Chauvet LEDsplash Jr LED-PAR83 User Manual
Ledsplash
Hide thumbs
Also See for LEDsplash Jr LED-PAR83:
- Supplementary manual (1 page) ,
- User manual (13 pages)
Related Manuals for Chauvet LEDsplash Jr LED-PAR83
Summary of Contents for Chauvet LEDsplash Jr LED-PAR83
-
Page 1: User Manual
LED-PAR83 LEDsplash™ Jr. USER MANUAL CHAUVET, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com 2008-11-17/09:40... -
Page 2: Table Of Contents
DMX Primer ............................................10 Fixture Linking ........................................... 10 DMX Channel Values ........................................11 Returns Procedure ..........................................11 Claims ............................................... 11 DMX Dipswitch Quick Reference Chart .................................... 12 Technical Specifications ........................................13 Technical Support ..........................................13 LED-PAR83 User Manual 2008-11-17 9:40:00 AM... -
Page 3: Before You Begin
EFORE EGIN What is included 1 x LED-PAR83 LEDsplash™ JR 1 x Power cable (1 m) and 1 x Linking cable (1.5 m) Warranty Card Users Manual Unpacking Instructions Immediately upon receiving a product, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. -
Page 4: Introduction
Built-in automated programs via master/slave OPTIONS • Programmable: Any universal DMX-512 controller DMX Channel Summary HANNEL NTENSITY ONTROL OF Reserved Blackout/Strobe/Dimmer Green & Blue Green & Blue Green Blue Green & Blue Green & Blue LED-PAR83 User Manual 2008-11-17 9:40:00 AM... -
Page 5: Product Overview
AC Voltage Switch Power connection Power c onnection Fuse Fuse Hanging yoke Hanging yoke Green & Blue Green & Blue Green & Blue Green & Blue Green & Blue LED-PAR83 User Manual LED-PAR83 User Manual 2008-11-17 9:40:00 AM 2008-11-17 9:40:00 AM... -
Page 6: Setup
1. Align the clamp screw with the center hole on the yoke and tighten. 2. Verify the structure can hold 10 times the weight of all to-be installed fixtures. 3. Adjust the angle on the yoke arm as necessary. LED-PAR83 User Manual 2008-11-17 9:40:00 AM... -
Page 7: Operating Instructions
B u i l t - in P ro gr a m Op t i o ns Dipswitches 1 ~ 8 There are 8 Individual programs that can be (programs) accessed by turning ON dipswitches 1 through 8 individually. LED-PAR83 User Manual 2008-11-17 9:40:00 AM... -
Page 8: Manual Control Options
If this is your first time addressing a fixture using the DMX-512 control protocol than I suggest jumping to the Appendix Section and read the heading “DMX Primer”. It contain s very useful info rmation that will help you understand its use. LED-PAR83 User Manual 2008-11-17 9:40:00 AM... - Page 9 1 – (1) = 0, Turn ON Dip # 1 simple math. ddress 233 You will most likely use the first available number which maybe number 1. This number was selected for example purposes. LED-PAR83 User Manual 2008-11-17 9:40:00 AM...
-
Page 10: Appendix
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) -
Page 11: Dmx Channel Values
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 12: Dmx Dipswitch Quick Reference Chart
DMX Dipswitch Quick Reference Chart DMX Address Quick Reference Chart Dip Switch Position DMX DIP SWITCH SET #9 0=OFF 1=ON X=OFF or ON Dip Switch Position DMX Address LED-PAR83 User Manual 2008-11-17 9:40:00 AM... -
Page 13: Technical Specifications
29th Ct ywoo , FL 3 3020 (U.S.A. uppo rt (Email): tec @ch uvetl hting com Telephone: (954) 929-1115 - (Pre ss 4) Fax: 929- 5560 - (Att ention: Servi Website: http://www.chau etlighting.c m LED-PAR83 User Manual 2008-11-17 9:40:00 AM...
