INSPECTION AND MAINTENANCE

ASSEMBLING THE SCOOTER

1. Position the front and rear sections of the scooter.
Align the lower curved locking brackets of the front section with the corresponding
pegs on the front of the rear section.
Holding the seat first, slowly pivot the rear section forward until the curved locking
brackets are fully connected onto the top rear pegs
2. Loosen the tiller adjustment bolt, raise the tiller to the desired position and tighten the
bolt.
3. Reinstall the batteries and secure them with the hook and loop strap connect batteries
with cables.
4. Replace the seat and rotate to align lock pin.
Secure lock pin in place.
WARNING
After assembling your scooter, make absolutely certain the tiller adjustment knob is fully
tightened.
1
3
2
4
