InfiniScale® IV 36-Port QSFP 40 Gb/s
InfiniBand Switch User Manual
P/N:
IS5025D-1BRC, IS5025Q-1BFC, IS5025Q-1SRC, IS5025Q-1SFC, IS5025Q-1BRC, IS5025Q-2SRC,
IS5025Q-2BRC, IS5030Q-1BFC, IS5030Q-1SFC, IS5030Q-1BRC, IS5030Q-2BFC, IS5030Q-2SFC,
IS5030Q-2BRC, IS5035Q-1BFC, IS5035Q-1BRC, IS5035Q-2BFC, IS5035Q-2BRC, IS5035Q-1SFC,
IS5035Q-2SFC
Rev 3.4
www.mellanox.com
Advertisement
Table of Contents
Related Manuals for Mellanox Technologies IS5025D-1BRC
Summary of Contents for Mellanox Technologies IS5025D-1BRC
- Page 1 InfiniScale® IV 36-Port QSFP 40 Gb/s InfiniBand Switch User Manual P/N: IS5025D-1BRC, IS5025Q-1BFC, IS5025Q-1SRC, IS5025Q-1SFC, IS5025Q-1BRC, IS5025Q-2SRC, IS5025Q-2BRC, IS5030Q-1BFC, IS5030Q-1SFC, IS5030Q-1BRC, IS5030Q-2BFC, IS5030Q-2SFC, IS5030Q-2BRC, IS5035Q-1BFC, IS5035Q-1BRC, IS5035Q-2BFC, IS5035Q-2BRC, IS5035Q-1SFC, IS5035Q-2SFC Rev 3.4 www.mellanox.com...
- Page 2 QUALITY. ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT ARE DISCLAIMED. IN NO EVENT SHALL MELLANOX BE LIABLE TO CUSTOMER OR ANY THIRD PARTIES FOR ANY DIRECT, INDIRECT, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES OF ANY KIND (INCLUDING, BUT NOT LIMITED TO, PAYMENT FOR PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;...
-
Page 3: Table Of Contents
Conventions ..........10 Mellanox Part Numbering Legend .......11 Chapter 1 Overview . - Page 4 4.3.2 Current Firmware Revision........44 4.3.3 How to Get Mellanox Firmware Tools (MFT) ..... . 48 4.3.4 Open SM .
-
Page 5: List Of Figures
Figure 35: Rack Rail Kit Parts MIS00083/85 ........62 Figure 36: Which Side of the Rack Do You Want the Connectors? ....63 Mellanox Technologies... - Page 6 Figure 52: Connect Bracket to Rack Vertical support ......71 Mellanox Technologies...
-
Page 7: List Of Tables
Table 15: Replacement Parts Ordering Numbers ....... .75 Mellanox Technologies... -
Page 8: Revision History
July 2010 Rev 1.9.1 Added “QSFP Cable Power Budget Classification” June 2010 Rev 1.9 • Added section Getting the License • Added Note “Each Ethernet connector gets connected to Ethernet switches. These switches must be configured to 10/100M auto-negotiation.” Mellanox Technologies... - Page 9 Fixed Status Fan LED info on page 13. Added to Troubleshooting section. Updated power numbers Added IS5025Q-2SRC, IS5025Q-2BRC model numbers September 2009 Rev 1.2 Added Spec sheets for IS5025 and IS5035 updated revision table September 2009 Rev 1.1 Updated power numbers September 2009 Rev 1.0 Initial Release Mellanox Technologies...
-
Page 10: About This Manual
Rev 3.4 About this Manual This manual describes the installation and basic use of the Mellanox IS50XX switch, which is based on the InfiniScale IV InfiniBand switch device. Intended Audience This manual is intended for users and system administrators responsible for installing and setting up the switch platforms listed above. -
Page 11: Mellanox Part Numbering Legend
QDR InfiniBand Switch Platform User Manual Rev 3.4 Mellanox Part Numbering Legend Place Field Decoder Mellanox Technologies System Type InfiniScale Switch Model Family Form factor 25 = 36 Ports Unmanaged 30 = 36 Ports and Chassis Management 31 = 18 ports and Chassis Management ... -
Page 12: Chapter 1 Overview
Enterprise Data Centers, High-Performance Computing and Embedded environments. Networks built with IS50XX systems can carry converged traffic with the combination of assured bandwidth and granular quality of service. Built with Mellanox’s 4th generation InfiniScale® IV InfiniBand switch device, IS50XX systems provide up to 40Gb/s full bidirectional bandwidth per port. -
Page 13: License Key
1.1.3 License Key This switch comes with a license for FabricIT. The license key to activate the license is found on the bottom side of the pull out tab. Figure 3: License Key Label License Key: LK2‐EFM‐CONFIG‐5G2L‐S5HG‐ L0KA‐L64Q‐K6D2‐Q60Q‐3ADH‐ G88A‐1H3Q‐7FT9‐5M Mellanox Technologies... -
Page 14: Chapter 2 Internally Managed Vs. Externally Managed
Flash and EEPROM. Update the FW on unmanaged switches in-band only. When new FW is available you will receive an e-mail with the link to the Mellanox FW download site. The download site has the Mellanox FW tool package and full instructions for updating FW. -
Page 15: Chapter 3 Basic Operation And Installation
• The PSU LED for the second PSU should light up green only if a second PSU is installed in the switch for redundancy and Hot-Swap ability and it is connected to a power source. If two PSUs are installed and only one PSU is connected to a power sup- Mellanox Technologies... -
Page 16: Figure 5: Power, Fan, And System Leds
If the PSU LEDs are not green, this indicates a problem with the power supplies. Only run the switch if at least one of the PSU LEDs is green. Figure 5: Power, Fan, and System LEDs STATUS PSU 1 PSU 2 Mellanox Technologies... -
Page 17: Figure 6: System Health Led
No power to the port. Solid Green Logical link up Flashing Green Data activity flashing speed ≈ data transfer speed Orange Physical link up Flashing Orange A problem with the physical link Usually the SM is down or not enabling the port. Mellanox Technologies... -
Page 18: Figure 7: Is5030-2Brc Qsfp Power Side Panel
Off – The fan unit is not receiving any power. Check that the fan unit is properly and completely inserted. Figure 5 on shows the explanation of the PSU Status LED colors. page 16 Mellanox Technologies... -
Page 19: Reset Button
On the connector side panel under the system LEDs is a reset button. This reset button requires a tool to be pressed. DO NOT use a sharp pointed object such as needle or push pin for pressing the Reset button. Sharp objects can cause damage, use a flat object to press this reset button. Mellanox Technologies... -
Page 20: Air Flow
• Power side inlet to connector side outlet The air flow is specified in the product model number. See “Mellanox Part Numbering Legend” on page 11. On the switch and fan modules the air flow direction can be seen on the power side panel. -
Page 21: Qsfp Cable Power Budget Classification
The Connector side of the switch has 36 QSFP ports. These are placed in two rows, 18 ports to a row. The ports are labelled as shown in Figure 10. The bottom row ports are flipped from the top row. See Figure 11 for bottom row - top row port orientation. Mellanox Technologies... -
Page 22: Management And Fw Updating Interfaces
Installation Guide, “Configuring the Switch for the First Time”, must be done before any remote management is available. For the Socket pinout see “RJ45 CONSOLE Inter- face” on page 74. This connector is not found in unmanaged (externally managed) switches. Mellanox Technologies... -
Page 23: Figure 13: Rj45 I2C Connector
3.4.2.2 RJ-45 Connector (I2C) Externally Managed Switches only Figure 13: RJ45 I2C Connector IS5025 All firmware updates should be done in-band using Mellanox Firmware Management Tools. This interface is for FAEs and advanced This interface is for Debug and Troubleshooting only. -
Page 24: Package Contents
The unmanaged (externally managed) switch platform does not require any programming or con- figuration to operate as a basic InfiniBand switch and includes all of the necessary functionality to operate with external standard InfiniBand Subnet Management software. Mellanox Technologies... -
Page 25: Installation Safety Warnings
5. During Lightning - Electrical Hazard During periods of lightning activity, do not work on the equipment or connect or dis- connect cables. Mellanox Technologies... -
Page 26: Mechanical Installation
The power side of the switch includes a hot-swap power supply module, a blank cover for an optional second PSU for redundancy, and a hot-swap fan tray. There are two possible air flow directions. Be sure that the switch air flow direction is compatible with your system, rack, and Mellanox Technologies... - Page 27 19” rack whose vertical supports are between 500mm and 800mm apart. The standard depth switch uses the MIS000085 rail kit for installation in a 19” rack whose verti- cal supports are between 500mm and 800mm apart. Mellanox Technologies...
-
Page 28: Figure 14: Rack Rail Kit Parts Mis00083/85
For standard depth switches rail kit # MIS00085 is to be used for racks from 60cm to 80cm deep. Parts included in the rail kit: • 2 rails • 18 recessed flat head screws • 2 rail slides • 8 caged nuts • 2 brackets • 8 pan head screws M6 Mellanox Technologies... -
Page 29: Figure 15: Rack Rail Kit Parts Mis000079
• Do you want the connector side recessed in the rack to allow for a larger cable bending radius? • Will the connector side be recessed past other equipment in the rack and will this be prob- lematic? Mellanox Technologies... -
Page 30: Figure 16: Installation Options Available For Short Switches
Connector side Spine side Switch Switch Spine side Connector side Doors Doors Installation A Installation B Standard switches only support installation with the connector side of the switch near the rack door, as per installation B in Figure 17. Mellanox Technologies... -
Page 31: Figure 18: For Short Switches Which Side Of The Rack Do You Want The Connectors
3. Screw the brackets onto the switch. Use the flat head screws to connect the bracket. There are two options for mounting the bracket. One option will place the switch even with the vertical support of the rack and the second option will recess the switch further into the rack. If you Mellanox Technologies... -
Page 32: Figure 19: Making Room For The Power Cord
Place to put the power cable. Option A will require 3 flat head Option B will require 4 flat head screws screws This configuration also allows you to put the power cord through the bracket. Mellanox Technologies... -
Page 33: Figure 21: Screwing On The Rail
8. Tighten the bolts to 9.2 Nm or 81.5 pound inches. If the power cable is on this side of the switch, feed the power cable into the slot in the rail slide before screwing it to the vertical sup- port. Mellanox Technologies... -
Page 34: Grounding The Switch
Test the ground using an Ohm meter. Some national and/or local codes may require IT components to be bonded and exter- nally grounded (not including the power cord ground). You must follow all national and local codes when installing this equipment. Mellanox Technologies... -
Page 35: Power Connections And Initial Power On
Caution: When turning off the switch, make sure ALL LEDS are off to ensure a powered down status. Mellanox Technologies... -
Page 36: Extracting And Inserting The Power Supply Unit
Fan module airflow must coincide with the airflow of all of the PSUs. If the PSU airflow direction is different from the fan module airflow direction the system will shut down. Figure 26: Power Supply Unit Extraction Latch Release Mellanox Technologies... -
Page 37: Infiniband Cable Installation
When a logical connection is made the yellow light will come on. When data is being transferred the yellow light will blink. Cables in the bottom row should be inserted upside down in relation to the how the cables are inserted in the top row. Mellanox Technologies... -
Page 38: Extracting And Inserting The Fan Unit
These air flow labels must be the same To extract a Fan Unit 1. Using two hands, push both latch releases simultaneously while pulling the fan module out of the switch. As the fan unseats, the fan status indicator will turn off. Mellanox Technologies... -
Page 39: Disassembly Of The Switch From The Rack
Support the weight of the switch when you remove the screws so that the switch does not fall. 5. Slide the switch from the rack. 6. Remove the rail slides from the rack. 7. Remove the eight caged nuts. Mellanox Technologies... -
Page 40: Disposal
Basic Operation and Installation Disposal For proper disassembly instructions to comply with the WEEE Directive 2002/96/EC see the Mellanox website. According to the WEEE Directive 2002/96/EC, all waste electrical and electronic equipment (EEE) should be collected separately and not dis- posed of with regular household waste. -
Page 41: Chapter 4 Management And Tools Overview
10/100M auto-negotiation. Network Management and Clustering Software Download and install, on all nodes, the Mellanox OpenFabric software package for Linux, Win- dows, or other operating systems from the Mellanox software website: http://www.mellanox.com.=> Downloads => InfiniBand SW/Drivers. -
Page 42: Fabric Management With Ufm
4.2.2 Fabric Management with UFM For an added licensing fee you can purchase Mellanox's Unified Fabric. UFM is a powerful plat- form for managing scale-out computing environments. it enables data center operators to effi- ciently monitor and operate the entire fabric, boost application performance and maximize fabric resources utilization. -
Page 43: Configuring The Switch For The First Time
=> Downloads => Firmware. Be sure to read and follow all of the instructions regarding the updating of the firmware on your switch system. Firmware for the HCA cards connected to this switch system can be downloaded from the same site. Mellanox Technologies... -
Page 44: Unmanaged (Externally Managed) Switch
Rev 3.4 Management and Tools Overview Unmanaged (Externally Managed) Switch When using Mellanox 5025 (Unmanaged) switch as the single switch in the fabric, the switch requires a host based management solution. 4.3.1 I2C Connector The I2C connection provides access to Flash and EEPROMs. This connection allows access to the switch for updating FW when in-band FW updating is impossible. - Page 45 The “mst ib add” runs the ibdiagnet/ibdiscover tool to discover the InfiniBand fabric and then lists the discovered IB nodes as an mst device under /dev/mst/ directory. These devices can be used for access by other MFT tools. [root@mymach]> mst ib add Mellanox Technologies...
- Page 46 This interface is for Debug and Troubleshooting only. users only. The I2C connector should only be used when the firmware cannot be updated in-band. Use the MTUSB-1 adapter (available from Mellanox) to reprogram the switch firmware using a server or PC running MFT. Mellanox Technologies...
-
Page 47: Figure 32: Mtusb-1 With Cables
• "mtusb-1" mst device appears in "mst status" 2. Set the switch I2C switch to allow access by running: > mlxi2c -d /dev/mst/mtusb-1 -s IS5025 p /IS4 3. Run the burn command: flint -d /dev/mst/mtusb-1 -i ./fw-IS4-rel-7_0_142-Q_A1.bin -qq b Mellanox Technologies... -
Page 48: How To Get Mellanox Firmware Tools (Mft)
When you buy the switch, it comes with the latest firmware burned on the board. All firmware updates should be done through the management software. Go to the Mellanox Website and con- firm that the firmware is the latest. If not reburn the latest firmware from the download site. New firmware versions will be posted on the Mellanox firmware download page:... -
Page 49: Chapter 5 Troubleshooting
Status LED and or Status Health LED If either of these two LEDs is unplug the switch and call your Mellanox representative. Power supply unit: If the LED on the PSU is not lit or is red, check that the power cable is plugged into a working outlet. - Page 50 AMCC PowerPC 460EX Rev. A at 1000 MHz (PLB=200, OPB=100, EBC=100 MHz) Security/Kasumi support Bootstrap Option H - Boot ROM Location I2C (Addr 0x52) Internal PCI arbiter disabled 32 kB I-Cache 32 kB D-Cache Board: Mellanox PPC460EX Board FDEF: No I2C: ready DRAM: 2 GB (ECC enabled, 400 MHz, CL3)
- Page 51 QDR InfiniBand Switch Platform User Manual Rev 3.4 5. Select the image to boot. Mellanox Technologies...
-
Page 52: Appendix A Specification
7.6 W Temperature: SerDes Speeds: Humidity: 94.0 CFM 2.0W Shock and Connector Types: Vibration: 10, 20, or 40,Gb/s per port 10° to 45° Celsius QSFP 10% - 90% non-condensing ETSI EN 300 019-2-2: 1999-09 Protocol Support Regulatory Compliance Mellanox Technologies... - Page 53 Simultaneous wire-speed any port to Fan Module and any port Switching Capacity: 1+1 Redundant: Power Supplies 1.44Tb/s for 36 ports QDR 720 Gb/s for 36 ports DDR 720 Gb/s for 18 ports QDR 360 Gb/s for 18 ports DDR Mellanox Technologies...
-
Page 54: Table 11: Is5030 Specification Data
EU: EN61000-3-3, Class Environmental: Japan: VCCI, Class A EU: IEC 60068-2-64: Ran- Acoustic: dom Vibration EU: IEC 60068-2-29: Shocks, Type I / II Sound power level: EU: IEC 60068-2-32: Fall Test ISO 7779 ETS 300 753 76 dB(A) Mellanox Technologies... - Page 55 Fan Module and Simultaneous wire-speed any port to Hot-Swappable: any port Power Supplies Switching Capacity: 1+1 Redundant: 1.44Tb/s for 36 ports QDR 720 Gb/s for 36 ports DDR 720 Gb/s for 18 ports QDR 360 Gb/s for 18 ports DDR Mellanox Technologies...
-
Page 56: Table 12: Is5035 Specification Data
EU: EN61000-3-3, Class Environmental: Japan: VCCI, Class A EU: IEC 60068-2-64: Ran- Acoustic: dom Vibration EU: IEC 60068-2-29: Shocks, Type I / II Sound power level: EU: IEC 60068-2-32: Fall Test ISO 7779 ETS 300 753 76 dB(A) Mellanox Technologies... -
Page 57: Emc Certifications
§ 15.21 Statement Warning! Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Mellanox Technologies) could void the user's authority to operate the equipment. §15.105(a) Statement NOTE: This equipment has been tested and found to comply with the limits for a Class A digi- tal device, pursuant to Part 15 of the FCC Rules. -
Page 58: En Statements (Europe)
A.2.3 ICES Statements (Canada) Class A Statement: “This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.” Mellanox Technologies... -
Page 59: China Ccc Warning Statement
QDR InfiniBand Switch Platform User Manual Rev 3.4 China CCC Warning Statement VCCI Statements (Japan) Class A Statement: Mellanox Technologies... -
Page 60: Mic Certification (Korea)
Class A Device This device is registered for EMC requirements for industrial use. The seller or buyer should be aware of this. If this type was sold or purchased by mistake, it should be replaced with a residential-use type. Mellanox Technologies... -
Page 61: Appendix B Passing The Power Cord From The Connector Side To The Power Side
Parts included in the installation kit: • 2 rails • 8 recessed flat head screws • 2 rail slides • 4 caged nuts • 8 pan head screws M6 • 2 metal washers Figure 34: Rack Installation Kit Parts rail rail slide Mellanox Technologies... -
Page 62: Figure 35: Rack Rail Kit Parts Mis00083/85
IB connectors can be even with the vertical rack support. The other side of the switch will be further inside of the rack. Things to consider before choosing where to mount the rails and rail slides. Mellanox Technologies... -
Page 63: Figure 36: Which Side Of The Rack Do You Want The Connectors
4. Clip the nuts into the holes in the rack you will be using to connect the rail slides. Check that both sides of the switch are in the same position number on the rack. Mellanox Technologies... -
Page 64: Figure 38: Caged Nut Spacing
# MIS00079 is to be used for racks from 38cm to 50cm deep including the iDataPlex rack. For standard depth switches rail kit # MIS00085 is to be used for racks from 60cm to 80cm deep. Mellanox Technologies... -
Page 65: Figure 40: Rack Rail Kit Parts Mis000079
2. Choose which side of the switch you want close to the rack vertical support. Either the side with the power supply units or the side with the IB connectors can be close to one of the ver- tical rack supports. Things to consider before choosing where to mount the rails and rail slides. Mellanox Technologies... -
Page 66: Figure 41: Which Side Of The Rack Do You Want The Connectors
• Do you want the connector side recessed in the rack to allow for a larger cable bending radius? • Will the connector side be recessed past other equipment in the rack and will this be prob- lematic? Mellanox Technologies... -
Page 67: Figure 42: Full Rack
1. Clip the 4 caged nuts into the holes in the rack you will be using to connect the rail slides. Check that both sides of the switch, left and right, are the same level in the rack. Figure 43: Inserting the Caged Nuts The caged nuts are separated by a single space Mellanox Technologies... -
Page 68: Figure 44: Put The Cables Through The 1U Space
Rev 3.4 Figure 44: Put the Cables Through the 1U Space 2. Install the rail slides placing the power cords through the slots. Figure 45: Placing the Power Cords Mellanox Technologies... -
Page 69: Figure 46: Power Cord Through The Rail Slide
Place to put the power cable. In this position you will use 3 In this position you will use 4 flat head screws flat head screws This configuration also allows you to put the power cord through the bracket. Mellanox Technologies... -
Page 70: Figure 48: Making Room For The Power Cord
4. Slide the switch into the rack and catch the rail slides into the rails. Note: Before putting the switch in place guide the power cords through the slots in the brackets. Figure 50: Power Cord Through the Bracket Mellanox Technologies... -
Page 71: Figure 51: Power Side View
Warning: Any yellow status LEDs is cause for concern and must be dealt with immediately. It can take up to 3 minutes to boot up, during which time the status LED may indicate red. 5. You can start connecting all of the cables to the switch. Mellanox Technologies... -
Page 72: Appendix C Qsfp Interface
Ground Rx4n Receiver Inverted Data Output 3 Rx4p Receiver Non-Inverted Data Out- put 3 Ground ModPrsL Module Present IntL Interrupt Vcc Tx +3.3 V Power supply transmitter Vcc 1 +3.3 V Power Supply LPMode Low Power Mode Ground Mellanox Technologies... - Page 73 QDR InfiniBand Switch Platform User Manual Rev 3.4 18.35 View into Rear of Connector 8.50 18.35 View into Front of Cage 8.50 Mellanox Technologies...
-
Page 74: Appendix D Rj45 Console Interface
Pin 1 TXD- TXD+ RJ45_RTS# RJ45_RTS# RXD+ RJ45_DTR# TXD- RJ45_DTR# RJ45_TXD RXD- RXD+ RJ45_TXD RJ45_RXD Bl/W Pin 8 RXD- RJ45_RXD Br/w Looking into the Socket TXD+ Pin 1 TXD- RJ45_SDA RXD+ RXD- RJ45_SCL Pin 8 Looking into the Socket Mellanox Technologies... -
Page 75: Appendix E Replacement Parts Ordering Numbers
Power cord Type G for UK ACC000208 Power cord Type D for India ACC000209 Power cord Type I for China ACC000210 Power cord Type J for Switzerland ACC000211 Power cord Type B for Japan, ACC000212 Power cord Type I for Australia ACC000213 Mellanox Technologies... -
Page 76: Appendix F Avertissements De Sécurité D'installation (French)
7. Montage et entretien sur baie Lorsque ce produit est monté ou entretenu sur baie, il faut prendre des précau- tions spéciales pour s’assurer que le système reste stable. En général, il faut remplir la baie avec du matériel de bas en haut. Mellanox Technologies... - Page 77 L’élimination de ce matériel doit s’effectuer dans le respect de toutes les légis- lations et réglementations nationales en vigueur. 10. Codes électriques locaux et nationaux Ce matériel doit être installé dans le respect des codes électriques locaux et nationaux. Mellanox Technologies...
-
Page 78: Appendix G Installation - Sicherheitshinweise (German)
Vorsichtsmaßnahmen zu ergreifen, um die Stabilität des Systems zu gewährleisten. Im Allgemeinen sollten Sie das Gestell von unten nach oben mit Geräten füllen. 8. Geräteinstallation Diese Gerät sollte nur von geschultem und qualifiziertem Personal installiert, ausgetauscht oder gewartet werden. Mellanox Technologies... - Page 79 QDR InfiniBand Switch Platform User Manual Rev 3.4 9. Geräteentsorgung Die Entsorgung dieses Geräts sollte unter Beachtung aller nationalen Gesetze Bestimmungen erfolgen. 10. Regionale und nationale elektrische Bestimmungen Dieses Gerät sollte unter Beachtung der regionalen und nationalen elektrischen Bestimmungen installiert werden. Mellanox Technologies...
-
Page 80: Appendix H Advertencias De Seguridad Para La Instalación (Spanish)
Al instalar o realizar el mantenimiento de este aparato en un bastidor, es preciso adoptar precauciones especiales para garantizar que el sistema se mantenga estable. En general, en un bastidor, los equipos se deben insta- lar comenzando desde abajo hacia arriba. Mellanox Technologies... - Page 81 300 voltios nominal, con cobertura protectora aislante de PVC. El cable debe tener un enchufe moldeado con capuchón de 250 voltios nomi- nal, 10 A. ADVERTENCIA: Alta corriente de fuga. Es esencial efectuar la conexión a tierra antes de conectar la alimentación. Mellanox Technologies...
- Page 82 (EEE) se deben recolectar por separado y no se deben eliminar junto con residuos domésticos. Al deshacerse de este producto y de todas sus partes, hágalo de una manera res- ponsable y respetuosa con el medio ambiente. Mellanox Technologies...
-
Page 83: Appendix I Special Regulations Regarding Finland, Sweden, Denmark, And Norway
Do not connect this unit to any outlet that is not fully grounded! • Finland “Laite on liitettävä suojamaadoituskoskettimilla var- ustettuun pistorasiaan” • Norway “Apparatet må tilkoples jordet stikkontakt” Unit is intended for connection to IT power systems for Norway only. • Sweden “Apparaten skall anslutas till jordat uttag.” Mellanox Technologies...
