2 Installation of the SVGA Driver Complete the following steps to install the SVGA driver. Follow the pro- cedures in the flow chart that apply to the operating system that you are using within your board. Notes: 1. The windows illustrations in this chapter are intended as examples only.
  • Page 56 Press the "Next" button. Press the "Next" button. PCI-6886 User’s Manual...
  • Page 57 In order to continue setup, you must accept the agreement, press the "Yes" button and wait a minute. Choose the option "Yes, I want to restart my computer now." and press the "Finish" button. Chapter 5...

  • Page 58: Further Information

    5.3 Further Information For further information about the AGP/VGA installation in your PCA- 6886, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Intel website: www.intel.com. EMAC website: www.emacinc.com PCI-6886 User’s Manual...
  • Page 59 PCI Bus Ethernet Inter- face This chapter provides information on Ethernet configuration. • Introduction • Installation of Ethernet drivers for Windows XP • Further information...

  • Page 60: Chapter 6 Pci Bus Ethernet Interface

    Chapter 6 PCI Bus Ethernet Interface 6.1 Introduction The board is equipped with a high performance 32-bit Ethernet chipset which is fully compliant with 802.3u 100BASE-T or 802.3z/ab 1000BASE-T. It is supported by major network operating systems. It is also both 100Base-T and 10Base-T compatible. The Ethernet port provides a standard RJ-45 jack.
  • Page 61 Select “ Ethernet Controller” from Device Manager. Select “Update Driver”. Chapter 6...
  • Page 62 Click the “Next” button. Click the “Next” button. PCI-6886 User’s Manual...
  • Page 63 Please choose “Continue Anyway”. Click the “Finish” button Chapter 6...
  • Page 64 PCI-6886 User’s Manual...
  • Page 65 Audio Setup • Introduction • Installation of audio driver for Win- dows XP Chapter 7...

  • Page 66: Chapter 7 Audio Setup

    Chapter 7 Audio Setup 7.1 Introduction The PCI-6886 supports AC97 audio through the optional audio module PCM-231A-00A1. Notes The audio function needs external AUDIO board e.g. PCM-231. 7.2 Driver installation 7.2.1 Before you begin Please read the instructions in this chapter carefully before you attempt installation.
  • Page 67 1. Select the path: D:\wdm_a357, then double click to run "Install Shield Wizard". 2. Press the "Next" button and wait for a moment. Chapter 7...
  • Page 68 3. Choose the option "Continue Anyway”. 4. Choose the option "Yes, I want to restart my computer now", then click "Finish" button to reboot your computer. PCI-6886 User’s Manual...
  • Page 69 Programming GPIO & Watchdog Timer The board is equipped with a watchdog timer that resets the CPU if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 70: Appendix A Programming Gpio & Watchdog Timer

    Appendix A Programming GPIO & Watchdog Timer A.1 Supported GPIO Register Bellow are detailed description of the GPIO addresses and programming sample. A.1.1 GPIO Registers CRF0 (GP10-GP17 I/O selection register. Default 0xFF) When set to a '1', respective GPIO port is programmed as an input port. When set to a '0', respective GPIO port is programmed as an output port.

  • Page 71: Gpio Example Program-1

    A.1.2 GPIO Example program-1 ------------------------------------------------ Enter the extended function mode, interruptible double-write ------------------------------------------------ MOV DX,2EH MOV AL,87H OUT DX,AL OUT DX,AL --------------------------------------------------------------- Configurate logical device 7(GP10~GP17), configuration register CRF0,CRF1,CRF2 --------------------------------------------------------------- MOV DX,2EH MOV AL,07H ; point to Logical Device Number Reg. OUT DX,AL MOV DX,2FH MOV AL,07H ;...

  • Page 72: Watchdog Programming

    OUT DX,AL MOV DX,2FH MOV AL,??H ; Put the output value into AL OUT DX,AL ------------------------------------------ Exit extended function mode | ------------------------------------------ MOV DX,2EH MOV AL,AAH OUT DX,AL A.2 Watchdog programming Watchdog: (Index Port:300H , Data Port:301) 1, Enable Watchdog Outportb (0x2e,0x87);...
  • Page 73 Outportb (0x2e,0xaa); //Exit Configuration Mode 3, Disable Watchdog Outportb (0x2e,0x87); Outportb (0x2e,0x87); //Entry Configuration Mode Outportb (0x2e,0x07); //Select Register Index 0x07 Outportb (0x2f,0x08); //Select LDN 8 Outportb (0x2e,0x30); //Select LDN 8 Register Index 0x30 Outportb (0x2f,0x00); //Disable Watchdog Timer Device Outportb (0x2e,0xaa);...
  • Page 74 PCI-6886 User’s Manual...
  • Page 75 Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • Floppy Drive Connector • Primary IDE Connector • LPT Connector • Secondary IDE(Slave) Connector • ATX Power Connector • COM3/COM4 output • USB1, 2 Connector •...

  • Page 76: Appendix B Pin Assignments

    Appendix B Pin Assignments B.1 ATX power connector (CN5) Table B.1: ATX power connector(CN5) Signal 5VSB PSON# +12V PCI-6886 User’s Manual...

  • Page 77: Floppy

    B.2 Floppy connector (CN4) Table B.2: Floppy Connector (CN4) Signal Signal RWC# Index# MOA# DSB# DSA# MOB# DIR# STEP# Track0# RDATA# HEAD# DSKCHG# *low active Appx. B...

  • Page 78: Primary Ide Connector (Cn3)

    B.3 Primary IDE Connector (CN3) Table B.3: Primary IDE connector (CN3) Signal Signal IDE RESET READY Cable Select DACK IRQ14 ATA check CS1# CS3# Active PCI-6886 User’s Manual...

  • Page 79: Secondary Ide Connector(Slave) (Cn7)

    B.4 Secondary IDE Connector(Slave) (CN7) Table B.4: Secondary IDE connector (CN7) Signal Signal IDE RESET READY Cable Select DACK IRQ14 ATA check CS1# CS3# Active Appx. B...

  • Page 80: Compactflash Connector(Cn21)

    B.5 CompactFlash connector(CN21) Table B.5: CompactFlash Connector (CN21) Signal Signal #CD1 #CE2 #VS14 #IORD #IOWR #IRQ #CSEL #VS2 RESET #WAIT #INPACK #REG BVD2 BVD1 IOCS16 #CD2 PCI-6886 User’s Manual...

  • Page 81: Lan,Rj45 Connector(Cn12)

    B.6 LAN,RJ45 connector(CN12) Table B.6: LAN,RJ45 connector(CN12) 10/100M Signal Signal 10/100/1000M MDI0- MDI2+ MDIO+ MDI2- MDI1+ MDI3+ MDI- MDI3+ B.7 USB1, 2 connector(CN10) Table B.7: USB 1, 2 connector(CN10) Signal Signal USB0- USB1- USB0+ USB1+ USB GND USB GND Appx. B...

  • Page 82: Usb 3, 4 Connector(Cn9)

    B.8 USB 3, 4 connector(CN9) Table B.8: USB 3, 4 connector(CN9) Signal Signal USB0- USB1- USB0+ USB1+ USB GND USB GND B.9 LCD INV power connector(CN20) Table B.9: LCD INV power connector (CN20) Signal +12V output Back-light enable signal output Back-light VBR signal output +5V output PCI-6886 User’s Manual...

  • Page 83: Dio Connector(Cn2)

    B.10 DIO connector(CN2) Table B.10: DIO connector(CN2) Signal Signal Appx. B...

  • Page 84: Lvds Connector(Cn15)

    B.11 LVDS connector(CN15) Table B.11: LVDS connector (CN15) Signal Signal +5V/3.3V +5V/3.3V +5V/3.3V +5V/3.3V LVDS0_N0 LVDS1_N0 LVDS0_P0 LVDS1_P0 LVDS0_N1 LVDS1_N1 LVDS0_P1 LVDS1_P1 LVDS0_N2 LVDS1_N2 LVDS0_P2 LVDS1_P2 LVDS0_C0N LVDS1_C0N LVDS0_C0P LVDS1_C0P LVDS_DDC LVDS_DDCPDATA OCLK NC/LVDS1_N3 LVDS0_N3 NC/LVDS1_P3 LVDSS0_P3 +0.3V Reference PCI-6886 User’s Manual...

  • Page 85: Lpt Connector(Cn6)

    B.12 LPT connector(CN6) Table B.12: LPT connector(CN6) Signal Signal STB# AFD# INIT# SLIN ACK# BUSY SLCT Appx. B...

  • Page 86: Com 1, 2 Connector (Cn13, Cn14)

    B.13 COM 1, 2 Connector (CN13, CN14) 9 8 7 Table B.13: COM connector (CN 13, CN14) COM1 connector (CN13) COM2 connector (CN14) Signal Signal Signal Signal SOUT SOUT DTR- N.C. TXD422+/ TXD422-/ 485+ 485- RXD422+ RXD422- PCI-6886 User’s Manual...

  • Page 87: Com 3, 4 Connector (Cn8)

    B.14 COM 3, 4 Connector (CN8) Table B.14: COM3,4 Connector(CN8) Signal Signal DCD3 DSR3 SIN3 RTS3 SOUT3 CTS3 DTR3 DCD4 DSR4 SIN4 RTS4 SOUT4 CTS4 DTR4 B.15 Audio I/F connector(CN17) Table B.15: Audio I/F connector(CN17) Signal Signal BitCLK DATA IN Sync DATA OUT ACRST...

  • Page 88: D-Sub Vga Connector(Cn11)

    B.16 D-SUB VGA connector(CN11) Table B.16: D-SUB VGA connector(CN11) Signal Signal S-DATA HSYNC VSYNC S-CLK B.17 MINI PS/2_KB/Mouse connector(CN19) Table B.17: MINI Keyboard connector(CN19) Signal KBDATA MSDATA KBCLK MSCLK PCI-6886 User’s Manual...

  • Page 89: Ext_Kb Connector(Cn18)

    B.18 EXT_KB connector(CN18) Table B.18: EXT_KB/Mouse connector(CN18) Signal KBCLK KBDATA B.19 HDD LED/Reset/Power Button(CN1) Table B.19: HDD LED/Reset/Power Button(CN1) Signal Signal HDD_LED SUSPEND 5VSB RESET PWR_Button Appx. B...

  • Page 90: Dvi Connector (Cn16)

    B.20 DVI connector (CN16) Table B.20: DVI connector(CN16) Signal Signal TDC0- TDC0+ TDCCLK- TDCCLK+ TDC1- TDC1+ MDVICLK MDVIDATA TDC2+ HOT_DETECT TDC2+ MI2CDATA MI2CCLK B.21 CPU FAN connector (FAN1) Table B.21: CPU FAN connector (FAN1) Signal +12V FAN SPEED DETECT PCI-6886 User’s Manual...

  • Page 91: Serial Ata (Sa1,Sa2)

    B.22 Serial ATA (SA1,SA2) Table B.22: Serial ATA (SA1, SA2) Signal Appx. B...
  • Page 92 PCI-6886 User’s Manual...
  • Page 93 System Assignments This appendix contains information of a detailed nature. It includes: • System I/O ports • 1st MB memory map • DMA channel assignments • Interrupt assignments Appx. C...

  • Page 94: Appendix C System Assignments

    Appendix C System Assignments C.1 System I/O Ports Table C.1: System I/O ports Addr. range (Hex) Device 00-0F Master DMA controller 20-21F Master Interrupt controller 40-5F Timer/Counter 60-6F Keyboard controller (60h) KBC Data (61h) Misc Funtions & Spkr Ctrl (64h) KBC Command/Status 70-77 RTC/COMS/NMI-Disable...

  • Page 95: 1St Mb Memory Map

    Table C.1: System I/O ports Addr. range (Hex) Device CF8-CFB PCI Configuration Address CFC-CFF PCI Configuration Data D00-FFFF -available for system use- C.2 1st MB memory map Table C.2: 1st MB memory map Addr. range (Hex) Device F0000h - FFFFFh System ROM *D0000h - EFFFFh Unused (reserved for Ethernet ROM)

  • Page 96: Interrupt Assignments

    C.4 Interrupt assignments Table C.4: Interrupt assignments Interrupt# Interrupt source IRQ 0 Interval timer IRQ 1 Keyboard IRQ 2 Interrupt from controller 2 (cascade) IRQ 3 COM2 IRQ 4 COM1 IRQ 5 COM4 IRQ 6 IRQ 7 LPT1 IRQ 8 IRQ 9 Reserved (audio) IRQ 10...
  • Page 97 Intel Speedstep Tech- nology • Introduction and Installation...

  • Page 98: Appendix D Intel Speedstep Technology

    Appendix D Intel Speedstep Technology ® ® D.1 Intel Pentium M SpeedStep instruction ® ® ® Mobile Intel Pentium M processors with Enhanced Intel SpeedStep technology let users customize high performance computing on their PC.The Enhanced Intel SpeedStep technology provides the Pentium M processor a flexible, multi-point operating mode, completely self man- aged, and with a very low CPU and memory unavailability time, which optimizes its power and performance according to demand.
  • Page 99 Appendix D...
  • Page 100 Step 3. Discover the different CPU freq. by using FrequencyDisplay util- PCI-6886 User’s Manual...
  • Page 101 The Result of Pentium M speed stepping: ® ® 1.1G---600MHz / 800MHz / 1.1GHz( Intel Pentium ® 1.6G---600MHz / 800MHz / 1.0GHz /1.2GHz / 1.4GHz / 1.6GHz( Intel ® Pentium Appendix D...
  • Page 102 PCI-6886 User’s Manual...

This manual is also suitable for:

Pci-6886fg-m0a1

Table of Contents
