MIB-II Statistics

The MIB-II Network Statistics page shows the various SNMP-served Management Information
Bases (MIBs) available on the XPort AR.
To view MIB-II statistics:
1. Click Diagnostics on the menu bar and then MIB-II at the top of the page menu. The MIB-II
Network Statistics page opens.
2. Click any of the available links to open the corresponding table and statistics. For more
information, refer to the table below:
XPort AR User Guide

Figure 11-16 MIB-II Network Statistics

Requests for Comments (RFCs)
Table 11-17
RFC 1213 Original MIB-II definitions.
RFC 2011 Updated definitions for IP and ICMP.
RFC 2012 Updated definitions for TCP.
Updated definitions for UDP.
RFC 2013
RFC 2096 Definitions for IP forwarding.
