Extron electronics CLK 100 Specification Sheet

CLK 100
12/24 Hour LCD Clock with Thermometer
FeaTures
High contrast, easy-to-read LCD display with 0.8 inch (20 mm) character
•
readout — The front panel display is easy to read from across the room, even under
dim lighting conditions.
12/24 hour time and date display — Facilitates time/date logging for service calls and
•
other applications.
Built-in thermometer with °F/°C temperature display — Continuous display
•
of ambient temperature, updated every 60 seconds. The thermometer is useful in
identifying potentially excessive room or equipment rack heat conditions.
Back panel sensor reads operating temperature inside equipment rack enclosure
•
Runs on a single AAA battery - included
•
Ideal for desktop or rack-mount applications
•
Rack-mountable 1U, quarter rack width metal enclosure
•
descrIPTIon
The Extron CLK 100 is a versatile, battery-operated LCD clock with an integrated thermometer,
ideal for monitoring the ambient temperature within an equipment rack or room. The CLK 100
displays the date and time of day in either 12 hour or 24 hour format, and temperature in
degrees Fahrenheit or Centigrade. Part of the VersaTools
friendly products, the CLK 100 is housed in a 1U, quarter rack width metal enclosure for easy
rack mounting with other VersaTools products, and is equally at home in desktop or shelf
top applications.
ModeL
CLK 100
europe europe dubai dubai
+31.33.453.4040 / +800.3987.6673 +31.33.453.4040 / +800.3987.6673 +971.4.2991800 +971.4.2991800
+31.33.453.4050 FAX +31.33.453.4050 FAX +971.4.2991880 FAX +971.4.2991880 FAX
line of small, economical, integrator
®
VersIon descrIPTIon
LCD Clock with Thermometer
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
asia asia
+65.6383.4400 / +800.7339.8766 +65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX +65.6383.4664 FAX

sPecIFIcaTIons

cLock and TherMoMeTer
Clock accuracy . . . . . . . . . . . . . . . . . . <±30 seconds per month
Temperature display range . . . . +16 to +122 °F (-9 to +50 °C)
Temperature accuracy . . . . . . . . . ±3 °F (±2 °C)
Temperature sampling
interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 minute
Temperature sampling
duration . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.1 to 0.2 s
GeneraL
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Supplied by internal batteries
Batteries
Number / Signal type . . . . . . . . . . . . . 1 AAA battery (1.2 to 1.7 V)
Operating life . . . . . . . . . . . . . . . . . . . . . . 1 year
Standby current . . . . . . . . . . . . . . . . . 20 µA
Temperature sampling
current . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300 µA
Temperature / Humidity . . . . . . . . Storage: +14 to +140 °F (-10 to +60 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount . . . . . . . . . . . . . . . . . . . . . . Yes, with optional 1U rack shelf, part #60-190-01 or 60-604-01; or
VersaTools rack shelf, part #60-190-20 or 60-604-20
®
Enclosure type . . . . . . . . . . . . . . . . . . . Metal
Enclosure dimensions . . . . . . . . . . 1.7" H x 4.3" W x 3.0" D (1U high, quarter rack wide)
4.2 cm H x 11.0 cm W x 7.6 cm D
Product weight . . . . . . . . . . . . . . . . . . 0.3 lbs (0.1 kg)
Shipping weight . . . . . . . . . . . . . . . . . 1 lbs (1 kg)
Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . ISTA 1A in carton (International Safe Transit Association)
Compliances . . . . . . . . . . . . . . . . . . . . . CE
MTBF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30,000 hours
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 3 years parts and labor
NOTE: All nominal levels are at ±10%. Specifications are subject to change without notice.
China China
+86.21.3760.1568 / +400.883.1568 +86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX +86.21.3760.1566 FAX
l c d c l o c k S & t h e r M o M e t e r S
ParT #
60-791-01
