PCI-7030 PCI Half-size Intel
with Dual GbE LAN/LVDS/DVI/2 SATA/6 COM
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 PCI-7030 PCI Half-sized Intel® ATOM™ N270 1.6GHz
processor-based single board Computer
• 1 PCI-7030 Startup Manual
• 1 CD with driver utility and manual (in PDF format)
• 1 Power cable
• 1 FDD cable (600 mm)
•
1 EIDE (HDD) cable
• 1 Dual COM cable 2.0mm pitch
• 1 Serial ATA HDD data cable
• 1 Serial ATA HDD power cable
• 1 Printer port cable 2.0mm pitch
• 1 Y cable for PS/2 keyboard and
PS/2 mouse
• 1 USB cable with 4 ports
• ATX feature cable
• 1 Jumper pack
• Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1: For detailed contents of PCE-7030, please refer
to information on the enclosed CD-ROM (in PDF
format). Acrobat Reader is required to view any
PDF file.
Note2:
Acrobat Reader can be downloaded at: www.
adobe.com/Products/acrobat/readstep2. html
(Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCI-7030 series Rev. A1
Part No. 2002703010
ATOM™ N270 1.6GHz FSB533MHz
®
p/n: 1700000265
p/n: 1701340603
p/n: 1701400452
p/n: 1700008762
p/n: 1700003194
p/n: 1703150102
p/n: 1700002223
p/n: 1700060202
p/n: 1700008887
p/n: 1700002343
p/n: 9689000002
1st Edition
July 2009
Specifications

Standard SBC functions

• CPU: Intel® ATOM™ N270 processor 1.6 GHz on board
• BIOS: Award® SPI 8 Mb Flash memory BIOS
• Chipset: Intel 945GSE with ICH7M
• System memory: Single Channel; One SODIMM sockets
accepts up to 2 GB DDR2 400/533 MHz SDRAM
• IDE interface: One channel, supports Ultra ATA
100/66/33 and One CF slot
• SATA interface: Supports two SATA1 HDD (150 MB/s);
• Serial ports: Two dedicated serial RS-232 ports on
board, plus four ports RS-232 or RS-422/485 w/Autoflow
control by module
• Parallel port: One EPP/ECP parallel port
• Keyboard/mouse connector: One standard PS/2 key-
board/mouse connector and one external 6-pin header.
• Watchdog timer: 1 min or 1 sec, Max 65535 min or
65535 sec intervals
• USB (2.0): 6 Universal Serial Bus ports on board for VG
sku; 5 for G2 sku.

VGA Interface

• Chipset: Intel 945GSE integrated
• Display memory: Shared with 224 MB system memory
• Video Output:
- VGA mode: Supports up to QXGA 2048 x 1536 pixels
with 32-bit color @ 75 Hz
- LVDS mode: Supports 18/36-bit up to UXGA 1600 x
1200
• DVI mode: Maximum pixel lock of 400 MHz up to 2048 x
1536 resolutions @ 75 Hz

Ethernet Interface

• Chipset: Dual G-LAN : Intel® 82574L Chipset
• Connection: Onboard RJ-45 connector (1 for VG sku; 2
for G2 sku)

Mechanical and Environmental

• Dimensions (L x W): 185 x 122 mm (7.3" x 4.8")
• Power supply voltage: +5 V, +12 V, 5 Vsb
• Power requirements:
+12 V @ 0.31 A , +5 V @ 2.19 A , +3.3 V @ 0 A ,+5 Vsb
@ 0.04 A , +2 V @ 0 A
Measuring the maximum current value with system under
maximum load (ATOM 1.6G + DDR2 533 / 2G)
• Operating temperature: 0 ~ 60° C (32 ~ 140° F) (opera-
tion humidity: 40°C @85% RH Non-Condensing)
• Weight: 0.365kg (weight of board)
(2 COMs on board,
plus 4 COMs by module)
