Operation Manual
For Rinnai continuous flow water heaters manufactured from 2010 onwards
•
Internal Rinnai continuous flow water heaters must be installed with an approved Rinnai
flue system
•
Appliance must be installed, commissioned and serviced by a licensed tradesperson in
accordance with these instructions and all applicable local rules and regulations
•
Models are not suitable as a spa or swimming pool heater
•
Owner, please retain this manual for future reference
•
All gas appliances require regular servicing
Continuous Flow Water
Heaters
(serial number 09.12—xxxxxx)
Installer, please leave this manual with the owner
Advertisement
Table of Contents
Related Manuals for Rinnai Continuous Flow Water Heaters
Summary of Contents for Rinnai Continuous Flow Water Heaters
- Page 1 For Rinnai continuous flow water heaters manufactured from 2010 onwards (serial number 09.12—xxxxxx) • Internal Rinnai continuous flow water heaters must be installed with an approved Rinnai flue system • Appliance must be installed, commissioned and serviced by a licensed tradesperson in accordance with these instructions and all applicable local rules and regulations •...
- Page 2 Rinnai. A solar installation using a Rinnai continuous flow unit in a single residential dwelling is considered a domestic application. Examples of a commercial application in a domestic dwelling, hair salon, catering kitchen, motel, communal care facility etc.
- Page 3 WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, personal injury or loss of life. For assistance or additional information contact Rinnai on 0800 RINNAI (0800 746 624). Rinnai New Zealand Continuous Flow Water Heater Operation Manual...
-
Page 4: Table Of Contents
About Your Continuous Flow Water Heater Warning About Hot Water General Safety General Information General Controller Information Universal Controller (Compact) Kitchen Deluxe Controller Bathroom Deluxe Controller Troubleshooting Service Record Draining Your Water Heater Installer Details Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09... -
Page 5: About Your Continuous Flow Water Heater
About Your Continuous Flow Water Heater Congratulations on purchasing the latest technology Rinnai continuous flow water heater. Before using or operating your water heater Ensure the installer talks to you about the use and care of this appliance and that you understand these instructions. -
Page 6: Warning About Hot Water
Hot water at 65 °C (a common water temperature in New Zealand) can severely burn a child in less than half a second. At 55 °C (preset temperature for domestic Rinnai continuous flow water heaters) it takes a half minute. -
Page 7: General Information
Improper installation, adjustment, service or maintenance can cause serious injury, property damage or death. Please ensure your installation is completed by a licensed tradesperson. Safety devices Your Rinnai continuous flow water heater has the following safety devices. • Flame failure - flame rod... - Page 8 Rinnai has a service and spare parts network with personnel who are fully trained and equipped to give the best advice on your Rinnai appliance. If your appliance needs servicing, please call Rinnai (0800 746 624) from a land line and select option one for a service centre in your area.
-
Page 9: General Controller Information
If the temperature this is not the case, the controllers have before a child been incorrectly installed and you should is placed in contact your installer. contact with hot water. Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09... - Page 10 Maximum of one Kitchen Deluxe Controller (MC-100V) • Maximum of two Bathroom Deluxe Controllers (BC-100V) • Only one controller can be set to deliver 55 °C, this cannot be a Bathroom Deluxe Controller Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09...
- Page 11 11 or 12) ignition may fail and the ‘In Use’ button will not be lit. The water flow may need to be stopped and re-started several times before the appliance will remain alight. Rinnai New Zealand Continuous Flow Water Heater Operation Manual...
-
Page 12: Universal Controller (Compact)
‘Hot water temp.’ up or down buttons until the desired temperature is reached. The ‘beep’ sound can be muted by pressing the ‘Hot water temp.’ up and Muting the down buttons simultaneously for more than 3 seconds. ‘beep’ sound Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09... -
Page 13: How To Use Two Or More Universal Water Controllers
Once the hot water is running, if the set temperature is either too hot or cold, press the ‘Hot water temp.’ up and down buttons until the desired temperature is reached. Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09... -
Page 14: Kitchen Deluxe Controller
On or Off. The clock may need resetting if power to the water heater is disrupted due to a power failure or if the power is switched off over a prolonged period. Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09... - Page 15 Once the hot water is running, if the set temperature is either too hot or cold, press the ‘Hot water temp.’ up and down buttons until the desired temperature is reached. Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09...
-
Page 16: Bathroom Deluxe Controller
If more than one controller is fitted press the ‘Transfer’ button once to transfer priority to the desired controller. Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09... - Page 17 Once the hot water is running, if the set temperature is either too hot or cold, press the ‘Temperature’ up and down buttons until the desired temperature is reached. Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09...
- Page 18 Delivered Volume (bathfill Delivered Volume (bathfill restarted Volume interrupted - tap closed) - tap turned on again) 160 L 50 L 110 L 160 L 110 L Resets back to normal operation Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09...
- Page 19 The water heater can be turned on and off at any water controller. If more controllers than one controller is fitted, press the ‘Transfer’ button to transfer priority to the desired water controller. Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09...
-
Page 20: Troubleshooting
Troubleshooting With controllers or status monitor Your Rinnai continuous flow water heater has a self diagnostic capability. If a fault occurs, an error code will flash on the digital monitor (if you have water controllers) or status monitor (selected models only). This assists with diagnosing the fault and may enable you to overcome a problem without a service call. - Page 21 This page has been intentionally left blank Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09...
-
Page 22: Service Record
Date Service 6 Date Company Company Address Address Phone Phone Contact Contact Comments Comments Service 7 Date Service 8 Date Company Company Address Address Phone Phone Contact Contact Comments Comments Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09... - Page 23 Service Record - Parts Replaced Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09...
-
Page 24: Draining Your Water Heater
About this document These instructions are intended as a guide only. Rinnai will not accept liability for issues arising from the use of this information. In particular Rinnai will not be responsible for damage caused by water freezing where this procedure was followed and sufficient water failed to drain from... - Page 25 DO NOT operate the water heater if it or the external pipes have frozen. Close the gas and water valves and turn off the power. Wait until the water thaws, check this by opening the water supply valve. Check the water heater and pipes for leaks. Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09...
-
Page 26: Installer Details
Installer Details Company name:______________________________________________________________ Installer name:_______________________________________________________________ Address:____________________________________________________________________ ___________________________________________________________________________ Phone:_______________________________ Mobile:______________________________ Certificate of Compliance number for installation:____________________________________ Signed:______________________________ Date:_______________________________ Installer, please remember to complete and leave the Commissioning Checklist with the customer. Rinnai New Zealand Continuous Flow Water Heater Operation Manual 01-09... - Page 28 (09) 257 3899 Email: info@rinnai.co.nz Websites: www.rinnai.co.nz and www.rinnai-tradesmart.co.nz All Rinnai appliances meet or exceed the safety standards required by New Zealand gas and electrical regulations. Rinnai is constantly improving its products and as such information and specifications are subject to change or variation without notice.
