Pre-Installation

Pre- Installation
Select installation site: Normally this is near the center of the room, often replacing a light fixture.
Make certain that ample clearance is left for the rotating fan blades. For maximum efficiency, no
obstruction (walls, posts, etc.) should be within 24" of the tips of the blades (see Fig. 1).
Your Hunter fan comes with the proper hardware to hang the fan from a 8 foot ceiling so the fan
blades will be 12" from the ceiling and approximately 7 feet from the floor (see Fig. 1).
NOTE: On vaulted ceilings, up to 45° pitch, you may want to use the Hunter Vaulted Ceiling
Mounting Kit (22174). This kit can be purchased via our website or our parts and service number
provided on page 14 of this manual.
!
CAUTION
!
NEVER LIFT THE MOTOR BY THE WIRES.
LET MOTOR REST IN THE CARTON LINER FOR PROTECTION.
12" (ref.) Minimum
24" Clearance
7' From Floor
Fig. 1

Hunter Fan Company
42761-01 • 07/09/07
