2.1 Hardware Installation
Step One: Place Acer WLAN 11b Broadband Router to the best optimum transmission
The best transmission location for Acer WLAN 11b Broadband Router is usually at
the geographic center of your wireless network, with line of sign to all of your
Step Two: Connect Acer WLAN 11b Broadband Router to your wired network.
Connect the Ethernet WAN interface of Acer WLAN 11b Broadband Router by
category 5 Ethernet cable to your switch/ hub/ xDSL modem or cable modem. A
straight-through Ethernet cable with appropriate cable length is needed.
Step Three: Supply DC power to Acer WLAN 11b Broadband Router.
Use only the AC/DC power adapter supplied with Acer WLAN 11b Broadband
Router; it may occur damage by using a different type of power adapter.
The hardware installation finished.
2.2 Software Installation
There are no software drivers, patches or utilities installation needed, but only the
configuration setting. Please refer to chapter 3 for software configuration.
