- Page 1 ANT-39000 QUICK START GUIDE Applicable to ANT-39000 Antrica Quick Start Guide ANT-39000 Series V230619 Page 1...
- Page 2 Contents 1 Whats in the box 2 Setting up the ANT-39000 3. Configuring the ANT-39000 3.1 Video Information 3.2 Video Encode 3.3 Network & IP Port 4. Streaming 4.1 RTSP over TCP to VLC player 4.1.1 How to configure VLC 4.2 MPEG Transport Stream to VLC...
- Page 3 Connect the input Video source using an HDMI cable Connect the 12 volt power input (or use PoE )and switch on. The ANT-39000 will take approximately 1 minutes to boot up. You will see 4 LEDs. On powering the Red power LED is ON, after boot up the Green Status LED will flash.
- Page 4 3.1 Video Information The Video Information page shows if a valid video signal is connected and gives information about the stream settings. 3.2 Video Encode:Settings Input format HDMI only for ANT-39000 Input format Detected in Auto Mode Primary Stream settings...
- Page 5 ADDRESS>:<PORT>/video1 (video only streaming of primary stream) rtsp://<IP ADDRESS>:<PORT>/video1s (video only streaming of 2nd stream) rtsp://<IP ADDRESS>:<PORT>/video1s1 (video only streaming of 3rd stream) rtsp://<IP ADDRESS>:<PORT>/video1s2 (video only streaming of 4th stream) Antrica Quick Start Guide ANT-39000 Series V230619 Page 5...
- Page 6 NOTE! In advanced settings you will find VLC has a default buffer setting of 1000mS this can be lowered to reduce latency to around 100-200mS 4.2 MPEG Transport Stream over UDP Antrica Quick Start Guide ANT-39000 Series V230619 Page 6...
- Page 7 Router in this building will need to PORT FORWARD this stream( port number chosen above) to the internal IP address of the computer. Further data on Port Forwarding and Router setup contact support@antrica.com . Multicast is not supported over the Internet.
- Page 8 5.0 Help and Further Support 5.1 ONVIF Support The ANT-39000 series supports ONVIF profile S+G and uses port 80 as standard and login user name and password (admin: 1234). Profiles are as defined in the 4 stream settings in section 3.2 of this Quick Start Guide.
