Installation
In addition to the back panel connections, a three-color light-
emitting diode (LED) is visible through the top of each unit and
provides information about the status of the equipment.

Installation Procedure

Installing the Remote Module involves connecting the line cords,
the telephone cord, the power cord, and, at your option, the
RS-232 cable. The line cord and power cord are supplied with your
Remote Module, and the telephone cord and any power cords
required for the operation of the telephone are supplied with the
display telephone.
Follow these steps to install the Remote Module:
!
CAUTION
Do not plug the A/C adapters into the electrical outlets until
instructed to do so in the following procedure.
1. Ensure that the module has the proper DIP switch configuration
(see Table 2-1).
