- Page 1 Kramer Electronics, Ltd. Preliminary USER MANUAL Model: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter...
-
Page 2: Table Of Contents
Table 1: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter Features Table 2: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter (Underside) Features Table 3: CAT 5 PINOUT Table 4: Technical Specifications of the VP-300THD (with 30m CAT 5 cable) ... -
Page 3: Introduction
GROUP 7: Scan C onverters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products 2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com 3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... -
Page 4: Quick Start
Connect the input Connect the input Connect the outputs Connect the outputs Connect the CAT 5 cable between the Connect the CAT 5 cable between the transmitter (VP-300THD) and the transmitter (VP-300THD) and the receiver (TP-120) receiver (TP-120) Display VP-300THD... -
Page 5: Overview
Overview Overview The VP-300THD is a high-performance distribution amplifier for computer graphics video signals with resolutions ranging from VGA through UXGA and higher as well as HDTV. It takes one input, provides correct buffering and isolation, and distributes the signal to two computer graphics video or HDTV outputs and one twisted pair output. -
Page 6: About The Power Connect Feature
We recommend that you use Shielded Twisted Pair (STP) cable. There are different levels of STP cable available, and we advise you to use the best quality STP cable that you can afford. Our non-skew-free cable, Kramer BC-STP is intended for analog signals where skewing is not an issue. For cases where there is skewing, our UTP skew-free cable, Kramer BC-XTP, may be used. -
Page 7: Your Vp-300Thd 1:2 Xga/Hd Da/Cat 5 Transmitter
Your VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter Figure 1 Table 1 define the VP-300THD: Figure 1: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter Table 1: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter Features Feature Function OUTPUT 1 15-pin HD Connect to the XGA acceptor 1... -
Page 8: Connecting The Vp-300Thd
; to the left to set to OFF Connecting the VP-300THD You can use the VP-300THD and, for example, the TP-120 to configure an XGA/HD DA/CAT 5 Transmitter and Receiver system. To connect the VP-300THD with the TP-120, as the example in... -
Page 9: Figure 3: Connecting The Vp-300Thd
2. On the TP-120 XGA Line Receiver, connect the XGA OUT 15-pin HD connector to the XGA / HD acceptor (for example, a display). 3. Connect the LINE OUT RJ-45 connector on the VP-300THD to the LINE IN RJ-45 connector on the TP-120, via UTP cabling (with a range of more than 300ft (more than 100 meters)), see section 3.2. -
Page 10: Wiring The Cat 5 Line In / Line Out Rj-45 Connectors
7 and 8 Technical Specifications This section includes the technical specifications of the VP-300THD. Table 4: Technical Specifications of the VP-300THD (with 30m CAT 5 cable) INPUT: 1 XGA on an 15-pin HD connector OUTPUTS: 2 XGA on 15-pin HD connectors; 1 RJ-45 connector MAX. - Page 11 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 12 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
