Hanging The Fan - Hunter Ceiling Fans Installation And Operation Manual

BE SURE TO TIGHTEN THE HANGER PIPE INTO THE FAN, AND THE
HANGER BRACKET ONTO THE PIPE. TIGHTEN THE 2 SET SCREWS, AS
DESCRIBED IN STEP 7, TO PREVENT THE FAN FROM FALLING. YOUR FAN
MAY WEIGH UP TO 50 LBS. ALL OF THE FOLLOWING STEPS MUST BE
FOLLOWED IN ORDER TO ENSURE A SECURE MOUNTING.
1. Feed the wires from the top of your motor through the hanger pipe (see Fig. 3).
2. Back out the motor housing set screw (Do not completely remove from fan) in neck of fan motor
housing and hanger bracket assembly so the hanger pipe can be screwed in.
3. Screw the pipe into the fan until tight (at least 4 1/2 turns) (see Fig. 4).
NOTE: Some of the pipe threads may still be visible.
Wires
Motor
Housing
Fig.
Hunter Fan Company

Hanging The Fan

! CAUTION
Hanger
Pipe
Fig.

!
Motor Housing
Set Screw
42761-01 • 07/09/07
