AXIS 200+ and 240 User's Guide

Quick Installation Procedure

To get your camera server up and running on an ethernet network, follow these instructions:
1. Note the serial number found on the underside label of the camera server. The serial number
equals the Ethernet address of the unit.
2. AXIS 240 only: Connect the camera(s) to the camera server.
3. Connect your camera server to the network.
4. Connect the external power supply.
specific. Refer to Appendix A - Hardware Inventory and check that the type of power supply is correct.
5. Acquire a valid and unused IP address for the camera server from your Network Administrator.
6. Assign the IP address using your preferred method, the AXIS IP Installer program or ARP:
Easy - AXIS IP Installer
7.a Windows 95/98 & NT - Install the AXIS
IP Installer. You will find the installation
program on the AXIS Online CD and on
the Axis Web Site at http://www.axis.com
7.b Run the AXIS IP Installer from the Start
menu.
7.c Restart your camera server.
7.dLocate the serial number of your camera
server in the list.
7.e Enter the desired IP address, and click Set
IP address.
8. To access the camera server Home Page,
click Home page of selected Axis-server...
9. Adjust the focus of the camera(s). Click Reload/Refresh in your Web browser to test your
adjustments.
The installation is complete and you can now include snapshots into your own applications.
Modem Only Installation
See Appendix C - Modem Installation on how to install your camera server if you are using a modem.
Note: The power supply supplied with your product is country
Quick - ARP/ping
7. Windows 95/98 & NT - Start a DOS
window and type these commands:
arp -s <camera IP address> <Ethernet address>
<my PC IP address>
ping <IP address>
Example
arp -s 192.168.3.191 00-40-8c-10-00-86
192.168.3.193
ping 192.168.3.191
UNIX & OS/2 - Type these commands:
arp -s <IP address> <Ethernet address> temp
ping <IP address>
Example
arp -s 192.168.3.191 00:40:8c:10:00:86 temp
ping 192.168.3.191
8. To access the camera server Home Page,
start your Web browser and enter the IP
address in the location/address field
http://<IP address>/
Example
http://192.168.3.191/
