4. With the help of a second person, hold the con-
sole assembly near the Uprights (73, 74).
Connect the Upright Wire Harness (75) to the
Console Wire Harness (71). Make sure to con-
nect the connectors properly (see the inset
drawing). The connectors should slide to-
gether easily and snap into place. If they do
not, turn one connector and try again. IF THE
CONNECTORS ARE NOT CONNECTED
PROPERLY, THE CONSOLE MAY BE DAM-
AGED WHEN THE POWER IS TURNED ON.
5. Insert the brackets on the Handrails (99) into the
Right Upright (74) and the Left Upright (73).
Make sure that no wires are pinched.
6. Finger tighten three Handrail Bolts (64) with
three Star Washers (90) into the Right Upright
(74). Next, finger tighten three Handrail Bolts
with three Star Washers (not shown) into the
Left Upright (73). Then, firmly tighten all six
Handrail Bolts.
4
Console
Assembly
71
75
5
99
73
6
73
64
8
73
71
75
74
64
90
74
90
74
99
