Related Part Numbers

Option Kit Part Numbers

B-1
Extron Part
Blank Front Panel
Front Panel Controller (QS-FPC)
Audio Connectors (Phoenix)
SVHS-to-BNC Adapter
GLI 250
- (Ground Loop Isolator, 250 MHz RGBHV)
PA 250
- (Peaking Amplifier, 200 MHz RGBS)
Matrix 100 User's Manual
SC 110 Sync Combiner (115v)
SC 210 Sync Processor (115v)
Kits can be ordered from Extron for adding modules to an existing Matrix 100.
The following list gives part numbers for available kits.
Matrix 100 Option Kit
Redundant Power Supply
8 x 8 Stereo Audio Module
4 x 4 MRAM (for RGB)
8 x 4 MRAM (for RGB)
8 x 8 MRAM (for RGB)
4 x 4 Sync Module
8 x 4 Sync Module
8 x 8 Sync Module
4 x 4 Composite Video
8 x 4 Composite Video
8 x 8 Composite Video
These kits include all the necessary parts, as well as instructions for a qualified
person to add options to a Matrix 100. Chapter 2 of this manual also has some
procedures for adding options.
Appendix B • Part Numbers and Reference
Part #
60-147-01
60-188-01
10-163-01
26-353-01
60-123-01
60-124-01
68-199-01 - (this manual)
60-153-01 (230v = 60-153-02
60-154-01 (230v = 60-154-02)
Part #
70-020-01
70-039-01
70-041-01
70-041-02
70-041-03
70-024-01
70-024-02
70-024-03
70-025-01
70-025-02
70-025-03
Extron • Matrix 100 • User's Manual
