S p e c i f i c a t i o n s
Electronics
Vacuum Tubes 2 x 6BQ5
3 x 12AX7 (alt 7025A)
DC powered filament supply on preamp tubes
Bias Supply Cathode Bias
Power Output: 15 Watts RMS
Speaker: 12 inch Celestion® speaker
Channels: one lead and one clean channel
Input Impedance: 1 Meg Ohm
Tone Controls: Treble, Bass, & Middle
Reverb on Master Section
Reverb Accutronics® long-reverb with dual-springs
Power Supply Fully regulated
Connectors
Input Jack 1/4 inch phone jack
Send Jack Balanced 1/4 inch TRS
(Tip-positive / Ring-negative / Sleeve-ground)
Return Jack balanced 1/4 inch phone jack, 10kOhms
Speaker Jacks Two 1/4 inch phone jacks
Footswitch Jack 1/4 inch TRS, accepts a standard,
latching dual-footswitch and connecting cable
Cabinet
Cabinet Construction All Plywood
Covering Black Leatherette
Grille Perforated 18 gauge painted steel
with silver cloth covering
Dimensions (WxHxD) 18.5 x 17 x 8.5 inches
47 x 43 x 22 cm
Weight 32 lbs (14.5 kg)

Power Requirements

120V 60Hz 0.5A
230V 50Hz 0,25A
Warranty Two-year, unlimited (
transferable warranty*
(
valid in USA and Canada only
even if you break it!
)
4
)
