STEP 3 CHOOSE MEMORY
The standard memory features are:
Plug-In Memory Riser Boards
■
—
—
—
DIMMs
■
—
—
—
—
Each CPU controls eight Millbrook-2 DDR3 channels. There is one memory riser board for
■
each DDR3 channel. Memory is organized as paired-DIMM memory channels.
Choose Riser Boards
You may choose eight or sixteen riser boards. If you choose eight, four will be installed per CPU.
If you choose sixteen, eight will be installed per CPU.
Table 4 Available Riser Boards
Product ID (PID)
Riser Board Options
C260-MRBD-002
C260-MRBD-004
Approved Configurations
(1) Eight Two-Socket Risers
16 DIMMs capacity total
■
(2) Sixteen Two-Socket Risers
32 DIMMs capacity total
■
Cisco UCS C260 M2 High-Performance Rack-Mount Server
Two types
• 2-DIMM riser board
• 4-DIMM extended memory riser board
Riser boards plug vertically into the motherboard
Four or eight riser boards per CPU (total maximum of sixteen per system)
Clock speed: 1333 MHz
Ranks per DIMM: 1, 2, or 4
Operational voltage: 1.35 V
Registered
PID Description
Low Cost 2-Socket Memory Riser
Extended 4-Socket Memory Riser
CONFIGURING the SERVER
DIMMs per Riser
2
4
