COLOR VIDEO CAMERA
DXC-D35
DXC-D35P
DXC-D35WS
DXC-D35WSP
SERVICE MANUAL
Volume 1 1st Edition
WS

Advertisement

Table of Contents
loading

Related Manuals for Sony DXC-D35

Summary of Contents for Sony DXC-D35

  • Page 1 COLOR VIDEO CAMERA DXC-D35 DXC-D35P DXC-D35WS DXC-D35WSP SERVICE MANUAL Volume 1 1st Edition...
  • Page 2 électrique, d’incendie ou de blessure n’effectuer que les réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres. Pour toute réparation faire appel à une personne compétente uniquement. DXC-D35/D35WS (UC) DXC-D35P/D35WSP (CE) V1...
  • Page 3 Mettre au rebut les batteries usagées conformément aux instructions du fabricant. ADVARSEL! Lithiumbatteri-Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. DXC-D35/D35WS (UC) 1 (P) DXC-D35P/D35WSP (CE) V1...
  • Page 4 X-RAY RADIATION WARNING Be sure that parts replacement in the high voltage block and adjustments made to the high voltage circuits are carried out precisely in accordance with the procedures given in this manual. 2 (P) DXC-D35/D35WS (UC) DXC-D35P/D35WSP (CE) V1...

  • Page 5: Table Of Contents

    Recommended Replacement Parts ............2-14 2-10. Attaching the 4-type or 5-type Viewfinder ..........2-15 2-11. Disconnecting/Connecting the Flexible Card Wire ........2-16 2-12. Service Mode Operation ................2-17 2-12-1. Service Menu ................2-18 2-12-2. File Menu ................. 2-30 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 6 Changing the Setting Value of Black Level ......3-18 3-4-3. Changing the Flare Compensation Setting Value ....3-19 3-4-4. Changing the Gamma Correction Setting Value ...... 3-19 3-4-5. Changing the Manual Knee/White Clip Setting Value .... 3-20 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 7: Manual Structure

    Manual Structure Purpose of this manual This is the Service Manual Volume 1 of the color video camera DXC-D35/D35P and DXC-D35WS/D35WSP. Contains the operation manual related to the operations of this equipment, the replacement of the parts and adjustments. Related manuals Besides this Service Manual Volume 1, the following manuals are availabel for color video camera DXC-D35/D35P and DXC-D35WS/D35WSP.

  • Page 9: Operating Instructions

    3-203-895-11(1) Color Video Camera Operating Instructions Before operating the unit, please read this manual thoroughly and retain it for future reference. DXC-D35K/D35PK DXC-D35L/D35PL DXC-D35WSL/D35WSPL DXC-D35H/D35PH 2000 by Sony Corporation...
  • Page 10 The model and serial numbers are located on the top. business trash may be prohibited. Record these numbers in the spaces provided below. Refer to them whenever you call upon your Sony dealer regarding RBRC (Rechargeable Battery Recycling Corporation) this product.
  • Page 11 Product Configurations ............ 7 Basic Procedure for Shooting........43 Features ................9 Using the DynaLatitude Function ........45 Features on the DXC-D35/D35P/D35WSL/D35WSPL ..9 Shooting with the DSR-1/1P ........... 46 Features on the DXC-D35WSL/D35WSPL ...... 12 Using the ClipLink Function ..........46 Location and function of Parts ........
  • Page 12 Table of Contents Chapter Chapter 5 Adjustments and White Balance Adjustment ..........79 Settings Saving an Appropriate White Balance Value Overview in Memory ..............79 Using the Preset White Balance Settings ......81 Light Sources and Color Temperatures ......81 Using the ATW (Auto Tracing White Balance) Function................

  • Page 13: Product Configurations

    (DXC-D35WSL/D35WSPL) settings and you can freely create user files as well. • Sensitivity: F11.0 (at 3200 K, 2000 lux) • S/N: 63 dB (DXC-D35/D35WSL) or 61 dB (DXC- Automatic recording of setup data (when Test chart for flange focal length...
  • Page 14 Thanks to the Dynafit Pad which fits well to the The ClipLink function can be used at every step from IRE on the DXC-D35/D35WSL (or from 70 to 90% on shoulder, the camera is stable on the shoulder. acquisition to editing. Information necessary for 24 dB+DPR and hyper gain.
  • Page 15 Location and Function of Parts Features Features on the DXC-D35WSL/ Camera Head D35WSPL Right side view Features only on the DXC-D35WSL/S35WSPL is described in this section. See “Features on the DXC- D35/D35P/D35WSL/D35WSPL” (page 9) for common features on a 4:3 standard-screen type digital 1 EZ MODE button and indicator video camera and 16:9 wide-screen type digital video 2 EZ FOCUS button...
  • Page 16 HYPER GAIN switch available, and press either of the buttons to the inner position, the DXC-D35/D35P/D35WSL/D35WSPL’s Setting this switch to the ON position increases the position to increase the speed. status (of current settings) is displayed.
  • Page 17 Location and Function of Parts w; ZEBRA switch wa UP/ON button 6 SHUTTER switch 8 AUDIO LEVEL knob Set this switch to the ON position to display a zebra Use this button to open displays and to make “ON” Use this switch to set the shutter speed, CLS (clear When the DSR-1/1P is attached, you can use this knob pattern (diagonal stripes) in the viewfinder.
  • Page 18 Location and Function of Parts 7 REMOTE connector 1 (mini-jack) qa LENS connector (12-pin, for -inch lens) VCL-918BY Zoom Lens Connect the RM-LG1 Remote Control Unit to enable Connect the lens connector. remote operation of the ClipLink function. qs VF (viewfinder) connector (8-pin) 8 MONITOR OUT connector (BNC) This is the connector for the DXF-41/51 viewfinder.

  • Page 19: Dxf-801/801Ce Viewfinder

    Location and Function of Parts 1 Iris ring 0 RET (return) button DXF-801/801CE Viewfinder For manual iris control, set the IRIS selector qd to the This allows you to check the video signal as follows. “M” position, and turn this ring. When operating with a portable VTR connected You can switch the scan size of the DXF-801/801CE via other equipment: when the VTR is in...

  • Page 20: Fitting And Connections

    If you have difficulty finding qa Tally lamp CR2032-type lithium batteries, contact your Sony When the TALLY switch qf is in the ON position, this dealer. operates in the same way as the REC/TALLY indicators 6.

  • Page 21: Replacing The Lithium Battery

    Fitting a VTR Replacing the Lithium Battery This section explains how to attach the DSR-1/1P to When replacing the camera head grip with a camcorder Pull the upper part of the grip, see “Using the Camcorder Grip” (page 27). the camera head. The method for attaching a PVV-3/ battery cover (on the rear of 3P is similar.

  • Page 22: Fitting A Vtr

    Fitting a VTR Using the Camcorder Grip Slide the DSR-1/1P and the camera head together in the When using the camera head with a VTR as a camcorder grip and the method for attaching it differ groove as far as possible. camcorder, you can replace the camera head’s grip slightly depending on the type of VTR.
  • Page 23 Fitting a VTR Perform the first three steps in Remove the grip’s three “Fitting a VTR”. screws, then pull up the grip to remove it. Screw the connection plate (supplied with the grip for the DVCAM camcorder) which straddles the connection between the camera head and the DSR-1/1P.
  • Page 24 Fitting the Lens In the case of the DXC-D35K/D35PK model, the lens Using the triangular mark as a is already fitted. In other cases, use the following guide, push the lens connector procedure to fit the lens. into the LENS connector on the camera head, until it clicks Remove the retaining rubber into place.

  • Page 25: Using The Viewfinder

    You cannot stow the camera attached with a left eye with your left eye to the viewfinder. adaptor in the LC-421 Carrying Case. Removing the Viewfinder For details, consult your Sony dealer. Remove any microphone from the viewfinder before Using an Optional Microphone beginning.

  • Page 26: Using Accessories

    Example of fully-stowed carrying case For details see the instructions provided with the CAC-4. VCT-U14 Tripod Adaptor DXC-D35/D35P/D35WS/D35WSP Color Video Camera Tripod This can be stored with the following system Side the camera forward component fitted.

  • Page 27: Connecting A Portable Vtr

    CCU-M5/M5P/M7/M7P Camera configuration. 26-pin connector Control Unit to provide video and color sync between cameras, and special effects and other devices to allow For details, consult your Sony dealer. DXC-D35/D35P/ VTR/CCU/CMA switching, wipes and so forth. D35WS/D35WSP...
  • Page 28 Connections Connecting a Number of Cameras (Without Using a Camera Control DXF-41 or DXF-51 Unit) DXC-D35/D35P/D35WS/D35WSP CA-537/537P signal. The camera will then operate synchronized to When using two or more synchronized cameras Headset without a camera control unit, connect an external sync this signal.

  • Page 29: Camera Adaptor Power Supply

    Using an Anton Bauer Intelligent Battery a fully-charged battery pack BC-410/410CE System and Ultralight System NP-1B BC-1WD/1WDCE, 95 minutes DXC-D35/D35P Fitting the special battery mount made by Anton Bauer BC-410/410CE Corporation to this unit allows you to use their Battery pack With camera With DSR-1/...
  • Page 30 Chapter Shooting Basic Procedure for Shooting ZEBRA switch RET button POWER switch Focusing ring FILTER control VTR button Attach the VTR or camera adaptor to the camera Set the FILTER control appropriately for the head, then turn each device’s power on. lighting conditions.

  • Page 31: Basic Procedure For Shooting

    Basic Procedure for Shooting Turn the focusing ring so that the subject is Reviewing the recording Filter setting Lighting conditions sharply in focus. It may be convenient to use the 1 (3200K) Studio halogen lighting (incandescent), EZ FOCUS button for the “easy focus” function sunrise and sunset.
  • Page 32 Shooting with the DSR-1/1P The DXC-D35/D35P/D35WS/D35WSP docks with Press the VTR button on the camera head or the Press the TAKE button when you find a shot Setting Mark IN/OUT points as you shoot the DSR-1/1P to configure a DVCAM Camcorder.

  • Page 33: Shooting With The Dsr-1/1P

    Shooting with the DSR-1/1P Release the REV or FWD button when you find Press the UP/ON button when you see the image Setting cue points as you shoot Using the Edit Search Function the tape location where you wish to continue you want to freeze.
  • Page 34 Chapter Viewfinder Screen Indications and Menus Viewfinder Screen Indications There are four types of indication screen which appear in the viewfinder, as follows. • Normal indications These show the operating state of the camera and connected VTR. (See page 54.) •...
  • Page 35 Viewfinder Screen Indications Displaying the advanced menu and Status indications Display by holding the switching to the normal indications MENU/STATUS switch up Normal indications while the normal indications are present. WHITE : AUTO/A Use the following procedure to display the advanced TCG 12:34:56:00 A.IRIS: STD FILE...
  • Page 36 Viewfinder Normal Indications During normal operation, the following items can be 5 Clip mode indication qa Audio recording level indicators indicated in the viewfinder. A “CLIP M” or “CLIP C” indication appears when These show the recording levels of audio channels 1 you use the ClipLink function and record using the and 2 on the VTR.

  • Page 37: Viewfinder Normal Indications

    CLIP DATA ERR Abnormality of the cassette memory data. qk Gain indication If an error message appears, contact your Sony dealer. AUDIO 48kHz? At back space editing, audio This shows the gain value, and the settings of the (4 flashes/s)
  • Page 38 (black compress) and positive values For details of this operation, see “Setup Files” (page 71). make these areas brighter (black stretch). SHUTTER DXC-D35/D35WSL: 1/100 (normal Sets shutter speed value), 1/250, 1/500, 1/1000, 1/ or CLS/EVS setting 2000, EVS, CLS (60.4 Hz to 200.3 (see page 84) .

  • Page 39: Viewfinder Basic Menu

    Viewfinder Basic Menu Press the MENU/STATUS switch to move the text Basic menu page 6 Basic menu pages 7 and 8 Item Settings entry arrow. MARKER ON (normal value), OFF Sets MARKER display ON/OFF. MARKER is displayed The following display is shown when the DSR-1/1P is You can create a title of up to four lines, each of when this setting is ON Press the MENU/STATUS switch upward to move...
  • Page 40 (see page 57) do not appear in the normal indications are displayed. If this message normal incidations. However, when you press the appears, contact your Sony dealer. To change a character after confirming it MENU/STATUS switch up, for as long as you hold it Return to step 3, and input the character again.

  • Page 41: Advanced Menu Operations

    SMPTE (normal value for ZEBRA 1 (normal value): Displays To select items in a page Selects normal width or DXC-D35/D35WSL): narrower width for color Normal width Selects type of zebra pattern the zebra pattern over parts Press the MENU/STATUS switch to move the cursor...

  • Page 42: Viewfinder Advanced Menu

    Viewfinder Advanced Menu When you have finished entering the text, move Item Settings Item Settings Item Settings the cursor to the parenthesis position. GAIN IND ON (normal value): Always VF TALLY 1: Uses only the upper TC IND ON (normal value): Selects whether or not to displays.
  • Page 43 Viewfinder Advanced Menu EZ mode settings Item Setting Advanced menu pages 10 to 13 Advanced menu pages 14 and 15 The following settings are set for the camera head CLOCK IND OFF (normal value): Not when EZ mode has been selected. Selects whether or not to display.

  • Page 44: Calling Up A Setup File

    Setup Files Viewfinder Advanced Menu You can use setup files to reproduce a particular Move the cursor to SELECT FILE and use the UP/ Video Output and Viewfinder Picture (For DXC-D35WSL/D35WSPL) configuration of settings. You can also revise the ON button or the DOWN/OFF button to select the contents of setup files.

  • Page 45: Setup Files

    Setup Files Press the UP/ON button to call up the file. To Page 12 To call up files recorded onto a tape (when Changing File Settings abort the call up operation, press the DOWN/OFF using the DSR-1/1P) Item Settings button (the display returns to the one shown in step When using advanced menu page 11 or 12, you can –99 to ±0 (normal value) to First, connect the DSR-1/1P to the camera head and...
  • Page 46 Setup Files Access advanced menu page 13. Press the UP/ON button to store the file. To abort the save operation, press the DOWN/OFF button (the screen returns to the screen shown in step 2). Currently The tape automatically rewinds and recording selected file starts.

  • Page 47: Setting Up The Camera Using Data Recorded On Tape

    Using SetupNavi and SetupLog with the DSR-1/1P The SetupNavi function records the setup menu and ”NO TAPE” is displayed if you neglected to load a The cursor ( ) changes to the text entry cursor Recording the Menu Settings setup files onto a tape, so that the same settings can be cassette.

  • Page 48: Using Setupnavi And Setuplog With The Dsr-1/1P

    Using SetupNavi and SetupLog with the DSR-1/1P Chapter To abort the data recording while in progress Status display (page 2) Press the DOWN/OFF button. PLAY TCR 12:34:56:00 After the data has been recorded, the following display SETUP LOG appears. A.IRIS Adjustments and DTL LEV M.BLACK...

  • Page 49: White Balance Adjustment

    White Balance Adjustment Arrange a white subject (paper, cloth, etc.) under To recall a white balance value from memory Color temperatures of different light sources Message Meaning and corrections to be made Before beginning shooting, set the W. BAL switch to the same lighting conditions as for shooting, and Light source Color temperature (K)
  • Page 50 The iris opened during adjustment or there is a hardware error. -NG- Close the iris and try again. If this fails, consult your Sony dealer. Move the POWER switch to the ON SAVE TRY AGAIN position, and check that the OUTPUT/DL/DCC+...
  • Page 51 Shutter speeds There are five shutter speeds, from s (DXC-D35/ To return from the basic menu to the normal D35WSL) or s (DXC-D35P/D35WSPL) to indications...
  • Page 52 Setting the Clock and Timestamping Recordings Use advanced menu page 8 to set the camera head’s Timestamping recordings internal clock and record the date and time. You can timestamp recordings by superimposing the Note current date and time. If the following date/time setting procedure for the internal clock does not cause the date/time information Before shooting, set the CLOCK IND to CAM in to be displayed in advanced menu page 8, it may be...

  • Page 53: Flange Focal Length Adjustment

    Do not move the focusing ring. For details, consult your Sony dealer. Repeat steps 6 to 9 until the image stays in focus Loosen the F.B fixing screw.

  • Page 54: Adjusting The Lens

    • When using a lens with an extender, set it to 2. • When using a lens with a ratio converter, set it to 2. ZEBRA switch You can also ask a Sony dealer more precise settings A.IRIS MODE switch according to your lens. In this case, set it to 4.

  • Page 55: Skin Detail Correction

    Shooting conditions The background is very bright, and the Set the A.IRIS MODE switch to BACK L, This lightens the foreground. The DXC-D35/D35P/D35WSL/D35WSPL provides subject is too dark. turning the indicator on. an easy push-button function that designates an active You can adjust the specified color using setup files.
  • Page 56 • Locations where the unit may be exposed to rain • Locations subject to violent vibration If you should experience problems with the unit, contact your supplier or Sony service representative. • Close to radio or TV transmitters producing strong electromagnetic fields.

  • Page 57: Important Notes On Operation

    (During other fault in the heads, disconnect the recording only) Monitor screen the recording power and consult your Sony system. dealer. — — SERVO The servo Recording Disconnect the power and...
  • Page 58 15.625 kHz (DXC-D35P/ 122 120 219.7 mm (4 REMOTE connector 2: 10-pin There is a range of Sony products available to meet D35WSP) inches) (with lens hood, MONITOR OUT connector: BNC, every conceivable video shooting requirement. For Vertical: 59.94 Hz (DXC-D35/...
  • Page 59 VA-90/90P + EVV-9000/9000P C-74 Condenser Microphone CAC-12 Microphone Holder CCQ-BRS cable VO-8800/8800P U-matic EC-0.5C2 Microphone Cable CCQJ-2 cable EC-0.3C2 Micorphone Cable VHS VTR CA-327/ DXC-D35/D35P/ 327P D35WS/D35WSP S-video cable Studio equipment Camera Hi-8/S-VHS VTR Adaptor CCU-M5/M5P/M5A/M5AP/M7/M7P Camera Control CAC-4 Chest Pad...

  • Page 60: Example System Configuration

    DVCAM Camcorder ClipLink video production differs from conventional recorded on the disk drive to the DSR-85/85P, or in the tape (DXC-D35/D35WS + video production. opposite direction when loading data backed up on the DSR-1 or DSR-135P) ClipLink log data: recorded in DSR-85/85P to the disk drive.

  • Page 61: Cliplink Operation Flow

    ClipLink Operation Flow Cue point time codes Data Generated When Shooting How to record ClipLink log data This type of data is especially useful when shooting scenes that may contain unexpected events, such as The following describes the kinds of data that is The following describes how to record the various when shooting for sports coverage or documentaries.
  • Page 62 ClipLink Operation Flow Time codes recorded for Mark IN/OUT points There is a gap between actual time codes and Mark IN/ OUT time codes recorded in the cassette memory, as shown in the figure below. The frame digit is incremented at each Mark IN point and is decremented at each Mark OUT point.

  • Page 63: Service Overview

    CN-1684 board PA-256 board IF-532 board PA-256A board IF-700 board CN-1194 board PR-216 board PR-240 board SW-792 board VA-169A board VA-185A board SW-793 board SW-790 board PA-255 board PA-255A board SW-791 board *1 : DXC-D35/D35P *2 : DXC-D35WS/D35WSP DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 64: Removal/Attachment Of Cabinet

    2-2. Removal/Attachment of Cabinet 2-2. Removal/Attachment of Cabinet 2-2-1. Removal of Side Plate Slacken the eight screws as shown in the figure and remove the right and left side plates. DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 65: Removal/Attachment Of Top Chassis

    4. Remove the three screws and take off the SW board in the horizontal direction. Supports Screws (B3 x 4) Connector layout on the MB-629/785 boards CN105 CN106 CN107 Screw (B3 x 4) CN103 CN117 Screws CN118 SW board (B3 x 4) CN120 CN119 CN121 CN123 CN122 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 66 MB board (K3 x 6) Rear plate Screw (B3 x 10) Screw (B3 x 10) Front unit assembly 10. To reattach, perform in the reverse order of steps 1 to Diagram of harness routing on the MB board DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 67: Replacement Of Ccd Unit

    Front unit assembly The CCD block number label is put in the CCD unit. Screws with washer GUA xxxxx : DXC-D35 (NTSC) (B3 x 10) GVA xxxxx : DXC-D35P (PAL) HDA xxxxx : DXC-D35WS (NTSC) HEA xxxxx : DXC-D35WSP (PAL)
  • Page 68 (in Section 3-3-13) and the flare alignment (in Section 3-3-14). . Before performing alignment, be sure to read each item in Section 3-1-4 “Note on Alignment”. . Reuse the transport holder to transport the CCD unit removed from the unit. DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 69: Connectores And Cables

    OUT VTR : 0 0.25 V Zo < 1 kZ CCU : 5.0 0.5 V A14 CHROMA (G) NTSC : 0.286 V p-p 10 % B14 CHROMA (X) OUT PAL : 0.300 V p-p 10 % Zo < 75 5 % DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 70 BYRY (8) Zo < 75 Z 5 % MIC1 (X) OUT _20 dBm, Zo < 100 Z CF/V RESET H : 4.0 to 5.5 V p-p, Zo < 2 kZ L : 0 0.4 V dc MIC1 (Y) DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 71 OUT GND for VF VIDEO BATT IND OUT Zo < 1.1 kZ VF VIDEO (X) OUT V = 1 V p-p POWER EXT DC OUT 10.6 V to 17.0 V dc GAIN UP IND OUT Zo < 1.1 kZ DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 72 OUT V = 5 V p-p LD (VF) OUT Zo < 500 Z, 5 V p-p (EXTERNAL VIEW) No. Signal Specifications MIC (G) GND for MIC MIC (X) _60 dB MIC (Y) BALANCED (0 dB = 0.775 V) 2-10 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 73: Connection Connector

    (8P, FEMALE) CABLE, VF AT-144 board LENS 1-564-360-11 CONNECTOR, 12P, MALE (12P, FEMALE) HIROSE HR 10-10PA-12P equality 1-508-084-31 CONNECTOR, 3P, MALE (3P, FEMALE) CANNON XLA-3-12C equality 1-778-661-11 CONNECTOR, 20P, MALE (20P, FEMALE) HIROSE HR 12-14PA-20PC equality 2-11 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 74: Replacement Way Of Rom (Ic102)

    A side. (Refer to Fig.1) 4. For attachment, press the IC socket cover in the S101-2 DXC-D35WS DXC-D35 reverse direction of arrow A until it clicks while S102: For factory adjustment holding the ROM. Use always with the setting OFF –...

  • Page 75: Dc-Dc Converter Voltage

    CN103-28 pin +6.5 V CN114-20 pin +3.1 V CN103-27 pin +16 V CN103-25 pin +5.3 V CN103-26 pin +32 V CN103-23 pin _5 V E1 (GND) CN103-22 pin +9 V MIC 2 pin/1 pin(GND) +48 V 2-13 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 76: Recommended Replacement Parts

    Fig No. Description Sony P/N Remarks PAD ASSY A-8278-807-C rubber FILTER UNIT, OPTICAL 1-547-985-11 for DXC-D35 FILTER UNIT, OPTICAL 1-547-985-21 for DXC-D35P FILTER UNIT, OPTICAL 1-758-131-11 for DXC-D35WS/D35WSP RACKING, CONTROL 3-672-221-02 rubber 2-14...

  • Page 77: Attaching The 4-Type Or 5-Type Viewfinder

    (DXF-50 series) can be attached in accordance VF connection cable with the following procedures: (20pin) Parts Required (sold separately) Shoe Fixing ring Stop screw Name Sony Part No. Guide plate . Accessory shoe kit A-8274-968-B Shoe 3-664-218-0X Plate spring 3-664-228-0X Stop screw...

  • Page 78: Disconnecting/Connecting The Flexible Card Wire

    1. Slide portion A in the direction of the arrow and insert the flexible card wire as far as it will go into connector with the contact surface of the wire put down. 2. Slide portion A in the opposite direction of the arrow and lock. 2-16 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 79: Service Mode Operation

    When the page of the selected menu is displayed, the normal operation for the menu is available. When exiting from the menu, the screen returns to the menu select screen. [Reference] eference] eference] eference] eference] The menu screen can be seen on the viewfinder or MONITOR OUT of this camera unit. 2-17 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 80: Service Menu

    MATRIX DETAIL APERTURE FLARE R TITLE G TITLE B TITLE R EDGE G EDGE B EDGE M.GAMMA R GAMMA B GAMMA M.BLACK 2070 2075 WHT CLIP HI L.SAT IRIS GAIN IRIS MODE IRIS SET LOW LIGHT 2-18 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 81 2-12. Service Mode Operation ..Page 1 RESET (For DXC-D35/D35WS) Adjusting values such as the electronic volume control of each board except PAGE1 (NEXT PREV the values differ in every unit can be restored to their standard setting RESET values.
  • Page 82 B-Y carrier balance adjustment R-Y BST B-Y BST B-Y burst level adjustment B-Y C/B B-Y BST VF SYNC Viewfinder video sync level adjustment VF SYNC VF BLKG VF BLKG Viewfinder video blanking level adjustment EXIT MENU (YES 2-20 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 83 SC-H phase adjustment SC FREQ 2550 SC-H EXIT MENU (YES ..Page 9 Various Setting 1 (For DXC-D35/D35WS) SETUP ON/OFF control of setup PAGE9 (NEXT PREV READ OUT FD (Field): CCD switches to Field read mode...
  • Page 84 Title’s B level (0/25/50/75) ABC123 R EDGE Title edge’s R level (0/25/50/75) EXIT MENU (YES G EDGE Title edge’s G level (0/25/50/75) B EDGE Title edge’s B level (0/25/50/75) ABC123 Indication for checking actual title color 2-22 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 85 IRIS MODE IRIS SET LOW LIGHT Setting of LOW LIGHT warning indication level LOW LIGHT For DXC-D35/D35WS : For DXC-D35P/D35WSP : 160 EXIT MENU (YES ..Page 17 Color Temperature Calculation Reference Setting COLOR TEMP CAL.
  • Page 86 EEPROM and microcomputer when the power is turned on, the backed up data in EEPROM on the MB board is used. The “DIAG ERROR RESET” and “MEMORY BACKUP” will be also carried out when the RESET in Service Menu Page 1 is execut- 2-24 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 87 This display item is not used. PR-G1 000H PR-R1 000H PR-G0 PR-G0 000H PR-R0 000H This display item is not used. PR-B1 000H PR-R0 EXIT MENU (YES This display item is not used. PR-B1 This display item is not used. 2-25 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 88 IC520 pin107 is abnormal. (The No.1 of Y signal) 001H : The connection between PR board IC411 pin83 and IF board IC520 pin108 is abnormal. (The No.0 of Y signal) *: DXC-D35WS/D35WSP do not have this function. 2-26 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 89 002H: The connection between PR board IC411 pin110 and IF board IC520 pin82 is abnormal. (The No.1 of CB signal) 001H: The connection between PR board IC411 pin109 and IF board IC520 pin83 is abnormal. (The No.0 of CB signal) 2-27 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 90 [Reference] [Reference] [Reference] [Reference] [Reference] The corresponding display for the data of each EEPROM on the service menu becomes a blank column, when the EEPROM on the TG, IF, ES and MB boards is abnormal. 2-28 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 91 B Carrier balance adjustment at DPR ON G D.DARK B D.DARK EXIT MENU (YES ..Page 26 Option Normally this item setting is OFF. PAGE26 (NEXT PREV OPTION1 OPTION2 EXIT MENU (YES 2-29 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 92: File Menu

    2-12. Service Mode Operation 2-12-2. File Menu DXC-D35/D35P Reset items and standard values to be set. Standard set value NO.1 NO.2 NO.3 NO.4 NO.5 NO.6 to 8 ITEM HISAT FILMLIKE SVHS/VHS USER1 to 3 M.BLACK STRETCH M.GAMMA DTL LEV V DTL LEV...
  • Page 93 2-12. Service Mode Operation Standard set value NO.1 NO.2 NO.3 NO.4 NO.5 NO.6 to 8 KNEE APT HIGH DTL CCS LEV STRP1 STRP2 PRSP1 PRSP2 2-31 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 94 R_B LEV NTSC G_R LEV NTSC G_B LEV NTSC B_R LEV NTSC B_G LEV NTSC R_G WIDTH R_B WIDTH G_R WIDTH G_B WIDTH B_R WIDTH B_G WIDTH LEVEL DEP V DTL LIM CRISP APERTURE AFT DTL 2-32 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 95 2-12. Service Mode Operation Standard set value NO.1 NO.2 NO.3 NO.4 NO.5 NO.6 to 8 KNEE APT HIGH DTL CCS LEV STRP1 STRP2 PRSP1 PRSP2 2-33 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 96 2-12. Service Mode Operation ..Page 1 All Reset (For DXC-D35/D35WS) Each item value in all FILE can be restored to their standard setting PAGE1 (NEXT PREV (factory setting). ALL RESET (YES DEST : UC EXIT MENU (YES...
  • Page 97 G-R coefficient center value setting R-B LEV G-B LEV G-B coefficient center value setting G-R LEV G-B LEV B-R LEV B-R coefficient center value setting B-R LEV B-G LEV B-G LEV B-G coefficient center value setting EXIT MENU (YES 2-35 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 98 ..Page 11 File Stretch Setting STRP1 BLACK STRETCH Point1 setting PAGE11 (NEXT PREV STRP2 BLACK STRETCH Point2 setting STRP1 PRSP1 BLACK COMPRESS Point1 setting STRP2 PRSP2 BLACK COMPRESS Point2 setting PRSP1 PRSP2 EXIT MENU (YES 2-36 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 99 ..Page 12 File Store FILE File name to be recalled PAGE12 (NEXT PREV DESTINATION FILE Selection of FILE STORE destination FILE STORE STORE FILE Performing of FILE STORE FILE :*HISAT DISTINATION FILE USER1 STORE FILE (YES EXIT MENU (YES 2-37 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 101: Electrical Alignment

    . Digital voltmeter . Oscilloscope (100 MHz or more) . Vectorscope . Waveform monitor . B/W monitor (Sony PVM-91/122 or equivalent) . Color monitor (Sony PVM-1320 or equivalent) . AC Adaptor (Sony CMA-8/8A/8CE/8ACE) . Camera Adaptor (Sony CA-537/537P) . Frequency counter .

  • Page 102: Setting Before Adjustment

    3-3-13. Shading Adjustment 3-3-14. Flare Adjustment . If the waveform to be measured is blurred and the amplitude level is not clear, set the FILTER switch on the waveform monitor to “LUM” or “LPASS” mode. DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 103: Maintaining The Grayscale Chart

    Adjust the position and angle of the light source so that the whole surface of the chart is evenly 2000 lx. Light the chart from almost the same direction and height as the camera to shoot the chart. DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 104 4. Adjust the luminance control of the pattern box so that the white portion in the center of the chart is 573 6 cd/m This corresponds to the luminous intensity on the 89.9 %-reflective chart at 2000 lx. Chart Luminance meter DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 105: Before Adjustment

    . Partial difference between scale and signal level is caused by photographic error. . If the specifications are not met, carry out from “3-3-2. INT SC Phase Adjustment” through “3-3-9. Chroma (YC) Level Adjustment”. . Use the vectorscope conforming to setup “7.5 IRE”. (for NTSC) DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 106: Camera Adjustment

    If any other equipment is used, perform adjustment at the 3-3-1. Sub-Carrier Frequency Adjustment following adjustment point by reading the instruction manual attached. Equipment: Frequency counter To be extended: ES-32 board (for DXC-D35/D35P) Equipment: Waveform monitor (SC-H Phase mode) Preparation: ES-33 board (for DXC-D35WS/D35WSP) Test point: .

  • Page 107: Y/R-Y/B-Y Clp Level Adjustment

    3-3-3. Y/R-Y/B-Y CLP Level Adjustment 3-3-4. Y/SYNC/R-Y/B-Y Level Adjustment Equipment: Oscilloscope Equipment: Oscilloscope To be extended: IF-532 board (for DXC-D35/D35P) To be extended: IF-532 board (for DXC-D35/D35P) IF-700 board (for DXC-D35WS/D35WSP) IF-700 board (for DXC-D35WS/D35WSP) Preparation: OUTPUT/DL/DCC + switch: BARS...

  • Page 108: Carrier Balance Adjustment

    C = 525 20 mV 100% B-Y LEV TP62 NTSC: D = 700 20 mV PAL: D = 525 20 mV W B-Y LEV TP62 NTSC: D = 700 20 mV PAL: D = 525 20 mV *: DXC-D35WS/35WSP only DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 109: Chroma (Vbs) Level Adjustment

    NTSC) /ES-32 board (DXC-D35/D35P) /ES-33 board (DXC-D35WS/D35WSP) Equipment: Verctorscope 1 FL502 (PHASE) To be extended: ES-32 board (for DXC-D35/D35P) /ES-32 board (DXC-D35/D35P) ES-33 board (for DXC-D35WS/D35WSP) Preparation: /ES-33 board (DXC-D35WS/D35WSP) 1 RV504 (CHROAMA VBS LEV) . GAIN switch/Verctorscope: 75 % CAL .

  • Page 110: Y (Vbs) Level Adjustment

    3-3. Camera Adjustment 3-3-7. Y (VBS) Level Adjustment 3-3-8. Y (YC) Level Adjustment Equipment: Waveform monitor To be extended: ES-32 board (for DXC-D35/D35P) Be sure that “3-3-7. Y (VBS) Level Adjustment” is ES-33 board (for DXC-D35WS/D35WSP) completed. Preparation: OUTPUT/DL/DCC+ switch: BARS...

  • Page 111: Chroma (Yc) Level Adjustment

    3-3-9. Chroma (YC) Level Adjustment 3-3-10. VF SYNC/BLKG Level Adjustment Equipment: Oscilloscope Equipment: Oscilloscope To be extended: ES-32 board (for DXC-D35/D35P) To be extended: ES-32 board (for DXC-D35/D35P) ES-33 board (for DXC-D35WS/D35WSP) ES-33 board (for DXC-D35WS/D35WSP) Preparation: OUTPUT/DL/DCC + switch: BARS...

  • Page 112: Ccd Output Level Adjustment

    (When using the pattern box, set to Auto mode.) Object: Grayscale chart Equipment: Oscilloscope To be extended: VA-165 board (for DXC-D35/D35P) VA-185 board (for DXC-D35WS/D35WSP) Preparation: . OUTPUT/DL/DCC+ switch: CAM/DCC + . W. BAL switch: PRESET RV1 (PA-256 board) . Select a large lens iris to shoot the gray scale chart covering fully the underscanned frame.

  • Page 113: Carrier Adjustment At Dpr (Double Pixel Reading) On

    Object: Overall white . OUTPUT/DL/DCC + switch: CAM/DCC + Equipment: Waveform monitor, Oscilloscope Test point: VIDEO OUT connector To be extended: VA-169 board (DXC-D35/D35P) VA-185 board (DXC-D35WS/D35WSP) Trigger: VD (TP73/EX-490 baord) Adjustment Procedure 1. SEVICE menu “PAGE25” Preparation: R D.DARK: [When replacing the CCD unit] G D.DARK:...

  • Page 114: Flare Adjustment

    5. Make the lens iris large by two steps. 6. Adjust the flare with UP and DOWN switches alternatively to minimize the carrier leakage level. CL301 CL101 CL201 VA-169 board (B side) (DXC-D35/D35P) VA-185 board (B side) (DXC-D35WS/D35WSP) 3-14 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 115: Mic Level/Mic Level Ind Adjustment

    4. Set the DOWN switch at the five-descending RV201 position from the point the mark disappears. CL201 C202 CV3 (DXC-D35WS/D35WSP only) MB-629 board (B side) (DXC-D35/D35P) MB-785 board (B side) (DXC-D35WS/D35WSP) 3-15 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 116: Character Position Adjustment

    CV3 (DXC-D35WS/D35WSP only) MARKER : CENT/90% LIMITS : OFF TONE ZEBRA ZEBRA1 : 70IRE TONE XXdB VF TALLY : x2 XXdB LENS SEL XXXX XXXX EXIT MENU (YES MB-629 board (B side) (DXC-D35/D35P) MB-785 board (B side) (DXC-D35WS/D35WSP) 3-16 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 117: Title Adjustment (Only For Dxc-D35Ws/D35Wsp)

    (for NTSC) [for NTSC] OPEN MENU (YES SERVICE TONE XXdB XXXX XX XX XX X:XX Magenta Red RV201 CL201 XX XX XX C202 X:XX MB-785 board (B side) (DXC-D35WS/D35WSP) 3-17 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 118: Changing The Standard Setting Values (Video Level)

    EZ MODE button: 2075 (for PAL) A.IRIS MODE: ATW button: ..Front Panel FILTER control: 1 (3200 K) SHUTTER switch: ..Lens IRIS: M (Manual) ZOOM: M (Manual) 3-18 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 119: Changing The Flare Compensation Setting Value

    G FLARE standard setting value = 5 3. Make the lens iris large by more two steps. 4. Adjust the “R FLARE” and “B FLARE” alternatively with the UP or DOWN switch in order to mini- mize the carrier leakage level. 3-19 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...

  • Page 120: Changing The Manual Knee/White Clip Setting Value

    W.CLIP standard setting value = 255 When reducing the white clip setting value, it is recom- mendable to change the former mentioned manual knee setting in order to keep the reproduction of the grayscale in the high luminance level part. 3-20 DXC-D35/D35WS(UC) DXC-D35P/D35WSP(CE) V1...
  • Page 122 DXC-D35 (UC) DXC-D35P (CE) DXC-D35WS (UC) Printed in Japan Sony Corporation DXC-D35WSP (CE) E 2000. 4 08 Communication System Solutions Network Company 9-955-214-11 ©2000...

This manual is also suitable for:

Dxc-d35wsDxc-d35wspDxc-d35p

Table of Contents
