Traceroute

Here you can trace a packet from the XPort AR to an Internet host, showing how many hops the
packet requires to reach the host and how long each hop takes. If you visit a web site whose
pages appear slowly, you can use traceroute to determine where the longest delays are occurring.
To use Traceroute:
1. Click Diagnostics on the menu bar and then Traceroute at the top of the page. The
Diagnostics: Traceroute page opens.
2. Enter or modify the following setting:
Diagnostics: Traceroute
Settings
Host
3. Click Submit. The results of the traceroute display in the page.
XPort AR User Guide

Figure 11-21 Diagnostics: Traceroute

Diagnostics: Traceroute
Table 11-22
Description
Enter the IP address or DNS hostname. This address is used
to show the path between it and the device when issuing the
traceroute command.
11: Maintenance and Diagnostics Settings
103
