Chauvet LED-PALET Supplementary Manual

DMX Channel Values

C
HANNEL
1
2
3
4
5
6
7*
8*
9*
10*
11*
12*
13*
14*
15*
16*
17*
18*
19*
20*
21*
22*
23*
24*
25*
26*
27*
*If applicable.
COLORpalette User Manual
V F
ALUE UNCTION

Control/Operating Mode

000 019 27 Channel Mode
020 039 15 Channel Mode
040 059 9 Channel Mode
060 079 6 Channel Mode
080 089 Auto/Sound Mode 1
090 099 Auto/Sound Mode 2
100 109 Auto/Sound Mode 3
110 119 Auto/Sound Mode 4
120 129 Auto/Sound Mode 5
130 139 Auto/Sound Mode 6
140 149 Auto/Sound Mode 7
150 159 Auto/Sound Mode 8
160 169 Auto/Sound Mode 9
170 179 Auto/Sound Mode 10
180 189 Auto/Sound Mode 11
190 199 Auto/Sound Mode 12
200 209 Auto/Sound Mode 13
210 219 Auto/Sound Mode 14
220 229 Auto/Sound Mode 15
230 239 Auto Mode 1
240 255 Auto/Sound Mode 16
000 255 Auto Mode Speed (Slow > Fast)

Strobe

000 002 No Strobe
003 249 Strobe (Slow > Fast)
250 255 Sound-active (Static Colors Only)
000 255 Red 1 (0 – 100%)
000 255 Green 1 (0 – 100%)
000 255 Blue 1 (0 – 100%)
000 255 Red 2 (0 – 100%)
000 255 Green 2 (0 – 100%)
000 255 Blue 2 (0 – 100%)
000 255 Red 3 (0 – 100%)
000 255 Green 3 (0 – 100%)
000 255 Blue 3 (0 – 100%)
000 255 Red 4 (0 – 100%)
000 255 Green 4 (0 – 100%)
000 255 Blue 4 (0 – 100%)
000 255 Red 5 (0 – 100%)
000 255 Green 5 (0 – 100%)
000 255 Blue 5 (0 – 100%)
000 255 Red 6 (0 – 100%)
000 255 Green 6 (0 – 100%)
000 255 Blue 6 (0 – 100%)
000 255 Red 7 (0 – 100%)
000 255 Green 7 (0 – 100%)
000 255 Blue 7 (0 – 100%)
000 255 Red 8 (0 – 100%)
000 255 Green 8 (0 – 100%)
000 255 Blue 8 (0 – 100%)
13
2007-02-16/10:47
