  • Page 1 RLM H5 Owners manual R9010300 R5976817/03 02/06/2006...
  • Page 2 Barco nv Events Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70 Fax: +32 56.36.88.24 E-mail: sales.events@barco.com Visit us at the web: www.barco.com Printed in Belgium...
  • Page 3 The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of complaint, Barco can repair the fault or provide a replacement at its own discretion within an appropriate period.

  • Page 5: Table Of Contents

    The Video Selector ........................54 R5976817 RLM H5 02/06/2006...
  • Page 6 13.2 TextBox ..........................119 R5976817 RLM H5 02/06/2006...
  • Page 7 Index........................157 R5976817 RLM H5 02/06/2006...
  • Page 8 Table of contents R5976817 RLM H5 02/06/2006...

  • Page 9: Packaging And Dimensions

    ANSI 73.11 American power plug to connect the power cord to the wall outlet. Content • 1 RLM H5 projector (weight ± 30 kg or 67 lbs) • 1 remote control unit RCU + 2 batteries. • 2 power cables with outlet plug type CEE7 and ANSI 73.11.
  • Page 10 Projector packaging Save the original shipping carton and packing material, they will be necessary if you ever have to ship your projector. For maximum protection, repack your projector as it was originally packed at the factory. R5976817 RLM H5 02/06/2006...

  • Page 11: Dimensions

    1. Packaging and Dimensions Dimensions Side view Image 1-3 Side view Front view [27.76] 51.9 [2.04] Image 1-4 Front view R5976817 RLM H5 02/06/2006...

  • Page 12: Bottom View

    1. Packaging and Dimensions Bottom view [6.69] [6.69] [2.36] 76.8 ° 27.2 [1.07] [4.72] [2.36] [4.72] [7.87] 354.5 [13.96] Image 1-5 Bottom view R5976817 RLM H5 02/06/2006...

  • Page 13: Top View

    1. Packaging and Dimensions Top view 122.5 122.5 [18.11] [4.82] [4.82] 82.5 82.5 [3.25] [21.26] [3.25] [27.76] Image 1-6 Top view R5976817 RLM H5 02/06/2006...
  • Page 14 1. Packaging and Dimensions R5976817 RLM H5 02/06/2006...

  • Page 15: Installation Guidelines

    Only ever use the manufacturer’s recommended cleaning kit which has been specifically designed for cleaning optical parts, never use industrial strength cleaners on the projector’s optics as these will degrade optical coatings and damage sensitive optoelectronics R5976817 RLM H5 02/06/2006...

  • Page 16: Projector Configuration

    Positioning the projector The projector should be installed perpendicular with the screen on a distance PD and water leveled in both directions. The mounting positions in the following images are shown for a nominal lens position. R5976817 RLM H5 02/06/2006...
  • Page 17 2. Installation Guidelines Image 2-1 Front-Ceiling configuration Side view Top view Back view PD Distance projector - screen R5976817 RLM H5 02/06/2006...

  • Page 18: Lenses

    Cleaning the lens 2.3.1 Lenses Available lenses RLD lenses (standard lenses): Lenses Order number RLD (0.8) R9832640 RLD (1.5 - 1.8 : 1) R9832642 RLD (1.8 - 2.25 : 1) R9832643 RLD (2.25 - 3.0 : 1) R9832644 R5976817 RLM H5 02/06/2006...

  • Page 19: Lens Formulas

    PD = 2.02 x SW - 4.33 TLD HB (2 - Wide PD = 2.02 x SW - 0.14 PD = 2.02 x SW - 5.51 2.8) Tele PD = 2.86 x SW - 0.21 PD = 2.86 x SW - 8.27 R5976817 RLM H5 02/06/2006...

  • Page 20: Lens Installation

    3. Do not leave cleaning cloth in either an open room or lab coat pocket, as doing so can contaminate the cloth. 4. If smears occur when cleaning lenses, replace the cloth. Smears are the first indication of a dirty cloth. R5976817 RLM H5 02/06/2006...

  • Page 21: Battery Insertion In The Remote Control

    5. Insert the lower tab of the battery cover in the gap at the bottom of the remote control, and press the cover until it clicks in place (image 2-5). Image 2-5 Battery cover removal Image 2-4 Battery cover unlock Image 2-6 Battery removal R5976817 RLM H5 02/06/2006...

  • Page 22: Stacking Projectors

    Warning: Be sure the safe working loud of the used security cables and connectors are enough to support one projector. Refer to the supplier of the security cable for safety details. Image 2-7 Stacking two projectors R5976817 RLM H5 02/06/2006...

  • Page 23: Rigging Points And Accessories

    2. Slide the bolt into the groove until the exact position is reached (2). 3. Slide a washer on the bolt (3). 4. Secure with a first nut (4). 5. Turn a second nut on the bolt (5). R5976817 RLM H5 02/06/2006...
  • Page 24 7. Turn now the connecting-piece into the direction of the lens and secure this position by turning up the second nut. (image 2-11) 8. Turn the clamp on the movable connecting-piece. Image 2-10 Mounting the clamps fixation Image 2-11 Mounting the rigging clamp R5976817 RLM H5 02/06/2006...

  • Page 25: Connections

    Image 3-1 Power connection Power input Power cord clamp ON/OFF switch Fuses For continued protection against fire hazard : • refer replacement to qualified service personnel • ask to replace with the same type of fuse. R5976817 RLM H5 02/06/2006...

  • Page 26: Input Source Connections

    • 5–cable input component video (PR/Y/PB) RGBS • composite video • S-Video • Digital Visual Input (DVI) • Computer (analog RGB) • Serial Digital Input or High Definition Serial Digital Input with loop through connection R5976817 RLM H5 02/06/2006...

  • Page 27: 5-Cable Input

    L3 Layer 3 = (HD)SDI in and out + RS232OUT + Power wireless receiver L4 Layer 4 = Two way hardwired remote + Ethernet 5-Cable input Input specifications The 5-cable input section is made of 5 BNC input terminals. 0.7 Vpp ± 3dB 75 Ω terminated R5976817 RLM H5 02/06/2006...
  • Page 28 How to select a source on the 5 cable input ? 1. Press 1 on the RCU Note: Another way for selecting this input is via Source on the local keypad or via the Menu 1. data or video R5976817 RLM H5 02/06/2006...

  • Page 29: Composite Video Input

    Note: Another way for selecting this input is via Source on the local keypad or via the Menu. The projector allows the input of more composite video signals (up to 7 composite video signals) when using the 5 cable input in extended configuration. Press 3 to browse through the possible video sources. R5976817 RLM H5 02/06/2006...

  • Page 30: S-Video Input

    4 : chrominance signal (C) 300mVpp pin 4 : video C signal Chrominance The color component of a video signal that includes information about tint and saturation. Luminance The component of a video signal that includes information about its brightness. R5976817 RLM H5 02/06/2006...

  • Page 31: Digital Visual Interface (Dvi) Input

    This standard uses TMDS (Transition Minimized Differential Signal) from Silicon Image and DDC (Display Data Channel) from VESA (Video Electronics Standards Association). DVI can be single or dual link. Input specifications Single link DVI Differential input voltage: 200 mV - 800 mV R5976817 RLM H5 02/06/2006...
  • Page 32 TMDS DATA3- Pin 24 TMDS Clock- How to select the DVI Input ? 1. Press 5 on the RCU Note: Another way for selecting this input is via Source on the local keypad or via the Menu. R5976817 RLM H5 02/06/2006...

  • Page 33: Computer Input (Rgb Analog)

    How to select a computer input ? 1. Press 2 on the RCU Note: Another way for selecting this input is via Source on the local keypad or via the Menu. SDI or HDSDI input Serial Digital Interface R5976817 RLM H5 02/06/2006...

  • Page 34: Communication Connection

    RS232 IN connection • Wireless receiver 3.9.1 RS232 IN connection What can be connected to the RS232/422 IN connection ? The RS232 IN connection allows the projector to communicate with a computer e.g. IBM PC or Apple Macintosh. R5976817 RLM H5 02/06/2006...

  • Page 35: Wireless Receiver

    The optional wireless receiver for the optional rugged remote control can be connected to the Power wireless receiver output and to the RS232/422 IN. With these tools, it is possible to control the projector from a distance without using cables. R5976817 RLM H5 02/06/2006...

  • Page 36: Extended Configuration

    Beside the standard RGB, composite & sync signals, the extended capabilities of the 5-cable inputs make treatment of additional signals possible: • a composite video signal may be connected to 4 of the 5 BNC’s (beside the standard video BNC input) • a S-Video signal can be connected R5976817 RLM H5 02/06/2006...

  • Page 37: S-Video Extended Configuration

    2 composite video signal may be connected. Inputs Signals S-Video Composite Video Video Composite Video Video Table 3-5 Extended configuration of the S-Video input: the first column gives the possible signals, and the first row the S-Video inputs pins. R5976817 RLM H5 02/06/2006...

  • Page 38: Summarizing

    S-Video 3 : via the 1st and the 3rd BNC Key 4 on the RCU allows to browse through the active S-Video inputs, each hit moves to the next active video input. The first hit on key 4 selects the last selected video input. R5976817 RLM H5 02/06/2006...

  • Page 39: Getting Started

    • Projector address • Controlling the projector • Quick lens adjustment • Digital Zoom • Quick Picture in Picture selection Terminology overview Overview The following table gives an overview of the different functionalities of the keys. R5976817 RLM H5 02/06/2006...
  • Page 40 AUTOIMAGE Auto image, to center the image on the active DMD surface. Digit buttons direct input selection. SOURCE button this button allows to switch through the active (scanned) inputs R5976817 RLM H5 02/06/2006...

  • Page 41: Switching On

    Note: If Identification screen is on, the Identification screen will be displayed during start up. AUTION Pushing the standby key too long, might cause the projector to shut down right after an image is displayed. R5976817 RLM H5 02/06/2006...

  • Page 42: Lamp Runtime

    ARNING Using a lamp for more than x hours is dangerous as the lamp could explode. The lamp runtime reset as well as the lamp replacement can only be done by a Barco authorized technician. Switching to standby How to switch to standby? 1.

  • Page 43: Switching Off

    The operating distance may be up to 15 m (50ft). The remote control unit will not function properly if strong light strikes the sensor window or if there are obstacles between the remote control and the IR sensor. R5976817 RLM H5 02/06/2006...

  • Page 44: Hardwired Remote Input

    1. When using the wireless remote control, make sure you are within the effective operating distance (30m, 100ft in a straight line). The remote control unit will no function properly if strong light strikes the sensor window or if there are obstacles between the remote control unit and the projector IR sensor. (image 4-7) R5976817 RLM H5 02/06/2006...

  • Page 45: Projector Address

    2. Plug the other end in the XLR connector on the projector. Image 4-8 Two way hard-wired remote Projector address Overview • Address setting • Displaying and Programming addresses into the RCU 4.8.1 Address setting Projector address Address installed in the projector to be individually controlled. R5976817 RLM H5 02/06/2006...

  • Page 46: Displaying And Programming Addresses Into The Rcu

    Finally LED3 starts blinking for the number of units. If the blinking is done, the original status of the LEDs restored. Controlling the projector Input Selection Key in the corresponding slot number with the digit keys on the RCU. The selected source will be displayed. R5976817 RLM H5 02/06/2006...

  • Page 47: Picture Controls

    Use the + button for a higher gamma Use the - button for a lower gamma Freeze Press Freeze to freeze the displayed image. The Pause Key When the Pause key is pressed, the image projection is stopped, the mechanical shutter is closed. R5976817 RLM H5 02/06/2006...

  • Page 48: Quick Lens Adjustment

    Note: For the alignment, a lens adjustment test pattern can be activated: toggle button (C) to activate or deactivate the lens adjustment test pattern (3). 5. Press the corresponding arrows (A1) or (A2) on the adjust button, as indicated in front of the menu items, for alignment. R5976817 RLM H5 02/06/2006...

  • Page 49: Direct Lens Adjustment (Rcu)

    4.11 Digital Zoom What can be done ? The Digital Zoom key on the RCU allows to zoom in or out on one particular part of the image. Digital zoom cannot be performed on a logo. R5976817 RLM H5 02/06/2006...

  • Page 50: Quick Picture In Picture Selection

    The number of the layout which has to be entered is the same as the number between the brackets in the menubar → Tools → PiP select. To go back to full screen, enter the source number of the source which must be displayed full screen. R5976817 RLM H5 02/06/2006...

  • Page 51: Getting Used With The Menu Structure

    How to start up the menus PC like menu structure The RLM H5 has a build in “PC like” menu bar which allows easy access to different parameters for setting up the projector. How to activate 1. Press MENU on the RCU.

  • Page 52: Using The Dialog Boxes

    2. Press ← or → to select the digit to be changed. 3. Press ↓ or ↑ to increase or decrease the value. To confirm the changes always press ENTER. Use ↓ or ↑ to browse between the different fields. R5976817 RLM H5 02/06/2006...

  • Page 53: Using The Menus Via The Built-In Lcd Panel

    When the items are listed with 3 points or an arrow, the dialog box content of that item will be displayed on the display when ENTER is pressed. The ↓ or ↑ can be used to scroll through the content. To return one step, press EXIT. To jump out of the menu structure, press MENU on the RCU. R5976817 RLM H5 02/06/2006...
  • Page 54 5. Getting used with the menu structure R5976817 RLM H5 02/06/2006...

  • Page 55: Source Selection

    The Source selection menu allows to select one of the different sources. Another method to select an input source is via the remote control using the numeric keys or by using the local keypad. How to select a source ? 1. Press MENU to activate the menu bar. 2. Press ↓ to pull down the Source Selection menu. R5976817 RLM H5 02/06/2006...

  • Page 56: Selecting A Data Source On The 5-Cable Input

    When RGB video signal with Sync on green or sync on H is connected on the BNC’s. This signal is routed to the video circuit and is projected in a Video Window. Image 6-2 When selecting “1” with the remote control, the predefined source type will be displayed. R5976817 RLM H5 02/06/2006...

  • Page 57: Composite Video

    When the extended mode is not switched on, the on screen menu will have another layout with less selection possibilities. How to select one of the 3 S-Video inputs ? 1. Press MENU to activate the menu bar. R5976817 RLM H5 02/06/2006...

  • Page 58: The Video Selector

    A message will be displayed and followed by a graphical user interface. 4. Use the arrow keys to select the Extended check box. 5. Press ENTER to disable or enable the extended mode. Check Extended to switch to extended mode. Uncheck Extended to switch to standard mode. R5976817 RLM H5 02/06/2006...
  • Page 59 D: connector enabled active & selected • E: connector enabled & active & focused (browser positioned on connector) A source can also be selected via the dedicated key 9 on the RCU. Key 9 allows to browse through the active inputs. R5976817 RLM H5 02/06/2006...
  • Page 60 6. Source selection R5976817 RLM H5 02/06/2006...

  • Page 61: General Menu

    To restart the image : press PAUSE. Freeze Freezing the image With the Freeze function, the image can be frozen. To restart the image, reuse the Freeze function or press the FREEZE button on the remote control. R5976817 RLM H5 02/06/2006...

  • Page 62: Standby Timer

    8. Use ↑ or ↓ to browse to the input field. 9. Use ← or → , the numeric keys on the remote or the keypad to change the countdown setting. 10.Press MENU or BACK to exit or to go back to the previous menu. R5976817 RLM H5 02/06/2006...

  • Page 63: Identification

    4. Use ↑ or ↓ to select Identification. (image 7-6) 5. Press ENTER to activate the function. The Identification screen will be displayed. (image 7-7) 6. Press MENU or BACK to exit or to go back to the previous menu Image 7-6 R5976817 RLM H5 02/06/2006...
  • Page 64 7. General Menu Image 7-7 R5976817 RLM H5 02/06/2006...

  • Page 65: Image Menu

    Image menu overview • Settings • Aspect ratio • Show native resolution • Keystone correction • Color Temperature • Color space • Filmmode detection • Blanking • Input Balance • AGC on Video • Manual Gain Control R5976817 RLM H5 02/06/2006...

  • Page 66: Image Menu Overview

    Projector white Computer Video Film Broadcast Custom Preset... Custom... • Color space ANSI Projector Custom Preset... Custom... • Film mode detection • Blanking • Input Balance Black.. White... Preset • AGC on Video • Manual Gain Control... R5976817 RLM H5 02/06/2006...

  • Page 67: Settings

    3. Press ↓ to pull down the Image menu. 4. Use ↑ or ↓ to select settings. 5. Press → to pull down the menu. 6. Use ↑ or ↓ to select Contrast. 7. Press ENTER. A slider box appears. R5976817 RLM H5 02/06/2006...

  • Page 68: Brightness

    A slider box appears. 8. Use ← or → to change the brightness. The higher the value, the higher the brightness. click in the input box and enter the desired value with the numeric keys. Image 8-4 R5976817 RLM H5 02/06/2006...

  • Page 69: Color

    7. Press ENTER . A slider box appears. 8. Use ← or → to change the tint. The higher the value, the higher the tint. click in the input box and enter the desired value with the numeric keys. R5976817 RLM H5 02/06/2006...

  • Page 70: Sharpness

    A slider box appears. 8. Use ← or → to change the sharpness. The higher the value, the higher the sharpness. click in the input box and enter the desired value with the numeric keys. Image 8-7 R5976817 RLM H5 02/06/2006...

  • Page 71: Gamma

    When displaying computer patterns or graphics (RGB or YUV signals) which are very detailed (tilting, vertical stripes, etc. ), jitter in picture (mis-sampling) may occur, causing horizontal stripes in portions of the screen. When this jitter occurs, adjust ’Phase’ for optimum image. Image 8-9 Jittering on image R5976817 RLM H5 02/06/2006...

  • Page 72: Noise Reduction

    A slider box appears 8. Use ← or → to change the noise level. The higher the value, the higher the noise reduction. click in the input box and enter the desired value with the numeric keys. R5976817 RLM H5 02/06/2006...

  • Page 73: Aspect Ratio

    4:3. In all other cases the image is transformed. The second column shows the aspect ratios for a standard television signal with 16:9 image information. The only correct aspect ratio is “Letterbox”. In all other cases the image is transformed. R5976817 RLM H5 02/06/2006...
  • Page 74 2. Press → to select Image. 3. Press ↓ to pull down the Image menu. 4. Use ↑ or ↓ to select Aspect ratio. 5. Press ↓ to select the desired aspect ratio. 6. Press ENTER to confirm. R5976817 RLM H5 02/06/2006...

  • Page 75: Show Native Resolution

    8. Use ↑ or ↓ to adjust until the desired aspect ratio is obtained. press ENTER and enter the desired value with the digit keys. Image 8-14 Show native resolution Show native resolution overrules the Full Screen Representation function in Display Setup. R5976817 RLM H5 02/06/2006...
  • Page 76 3. Press ↓ to pull down the Image menu. 4. Use ↑ or ↓ to select Show native resolution. (image 8-16) 5. Press → to pull down the menu. 6. Use ↓ or ↑ to select On. 7. Press ENTER . R5976817 RLM H5 02/06/2006...

  • Page 77: Keystone Correction

    5. Press ENTER to confirm. A slider box is displayed . (image 8-19) 6. Use ← or → to adjust the keystone. enter the desired value with the numeric keys. The top and bottom adjustments affect the image differently. R5976817 RLM H5 02/06/2006...

  • Page 78: Color Temperature

    1. Press MENU to activate the menu bar. 2. Press → to select the Image item. (image 8-20) 3. Press ↓ to pull down the Image menu. 4. Use ↑ or ↓ to select Color temperature. R5976817 RLM H5 02/06/2006...
  • Page 79 Adjust first x and then y. Use Color button to toggle between x and y. (image 8-23) The color temperature value will be stored for later use. Image 8-21 Change between x and y with <COLOR> Image 8-23 1000 Image 8-22 R5976817 RLM H5 02/06/2006...

  • Page 80: Color Space

    The color space (gamut), the collection of colors which can be reproduced by the projector, can be adjusted to 4 predefined stored values (one projector specific, 2 international standards and one custom preset). A temporary custom adjustment is possible. The R5976817 RLM H5 02/06/2006...
  • Page 81 3. Press ↓ to pull down the Image menu. 4. Use ↑ or ↓ to select Color space. 5. Press → to pull down the menu. 6. Use ↓ or ↑ to select the Custom. 7. Press ENTER. R5976817 RLM H5 02/06/2006...
  • Page 82 Adjust first Red x to the desired value. Use COLOR to switch to the next adjustment. The adjustment order is Red x → Red y → Green x → Green y → Blue x → Blue y. When another color space is selected, the current values will be lost. R5976817 RLM H5 02/06/2006...

  • Page 83: Filmmode Detection

    Undesirable elements or defects in a video picture. These may occur naturally in the video process and must be eliminated in order to achieve a high-quality picture. Most common in analog are cross color and cross luminance. Most common in digital are macroblocks, which resemble pixelation of the video image. R5976817 RLM H5 02/06/2006...

  • Page 84: Blanking

    Blanking adjustments affect only the edges of the projected image and are used to frame the projected image on the screen and to hide or black out unwanted information (or noise). A ’0’ indicates no blanking. Which blanking adjustments are available ? • top blanking • bottom blanking • right blanking • left blanking R5976817 RLM H5 02/06/2006...

  • Page 85: Adjusting The Blanking

    ↑ or ↓ keys to select Top, Bottom, Left or Right blanking and press ENTER to change the value indication to a input field and enter a new value with the keyboard. Press ENTER to accept this value. (image 8-36) R5976817 RLM H5 02/06/2006...

  • Page 86: Input Balance

    Another value that is subject to alteration is the amplitude of the signal, resulting in an altered “Gain” of the signal (“white level” or contrast). The alterations of the three color signals will happen independently i.e. the colors will end to be unbalanced, image 8-38 R5976817 RLM H5 02/06/2006...

  • Page 87: Black Level

    These two references also set the range in which the ADC will work for that particular source (this explains also why each input balance setting is linked to a particular source and thus saved in the image file). R5976817 RLM H5 02/06/2006...

  • Page 88: Adjusting The Input Balance

    50% transition due to the contribution of these two other colors signals. 9. Adjust the Green black level until bright spots appear on the screen. 10.Adjust the Blue black level until bright spots appear on the screen. R5976817 RLM H5 02/06/2006...
  • Page 89 11. Adjust the Green white level (gain) until bright spots appear on the screen 12.Adjust the Blue white level (gain) until bright spots appear on the screen 13.Adjust the Red white level (gain) until bright spots appear on the screen The projected image should now be noisy neutral grey. R5976817 RLM H5 02/06/2006...

  • Page 90: Input Balance For Yprpb Signals

    A component video signal is present on the BNC’s. • ”Data on BNC’s” is selected in the Source selection menu. • Pr/Y/Pb is selected in the Advanced menu of the corresponding image file. The procedure is the same as for a data source except: R5976817 RLM H5 02/06/2006...

  • Page 91: Agc On Video

    4. Use ↑ or ↓ to select AGC on Video. 5. Press → to pull down the menu. 6. Use ↓ or ↑ to enable or disable the AGC. 7. Press ENTER to confirm. (image 8-49) A white bullet shows the active setting. R5976817 RLM H5 02/06/2006...

  • Page 92: Manual Gain Control

    A scroll bar is displayed. (image 8-51) 6. Use ← or → to adjust the gain so that uniform white parts in the image are obtained. use the numeric keys to enter the desired value. Image 8-50 R5976817 RLM H5 02/06/2006...
  • Page 93 8. Image Menu Image 8-51 R5976817 RLM H5 02/06/2006...
  • Page 94 8. Image Menu R5976817 RLM H5 02/06/2006...

  • Page 95: Tools Menu

    What are the different possibilities within the PiP mode ? The input section of the RLM H5 projector allows a multitude of combinations of different input signals which may be projected in the 4 windows of the PiP screen.
  • Page 96 These are factory layouts, they can be edited and saved. • Personal layouts Beside the 2 fixed layouts and the 3 factory layouts, you can create 5 additional (personal) layouts. 2. fixed layout 3. factory layouts R5976817 RLM H5 02/06/2006...

  • Page 97: Pip Select

    4. Use ↑ or ↓ to select PiP select. 5. Press → to pull down the menu. 6. Use ↑ or ↓ to select the desired configuration. (image 9-3) 7. Press ENTER. A white bullet shows the active layout. R5976817 RLM H5 02/06/2006...

  • Page 98: Pip Add Window

    6. Select the source you want to display in the window with the ↑ and ↓ . (image 9-7) 7. Resize the new window with the 4 arrow keys. (image 9-8) 8. Position the window on the screen with the 4 arrow keys. (image 9-9) R5976817 RLM H5 02/06/2006...

  • Page 99: Pip Remove Window

    In the lower part of the screen appears a wizard. (image 9-12) The selected window appears surrounded with a white frame. 6. Press PiP ADJUST to move the frame along the different windows until the desired window is selected. 7. Press ENTER to remove that window. R5976817 RLM H5 02/06/2006...

  • Page 100: Pip Layout

    Press ENTER to select the input field. Use ← or → to enter the name and exit with BACK or MENU. (numeric values can be added with the remote control) If save has been selected, a message box is displayed. (image 9-15) R5976817 RLM H5 02/06/2006...

  • Page 101: Pip Rename Layout

    A dialog box is displayed. (image 9-18) Press ENTER to activate the input box. Use ← or → to enter the name and exit with BACK or MENU (numeric values can be entered with the remote control). Image 9-16 R5976817 RLM H5 02/06/2006...

  • Page 102: Pip Delete Layout

    What can be done ? PiP adjust allows to browse through the windows in the active layout, a white frame indicates the window which has the focus. This way, independent settings (picture settings, ...) are possible for each window. R5976817 RLM H5 02/06/2006...
  • Page 103 How to adjust a window in the layout ? 1. Use the PiP Adjust key or function in the menu to choose the window to be adjusted. 2. Press ENTER. All actions can be taken on the focused window. R5976817 RLM H5 02/06/2006...
  • Page 104 9. Tools Menu R5976817 RLM H5 02/06/2006...

  • Page 105: Signal Menu

    5. Press → to pull down the menu. 6. Use ↑ or ↓ to select the desired switching mode. 7. Press ENTER. A white bullet shows the active effect. The next source switching will be done using the selected effect. R5976817 RLM H5 02/06/2006...
  • Page 106 The Seamless switching mode is not used in the Random mode. Note on Fade in/out In some cases, depending on the sources to be switched, the fade in/out effect is impossible or may not occur. R5976817 RLM H5 02/06/2006...

  • Page 107: Output Frame Rate

    How to change ? 1. Press MENU to activate the Tool bar. 2. Press → to select the Signal item. (image 10-3) 3. Press ↓ to pull down the Signal menu. R5976817 RLM H5 02/06/2006...

  • Page 108: Background

    6. Use ↑ or ↓ to select the desired background. 7. Press ENTER. Image 10-4 When there is no signal connected, the projector will also start its standby timer countdown (if enabled) and shuts down after the predetermined time. R5976817 RLM H5 02/06/2006...

  • Page 109: Lamps Menu

    4. Use ↑ or ↓ to select Runtimes. 5. Press ENTER. A text box is displayed. (image 11-2) Image 11-1 Runtime Lamp 1 Lamp 2 Projector 2005 Image 11-2 Runtime text box: yellow indicator means the lamp is working R5976817 RLM H5 02/06/2006...

  • Page 110: Mode

    5. Press → to pull down the menu. 6. Use ↑ or ↓ to select the desired mode. Single Only one lamp is ignited. Dual Both lamps are ignited. 7. Press ENTER to confirm. A bullet shows the active mode. R5976817 RLM H5 02/06/2006...

  • Page 111: Economic On/Off

    30 to 200 hours. The runtime warning is displayed by default at 30 hours before end of lamp lifetime. How to set the lamp runtime warning? 1. Press MENU to activate the menu bar. 2. Press → to select the Lamp item. (image 11-6) 3. Press ↓ to pull down the Lamps menu. R5976817 RLM H5 02/06/2006...
  • Page 112 8. Press Back to return. Image 11-6 Lamp runtime warning hrs before end of lamp lifetime Image 11-7 ARNING Lamp replacement should be done by a Barco authorized technician. R5976817 RLM H5 02/06/2006...

  • Page 113: Image Files Menu

    AutoImage works only in full screen mode If the AutoImage function does not succeed in finding a file and no file is loaded (load list is empty), which means that the source is not displayed, then use the copy function, R5976817 RLM H5 02/06/2006...

  • Page 114: Load File

    In PiP mode, the files which may be loaded will be of the data type if the active window is a data window, or they will be of the video type if the active window is a video window. R5976817 RLM H5 02/06/2006...

  • Page 115: File Selection

    3. Press ↓ to pull down the Image files menu 4. Use ↑ or ↓ to select Auto Image 5. Press ENTER A textbox showing a progress bar is displayed. Tip: Press the Cancel button to cancel the operation. R5976817 RLM H5 02/06/2006...

  • Page 116: Edit File

    A dialog box is displayed with the selected source settings. (image 12-7) 8. Use ← or → to edit and change the values. Note: greyed out fields can not be updated (total pixels). 9. Press ENTER to confirm. R5976817 RLM H5 02/06/2006...

  • Page 117: Correct File Parameters

    Vertical start in lines : number of lines between the start of the input signal and start of the image on the screen. 12.6.3 Advanced video settings Overview When a video source is selected, the advanced button enables the advanced settings for that video source. R5976817 RLM H5 02/06/2006...

  • Page 118: Advanced Data Settings

    The input format settings are used to "tell more" about the signals connected on the BNC’s, it completes the information in the source selection menu. - RGB is selected by default and means that an RGB signal is connected to the BNC’s - PR/Y/PB must be selected whenever: R5976817 RLM H5 02/06/2006...

  • Page 119: Rename File

    Use ← or → to select the characters. Use the ↓ or ↑ to change the value. 9. Press ENTER to confirm the changes. Image 12-12 Rename custom file Rename custom file New name: Video625.c01 Video625.c01 Video625.c02 Image 12-14 Image 12-13 R5976817 RLM H5 02/06/2006...

  • Page 120: Copy

    Copy a standard file (.sxx) which is not too different of the source to display, then edit this file to get the best image. 12.9 Delete The active file cannot be deleted. R5976817 RLM H5 02/06/2006...

  • Page 121: Automatic Load

    2. Press → to select the Image files item. (image 12-20) 3. Press ↓ to pull down the Image files menu. 4. Use ↑ or ↓ to select Automatic load. 5. Press → to display the choices. 6. Use ↑ or ↓ to select desired choice. R5976817 RLM H5 02/06/2006...

  • Page 122: Zoom-Focus

    5. Press → to display the choices. 6. Use ↑ or ↓ to select desired choice. Universal The same zoom/focus setting will be used for all files. Unique The zoom/focus settings will be stored file per file. Image 12-21 R5976817 RLM H5 02/06/2006...

  • Page 123: Display Setup

    All menus, dialog boxes and text boxes can be disabled by putting the text box function in the off position. How to enable/disable the Textbox ? 1. Press MENU to activate the menu bar. 2. Press → to select the Display setup item. (image 13-2) R5976817 RLM H5 02/06/2006...

  • Page 124: Menu Bar Position

    2. Press → to select the Display setup item. (image 13-4) 3. Press ↓ to pull down the Display setup menu. 4. Use ↑ or ↓ to select Menu bar position menu. 5. Press ENTER. 6. Use ↑ or ↓ to position the menu bar. R5976817 RLM H5 02/06/2006...

  • Page 125: Status Bar Position

    2. Press → to select the Display setup item. (image 13-6) 3. Press ↓ to pull down the Display setup menu. 4. Use ↑ or ↓ to select Status bar position. 5. Press ENTER. 6. Use ↑ or ↓ to position the status bar Image 13-6 R5976817 RLM H5 02/06/2006...

  • Page 126: Sliderbox Position

    Auto image allows to detect automatically the characteristics of the source and uses this information to adapt the image to the DLP panels. Auto image can adapt the image based on following data : • Start pixel and start line • Contrast/brightness levels Auto image works only for data signals. R5976817 RLM H5 02/06/2006...
  • Page 127 How to perform Auto Image ? 1. press Auto Image on the RCU A text box showing a progress bar is displayed. (image 13-11) Image 13-11 During the AUTO IMAGE measuring process the data source disappears temporarily. R5976817 RLM H5 02/06/2006...

  • Page 128: Scenergix

    Why ScenergiX ? When working in a multichannel setup the RLM H5 and its Soft Edge possibilities enable an image blending that gives the appear- ance of a single view, thus achieving realistic immersion for the majority of wide screen applications.

  • Page 129: Scenergix Overlap Zone (Horizontal Scenergix)

    Total horizontal screen size in pixels : 1948 pixels Pact projector 1 = [(1024 / 1948)] x 1600 = 841 pixels Pact projector 2 = [(1024 / 1948)] x 1600 = 841 pixels Pstart projector 2 = Pstart projector 1 + (1600 – 841) R5976817 RLM H5 02/06/2006...

  • Page 130: Scenergix Overlap Zone (Vertical Scenergix)

    Within this menu the width of the blending zone is set up. How to select a border? 1. Press MENU to activate the menu bar. 2. Press → to select the Display setup item. (image 13-16) R5976817 RLM H5 02/06/2006...

  • Page 131: Adjusting With The Arrow Keys

    The border line will move in the desired direction and the light output in the overlap area will be adapted to. (image 13-17) Set first the width of the first projector and repeat for the second one. (image 13-18, image 13-19) Image 13-17 Width selections R5976817 RLM H5 02/06/2006...

  • Page 132: Black Level Of The Images

    For dark images, the overlap zone will be brighter then the rest of the images. Therefore we can rise the black level of the remaining image (excluding the overlap zone) How to adjust 1. Press MENU to activate the menu bar. R5976817 RLM H5 02/06/2006...
  • Page 133 Use the left or right arrow key to select the adjustment direction and speed. Press ENTER to increment or decrement the value. Stay pressing on ENTER until the desired value is reached. Image 13-20 Image 2 Image 1 Image 13-21 Black level adjustment R5976817 RLM H5 02/06/2006...
  • Page 134 13. Display Setup R5976817 RLM H5 02/06/2006...

  • Page 135: Installation Menu

    6. Press ENTER to switch to the shift mode. See image 14-3. ← or → Horizontal shift ↑ or ↓ Vertical shift ENTER to switch the cursor key between vertical/horizontal shift and zoom/focus Logo to switch the image between active source or test pattern R5976817 RLM H5 02/06/2006...

  • Page 136: Projector Address

    The most right digit will be selected. Use the left arrow key to jump to the other digits. (image 14-6) 7. Enter an address between 0 and 255 with the digit keys on the RCU and press ENTER to activate. R5976817 RLM H5 02/06/2006...

  • Page 137: How To Change The Common Address

    A dialog box appears on the screen. Use the ↑ to scroll to Common RC5 address. (image 14-8) 6. Press ENTER to go to the edit mode. The digit will be selected. (image 14-9) 7. Enter the common address, 0 or 1. Image 14-7 Image 14-8 Image 14-9 R5976817 RLM H5 02/06/2006...

  • Page 138: Orientation

    4. Use ↑ or ↓ to select Language. 5. Press → to pull down the menu. 6. Use ↓ or ↑ to select the desired language. 7. Press ENTER to confirm. The language is adapted and a white bullet shows the active configuration. R5976817 RLM H5 02/06/2006...

  • Page 139: Quick Access Keys

    The quick access keys overview text box appears on the screen. (image 14-13) Default factory pre-programmed functions are : color, brightness and contrast. Image 14-12 Image 14-13 How to program the quick access keys ? 1. Scroll through the menu bar to the desired menu item. R5976817 RLM H5 02/06/2006...

  • Page 140: Rs Baudrate

    4. Use ↑ or ↓ to select RS mode 5. Press → to pull down the menu. 6. Use ↓ or ↑ to select the desired mode. The following modes are possible: RS232 RS422 RS422 terminated 7. Press ENTER to confirm. R5976817 RLM H5 02/06/2006...

  • Page 141: Automatic Startup

    4. Use ↑ or ↓ to select Automatic startup . 5. Press → to pull down the menu. 6. Use ↓ or ↑ to enable/disable the automatic startup. Automatic startup enabled Automatic startup disabled 7. Press ENTER to confirm. Image 14-16 R5976817 RLM H5 02/06/2006...

  • Page 142: Security

    9. Press ACCEPT. A dialog box is displayed. Enter the PIN code, and confirm the newly entered PIN code. (image 14-20) An informative text box is then displayed. Press ENTER or BACK to escape. (image 14-21) Image 14-17 R5976817 RLM H5 02/06/2006...

  • Page 143: How To Disable The Security Mode

    6. Use ↑ or ↓ to select OFF 7. Press ENTER to confirm An Enter PIN code dialog box will be displayed. 8. Enter your PIN code. When the PIN code is correct the security mode will be switched off. Image 14-22 R5976817 RLM H5 02/06/2006...
  • Page 144 14. Installation menu R5976817 RLM H5 02/06/2006...

  • Page 145: Service

    5. Press ENTER. An options dialog box opens. (image 15-2) Image 15-1 Image 15-2 15.2 Lamps and Power supply What is possible ? To get an overview of the firmware version of the µC and the measured temperatures. R5976817 RLM H5 02/06/2006...

  • Page 146: Board Identification

    1. Press MENU to activate the menu bar. (image 15-5) 2. Press → to select the Service item. 3. Press ↓ to pull down the menu. 4. Use ↑ or ↓ to select Board Identification..5. Press ENTER. An list dialog box opens. (image 15-6) R5976817 RLM H5 02/06/2006...

  • Page 147: Diagnostics

    7. Press ENTER to select I A text box is displayed. (image 15-8) Items with a green icon are OK. Items with a red icon have a problem. 8. Use the ↑ or ↓ keys to scroll inside the list. R5976817 RLM H5 02/06/2006...

  • Page 148: Lamps And Power Supply

    5. Press → to pull down the menu. 6. Use ↑ or ↓ to select Lamps and power supply. 7. Press ENTER to select Lamps and power supply. A text box with errors is displayed. (image 15-10) Image 15-9 R5976817 RLM H5 02/06/2006...

  • Page 149: Formatter Firmware

    During start up it is possible that one or more colors do not start up correctly. To solve this problem, the formatters will be restarted. During this process, the image will disappear for a few seconds. R5976817 RLM H5 02/06/2006...

  • Page 150: How To Display

    2. Press → to select the Service item. 3. Press ↓ to pull down the menu. 4. Use ↑ or ↓ to select Formatter reset..5. Press ENTER. An confirmation dialog box opens. (image 15-14) Image 15-13 Image 15-14 R5976817 RLM H5 02/06/2006...

  • Page 151: Adjustment Menu (Check Up)

    When character set is selected A character set is built up with several pages: 1. Press ENTER for the next set (page). 2. Press BACK for previous set (page). 3. Press MENU to return to menu structure. R5976817 RLM H5 02/06/2006...

  • Page 152: Convergence

    16. Adjustment menu (check up) 16.2 Convergence Only for check up of the convergence, no adjustment is possible in the field. When a convergence problem occurred, contact a Barco service center. How to select ? 1. Press MENU to activate the menu bar.

  • Page 153: Standard Image Files

    7. Fpix MHz: pixel frequency 8. Ptot : total pixels on one horizontal line. 9. Pact: active pixels on one horizontal line. 10. Ltot: total lines in one field 11. Lact: active lines in one field. 12. Interlaced R5976817 RLM H5 02/06/2006...
  • Page 154 60,019 33,790 74,339 2200 1920 HDSDI30p 30,00 33,750 74,249 2200 1920 1125 1080 HDSDI60p 60,00 45,00 75,250 1650 1280 NTSC 59,88 15,748 13,512 49,92 15,625 13,50 ProPAL 50,480 39,550 27,251 59,99 31,496 27,024 ProNTSC Table A-1 R5976817 RLM H5 02/06/2006...

  • Page 155: Maintenance Of The Projector

    For the filters 4 & 5, when the lock is released, move the filter a little to the inside of the projector until the filter center Tip: clips are free, and next remove the filter to the outside. R5976817 RLM H5 02/06/2006...
  • Page 156 B. Maintenance of the Projector Image B-2 Image B-3 Available kit All the 5 air filters are assembled to 1 kit, order number R401045K R5976817 RLM H5 02/06/2006...

  • Page 157: Specifications

    C. Specifications C. SPECIFICATIONS C.1 RLM H5 specifications Overview Light Output 4500 ANSI Lumen Resolution 1280 x 720 (native) Contrast ratio 1000 : 1 (full field) Brightness uniformity > 90% Lamp 2 x 250 W mercury max. lifetime: 1500 hrs typ.
  • Page 158 0.8 TLD (HB) 1.6 - 2.0 1.6 - 2.0 TLD (HB) 2.0 - 2.8 2.0 - 2.8 TLD (HB) 2.8 - 5.0 2.8 - 5.0 TLD (HB) 5.0 - 8.0 5.0 - 8.0 Order Information R9010300 R5976817 RLM H5 02/06/2006...

  • Page 159: Glossary

    This standard uses TMDS (Transition Minimized Differential Signal) from Silicon Image and DDC (Display Data Channel) from VESA (Video Electronics Standards Association). DVI can be single or dual link. Luminance The component of a video signal that includes information about its brightness. R5976817 RLM H5 02/06/2006...
  • Page 160 The Video Selector is a graphical interface which allows an overview of the different video inputs (Composite Video and S-Video) and whether they are active (signal connected) or not as well as the selection of these different signals. R5976817 RLM H5 02/06/2006...

  • Page 161: Index

    AGC on Video Sliderbox position Color space Startup screen Color temperature Status bar position Filmmode TextBox Gamma Display Setup Settings Input balance Pin configuration Keystone Manual Gain control Overview Settings Input 23, 25–27, 29 Economic mode R5976817 RLM H5 02/06/2006...
  • Page 162 Manual Gain control Overview Menu 47–49, 51–54, 57–59, 62–69, 71, 73–74, 76, 79–80, 82, Switching mode 87–88, 91, 93–98, 101, 103–107, 109–112, 115–122, 124, 131–132, Source selection 51–54 134–137, 143–144, 147–148 5-cable input Adjustment menu 147–148 R5976817 RLM H5 02/06/2006...
  • Page 163 Switch on Composite video Projector address Change Overview Projector Configuration S-Video Use of icons Video selector Specifications Quick access keys Stacking projectors Quick lens adjustment Standby Timer Quick PiP Startup Automatic Startup screen Status bar position R5976817 RLM H5 02/06/2006...
  • Page 164 Index Switching Introduction Switching mode PiP select Switching off Switching to standby Video 25–26 Composite Video Temperature S-Video Ambient TextBox Tint Tools menu 91, 93 Zoom-Focus setting Overview R5976817 RLM H5 02/06/2006...
  • Page 165 Revision Sheet Barco nv Events/Documentation Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.89.70, Fax: +32 56.36.88.24 E-mail: service.media_and_entertainment.emea@barco.com, Web: www.barco.com From: Date: Please correct the following points in this documentation (R5976817/03): page wrong correct R5976817 RLM H5 02/06/2006...

Table of Contents
