ANT-37500 Quick Start Guide
Contents
ANT-37500 Quick Start Guide .......................................................................................... 1
Document info ............................................................................................................... 1
1.
Setup out of Box ............................................................................................... 2
2.
Login ............................................................................................................... 4
3.
Network ........................................................................................................... 5
4.
Add camera ...................................................................................................... 6
4.1.
Add RTSP Camera .......................................................................................... 6
4.2.
Add ONVIF camera ......................................................................................... 8
4.2.1.
Add ONVIF camera manually ..................................................................... 8
4.2.2.
Add ONVIF camera by scanning................................................................ 10
5.
Setup camera's in grid view .............................................................................. 13
5.1.
Set up Grid view - example 2x2 ..................................................................... 14
5.1.1.
Add camera to view ................................................................................ 14
5.1.1.1. Add camera to view by adding ............................................................... 14
5.1.1.2. Add camera to view by dragging ............................................................ 15
5.2.
Organising cameras in view sequence ............................................................. 16
6.
Monitor view setup .......................................................................................... 18
Appendix 1 - TAG / VIEWS name association .................................................................. 19
Shown in Table 1 is the nominal maximum video size for each gird mode. Larger values could be
used, but there then may be decoding issues.
Table 1 : Nominal maximum resolutions per viewing mode
Viewing mode
maximum resolution and frame rate
full screen or 1x1
3840 x2160 P30
2x2
1920 x 1080 P30
3x3
1280 x 720 P30
4x4
640 x 480 P30
Document info
Version
date
0.1
26-Feb-25
For infomation use only
author
Comments
David M
Initial draft with 3.5.18
For further help and advice please contact Antrica on:
Email:
support@antrica.com
Phone: +44 1628 626098, during UK office hours, and
ask for technical support
Page 1 of 22
ANT-37500_QuickStartGuide_v0.1.docx
last saved: 26-Feb-25
Last printed: 26-Feb-25 15:04:00
15:04:00
Advertisement
Table of Contents
Related Manuals for Antrica ANT-37500
Summary of Contents for Antrica ANT-37500
-
Page 1: Table Of Contents
1x1 3840 x2160 P30 1920 x 1080 P30 1280 x 720 P30 640 x 480 P30 For further help and advice please contact Antrica on: Email: support@antrica.com Phone: +44 1628 626098, during UK office hours, and Document info... -
Page 2: Setup Out Of Box
Figure 2 : ANT-375000 with default screen at start up The IP address, and other information, for the ANT-37500 is displayed at the bottom of the screen for 10 ~ 15 seconds. This information is shown in Figure 3. This information can be shown at any time by pressing the “menu”... - Page 3 A. The current time within the ANT-37500D – 12:41:51 B. The version of firmware installed – 3.5.18 C. The MAC address of the ANT-37500D – 8c:1f:64:a1:b0:06 D. The IP address currently be used by the ANT-37500 – 192.168.0.222 For infomation use only Page 3 of 22...
-
Page 4: Login
Password - admin Figure 4 : ANT-37500 login page Once logged in the “HOME” webpage tab will be shown, as seen in Figure 5. Figure 5 : ANT-37500 HOME webpage tab For infomation use only Page 4 of 22 last saved: 26-Feb-25... -
Page 5: Network
ANT-37500 be used. To change the network settings, change the parameters as required and then click “APPLY”. A pop-up will appear, as shown Figure 7, and the ANT-37500 will restart with the new network settings. The NTP does not need to be used, but in some decoding configurations the source / camera and the decoder / ANT-37500 need to have the same internal time. -
Page 6: Add Camera
ANT-37500_QuickStartGuide_v0.1.docx 4. Add camera Go to CAMERAS tab, as shown in Figure 8. Figure 8 : ANT-37500 CAMERAS webpage page 4.1. Add RTSP Camera To manually add a camera using it’s RTSP stream, put the complete URL in the “url” field above. - Page 7 ANT-37500_QuickStartGuide_v0.1.docx Figure 9 : ANT-37500 CAMERAS webpage page RTSP camera added The LATENCY is 0 by default. This is actually using a 200ms buffer. If a value of 100 is used then new buffer size will 100ms. If a value of 400ms is used, the buffer is 400ms. If the buffer is too small then you will get unstable or no decoding.
-
Page 8: Add Onvif Camera
ANT-37500_QuickStartGuide_v0.1.docx Figure 11 : ANT-37500 CAMERAS webpage “SAVE ALL” 4.2. Add ONVIF camera 4.2.1. Add ONVIF camera manually Use the URL ONVIF://<IP address>, i.e. ONVIF://192.168.0.167. In the example in Figure 12 the ONVIF port is not the default 80 but 7070 and this indicated by adding :7070 to the end on the IP address. - Page 9 In the example shown there are 2 profiles per resolution, where one is unicast and the other is multicast. If the above is not followed then the ANT-37500 decoder may not correctly display the video for that particular resolution.
-
Page 10: Add Onvif Camera By Scanning
ANT-37500_QuickStartGuide_v0.1.docx The “SAVE ALL” button will be in a darker colour indicating that the setting needs to be changed. Once used it will change to a lighter / greyed-out colour, see for examples Figure 17 and Figure Figure 17 : CAMERAS – SAVE ALL requires clicking Figure 18 : CAMERAS –... - Page 11 In the example shown there are 4 profiles per resolution, where there are 2 with audio, and 2 without audio, and either unicast or multicast options. If the above is not followed then the ANT-37500 decoder may not correctly display the video for that particular resolution.
- Page 12 ANT-37500_QuickStartGuide_v0.1.docx Figure 22 : CAMERAS – select required profiles For infomation use only Page 12 of 22 last saved: 26-Feb-25 15:04:00 Last printed: 26-Feb-25 15:04:00...
-
Page 13: Setup Camera's In Grid View
Position 1 thru’ 16 Position 1 thru’ 4 Figure 24 shows only 1 camera in the CAMERAS list. In all cases, when finished click SAVE. Figure 24 : ANT-37500 VIEWS webpage For infomation use only Page 13 of 22 last saved: 26-Feb-25... -
Page 14: Set Up Grid View - Example 2X2
Set up Grid view – example 2x2 Selected the “grid_2x2” option, as shown in Figure 25. Figure 25 : ANT-37500 VIEWS webpage – 2x2 grid view setup 5.1.1. Add camera to view The C1 camera can be either “added” or “dragged” to the required view:. The VIEWS positions are view:1 is top left, view:2 is top right, view:3 is bottom left and view:4 is bottom right. -
Page 15: Add Camera To View By Dragging
Figure 27 : ANT-37500 VIEWS webpage – C1 in view:3 5.1.1.2. Add camera to view by dragging Figure 28 : ANT-37500 VIEWS webpage – drag C1 into view:2 Grab / click the 3 horizontal lines with the mouse’s left button held down and drag the outline to the desired view. -
Page 16: Organising Cameras In View Sequence
ANT-37500_QuickStartGuide_v0.1.docx 5.2. Organising cameras in view sequence In this example, 3 cameras have been added to Grid View 2x2 in view 1 position, as shown in Figure 30. The time delay between each camera being displayed is in the PERIOD field – 20 seconds in this example. - Page 17 ANT-37500_QuickStartGuide_v0.1.docx Once the cameras have added to a view, they can be re-sequenced by clicking on the 3 horizontal lines “ ” and dragging the camera to its required position, as shown in Figure 34. When the HOME page is viewed the cameras are now in the same order as shown in Figure 34, which is different from that shown in Figure 31.
-
Page 18: Monitor View Setup
ANT-37500_QuickStartGuide_v0.1.docx 6. Monitor view setup As shown in Figure 36, the set-up is that shown in Figure 29. The current grid view can be changed from the “Grid Mode” dropdown The power on / start-up grid mode can be set in the “Default Grid Mode”. The preview can be started / stopped by pressing the START / STOP button. -
Page 19: Appendix 1 - Tag / Views Name Association
ANT-37500_QuickStartGuide_v0.1.docx Appendix 1 – TAG / VIEWS name association The example below, the explanation about why the TAG needs to be set before the grid mode is setup. Figure 37, there are 5 cameras shown, the names seen are the TAG names. In Figure 38 shows the VIEW tab where the 2x2 Grid is setup with 2 cameras in view:1 and 1 camera in view:2, view:3 and view:4. - Page 20 ANT-37500_QuickStartGuide_v0.1.docx Figure 38 : Setup Grid mode 2x2 with 5 cameras Figure 39 : Display 2x2 Grid mode For infomation use only Page 20 of 22 last saved: 26-Feb-25 15:04:00 Last printed: 26-Feb-25 15:04:00...
- Page 21 ANT-37500_QuickStartGuide_v0.1.docx Figure 40 : Change TAG Figure 41 : Camera with changed TAG is not in shown or display grid mode list Figure 42 : Setup grid mode shows new TAG name in list of cameras For infomation use only Page 21 of 22 last saved: 26-Feb-25 15:04:00...
- Page 22 ANT-37500_QuickStartGuide_v0.1.docx Figure 43 : Setup grid does NOT show new TAG in view:1 For infomation use only Page 22 of 22 last saved: 26-Feb-25 15:04:00 Last printed: 26-Feb-25 15:04:00...
