Introduction
System Operation and
Configuration
The DEFINITY Extender system is designed for use with a
DEFINITY ECS of Version 3, Release 3 or later. The Extender
system consists of two modules. One module, identified as the
Switch Module, connects to your PBX. The other module, identified
as the Remote Module, connects to your DEFINITY telephone at
your off-premise location. Figure 1-1 shows the Extender system
configuration.
Figure 1-1. System Configuration
The modules communicate via a single analog telephone line (also
called a "plain old telephone service" [POTS] line), which can
extend your DEFINITY telephone to virtually unlimited distances.
See "Specifications" later in this chapter for detailed circuit
specifications.
1-2
Issue 2 July 1997
