Motion Computing C5v User Manual page 10

Back
Camera light
Speaker
Camera lens
Battery
Battery latch
Hot-swap logo
Pen tether
Pen holder
Fan cover
Camera (optional) lens
Camera (optional) light
Speaker
Battery
Battery latch
Hot-swap logo
Docking guide
Smart card reader (optional)
4 Chapter 1
Pen tether Pen holder
0560 0560
Docking guide
Attach the pen tether.
Store the pen when not in use (page 10).
Protects the fan assembly.
Capture images to the hard disk drive (page 12).
Provides light for the documentation camera (page 12).
Listen to audio (page 15).
Powers the system when it is not plugged in or docked (page 17).
Note: The Microsoft
under the battery.
Opens the battery compartment's door.
Indicates that you can hot swap the battery (page 34).
Aligns the unit with the Docking Station.
Reads and writes information on a smart card (page 14).
Getting Started
Fan cover
Smart card reader
® ®
Windows Certificate of Authenticity is located
