  • Page 1 OD-300CAM 1/4 CMOS Dual Stream Outdoor IR IP Camera User’s Manual...

  • Page 2: Declaration Of Conformity

    5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien City, Taipei County, Taiwan Declare that the product 1/4 CMOS Dual Stream Outdoor IR IP Camera AirLive OD-300CAM is in conformity with In accordance with 2004/108 EEC-EMC Directive and 1999/5 EC-R & TTE Directive Clause Description ■...
  • Page 3 Directiva 1999/5/CE. disposiciones aplicables o exigibles de la Directiva 1999/5/CE. ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ OvisLink Corp. ΔΗΛΩΝΕΙ OvisLink Corp izjavlja, da je ta AirLive OD-300CAM v Ελληνική [Greek] ΟΤΙ AirLive OD-300CAM ΣΥΜΜΟΡΦΩΝΕΤΑΙ Slovensko skladu z bistvenimi zahtevami in ostalimi relevantnimi ΠΡΟΣ...

  • Page 4: Federal Communication Commission Interference Statement

    20 cm spacing must be provided between computer mounted antenna and person’s body (excluding extremities of hands, wrist and feet) during wireless modes of operation. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two AirLive OD-300CAM User’s Manual...
  • Page 5 Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the Netherlands, Portugal, Spain, Sweden, and the United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland. EU Countries Not intended for use None. AirLive OD-300CAM User’s Manual...

  • Page 6: Table Of Contents

    OD-300CAM Outdoor 15M IR IP Camera - Contents – CHAPTER1: MINIMUM SYSTEM REQUIREMENT ......4 CHAPTER2: USING IP CAMERA VIA WEB BROWSER ....5 2.1 Camera Installation ........................6 CHAPTER3: USING IP CAMERA VIA MOBILE PHONE ....10 CHAPTER4: CONFIGURATION OF MAIN MENU ......11 4.1 Live View .............................

  • Page 7: Chapter1: Minimum System Requirement

    IP Installer. (For Windows 98, ME or 2000 server, the codec might not work properly. You’ll need to download Xvid codec 1.0 from the internet. 3. Please always update the latest Windows component. (.Net Framework, Windows Media Player, Enhance ActiveX Security) AirLive OD-300CAM User’s Manual...

  • Page 8: Chapter2: Using Ip Camera Via Web Browser

    2. Use the default account “admin” and default password “admin”. Note: The default user name “admin” and the password are set at the factory for the administrator. You can change them in the Account Menu (Please check“Setting → Basic → Security → Account”) AirLive OD-300CAM User’s Manual...

  • Page 9: Camera Installation

    Setting, Client Setting, and Image Setup. For more details, you can check Chapter 5.2、Chapter 5.3、Chapter 5.4. 2.1 Camera Installation 1. Insert CD into your PC/Laptop 2. Auto Run Screen then shows up, click “setup wizard” to install the configuration tool software AirLive OD-300CAM User’s Manual...
  • Page 10 4. The Software scans the network and finds the IP Camera, then list in the dialog box. 5. If the Camera’s IP address is in the same IP segment as your LAN, select the founded IP Camera and click “Link to IE” to proceed. AirLive OD-300CAM User’s Manual...
  • Page 11 Note that the text color of the listed IP Camera is red if it is not in same the IP segment with your PC. 7. Follows setup instruction to change the IP address of the IP Camera. AirLive OD-300CAM User’s Manual...
  • Page 12 10. Click “Link to IE” to proceed. 11. The tool launch your Internet Explorer and prompts up the login dialog 12. Enter default user name and password: admin / airlive 13. After a successful login, the browser asks for ActiveX installation.

  • Page 13: Chapter3: Using Ip Camera Via Mobile Phone

    <IP> is the Public IP address of your IP camera. 3. 2.5G Mobile Phone Browser Viewing For 2.5G mobile phone viewing, type “ ” into your 2.5G Web Browser. <IP>/mobile.htm <IP> is the Public IP address of your IP camera. AirLive OD-300CAM User’s Manual...

  • Page 14: Chapter4: Configuration Of Main Menu

    Chapter 4.2、Chapter 4.3、Chapter 4.4. In your right hand side, you can use Live View in your main Browser. There are Snapshot, Zoom and Audio and Video Play four different function. You can see more details as follow. AirLive OD-300CAM User’s Manual...

  • Page 15: Live View

    Pull the to adjust the digital zoom range, and it will be showed on the above window.  You can use the left click of your mouse to move the to any where on the window. AirLive OD-300CAM User’s Manual...
  • Page 16 IP camera(s) Speakers turned off mean you can broadcast to the connected IP Microphone turned on camera(s) via the Ethernet using your microphone Microphone turned off Volume control bar AirLive OD-300CAM User’s Manual...

  • Page 17: Setting

    Click Advance folder, there are four sub-folders including FTP Client, SMTP, HTTP event, Schedule, Motion Detection, and System Log. For more information, you can see Chapter 6.1、Chapter 6.2、Chapter 6.3、Chapter 6.4、Chapter 6.5、Chapter 6.6、 Chapter 6.6、Chapter 6.6 and Chapter 6.9. AirLive OD-300CAM User’s Manual...

  • Page 18: Client Setting

    Select the transferring protocol from TCP, UDP, HTTP and Multicast. 4.3.4 Video Buffer Turn the Video Buffer function On / Off. The Video Buffer function makes the streaming more smoothly in unsteady network environment, but might cause a little delay in live viewing. AirLive OD-300CAM User’s Manual...

  • Page 19: Image Setup

    Hue is one of the three main attributes of perceived color, affected by different wavelength of color. Withhigher value of hue, color will be much more vivid. 4.4.5 Default After the adjustment of all setting, you can still click Default to make the setting back to the original setting. AirLive OD-300CAM User’s Manual...

  • Page 20: Chapter5: Setting-Basic

    Chapter5: Setting-Basic Click the folder of Basic to display the sub folders including System, Camera, Network, and Security. AirLive OD-300CAM User’s Manual...

  • Page 21: System

    5.1 System Click the folder of System to display the sub-folders including Information, Date / Time, and Initialize. AirLive OD-300CAM User’s Manual...
  • Page 22 5.1.1 Information The Information page provides the product factory information which includes Product Name, Firmware Version and Web Version. AirLive OD-300CAM User’s Manual...
  • Page 23 The NTP server (Network Time Protocol) is the time server which is an Internet standard protocol built on the top of TCP/ IP. This assures accurate synchronization to the millisecond of computer clock times in a network of computers. AirLive OD-300CAM User’s Manual...
  • Page 24 Don't turn off the IP Camera power or disconnect the network until the upgrading is completed.  Upload Language Pack: Upgrade the device language pack. Click “Browse” and select the file for upgrading. A confirmation dialogue will appear. Click “OK” to start upgrading. The upgrade is applied AirLive OD-300CAM User’s Manual...

  • Page 25: Camera

    The default language is “English”. 5.2 Camera Click the folder of Camera to display the sub folders including General, MPEG4 and MJPEG. AirLive OD-300CAM User’s Manual...
  • Page 26 Text Overlay: You can see some information on the display screen which includes Date / Time and user-defined text. Also, you can change the background color.  Privacy Mask: You can cover a specific area of the video image. AirLive OD-300CAM User’s Manual...
  • Page 27 704 x 480, 352 x 240, and 176 x 120 for NTSC mode or 704 x 576, 352 x 288, and 176 x 144 for PAL mode.  Frame Rate: Set the frame rate of the MPEG4 image. You can choose values from 5, 10, 15, 20, AirLive OD-300CAM User’s Manual...
  • Page 28 Fixed Quality: You can select the value of quality among Medium, Good, Delicate and Excellent.  Fixed Bitrate: Set the bitrate of MPEG4 image transmission for a line. You can select the values from 64, 128, 256, 384, 512, 768, 1024, 1280, 1536, and 2048 kbps. AirLive OD-300CAM User’s Manual...
  • Page 29  Frame Rate: Set the frame rate of the MPEG4 image. You can choose values from 5, 10, 15, 20 fps. The unit “fps” stands for “frames per second”.  Quality:  Fixed Bitrate: Set the bitrate of MPEG4 image transmission for a line. You can select the value from 64, 32, 16 kbps. AirLive OD-300CAM User’s Manual...
  • Page 30  Frame Rate: Set the frame rate of the MJPEG image. You can choose values from 5, 10, 15 fps. The unit “fps” stands for “frames per second”.  Quality:  Auto: The quality will be automatically decided.  Fixed Quality: You can select the value of quality among Medium, Standard, Good, Delicate and Excellent. AirLive OD-300CAM User’s Manual...

  • Page 31: Network

    5.3 Network Click the folder of Network to display the sub folders including Information, PPPoE, DDNS, UPnP, IP Notification, and Messenger. AirLive OD-300CAM User’s Manual...
  • Page 32  Obtain an IP address automatically (DHCP): If a DHCP server is installed on the network, to select this while the IP address is assigned by the DHCP server.  Obtain DNS server address automatically: Select this to obtain the address of DNS server automatically. AirLive OD-300CAM User’s Manual...
  • Page 33 Setup Program, access the device by typing the IP address of the device on the web browser as follows: Example: when HTTP port number is set to 2000 http://192.168.1.100:2000/ Note: The IP Camera needs to be rebooted after it finishes changing the network setting completely. AirLive OD-300CAM User’s Manual...
  • Page 34  Password: Enter the password for authentication necessary for PPPoE connections. Type it up to 32 characters.  Re-type password: Re-type the password to confirm.  Obtain DNS server address automatically: Select this to obtain the address of DNS server automatically. AirLive OD-300CAM User’s Manual...
  • Page 35 ADSL, VDSL or SDSL) 2. The IP Camera needs to be rebooted after it finishes changing the network completely. 3. The IP Camera with Intelligent IP Installer can’t be founded after turning on the PPPoE and reboot. AirLive OD-300CAM User’s Manual...
  • Page 36  Password: Enter the password for authentication necessary for DDNS connections. Type it up to 32 characters.  Re-type password: Re-type the password to confirm.  Host name: Enter the host name that is registered to the DDNS server. AirLive OD-300CAM User’s Manual...
  • Page 37 How to apply DDNS username and Host name?? You can apply DDNS username and Host name by the following steps: 1. Login http://www.dyndns.org, click the Create Account 2. Input all information and follow step by step with DynDNS AirLive OD-300CAM User’s Manual...
  • Page 38 3. Login with new account and click Account → My Hosts → Add Host Services 4. Type domain in the Hostname field and select sub-domain AirLive OD-300CAM User’s Manual...
  • Page 39 5. After type information, check your DDNS service. 6. Type your DDNS User ID, Password and Host name in Setting → Network →DDNS. After completing setting, reboot IP Camera. AirLive OD-300CAM User’s Manual...
  • Page 40 The device will be automatically detected and a new icon will be added to “My Network Place” if it also enables on your computer. It provides Port Forwarding for opening a port in a router or firewall in a private network in order to let a party from the AirLive OD-300CAM User’s Manual...
  • Page 41 AirLive OD-300CAM User’s Manual...
  • Page 42  Authentication: Select the authentication required when you send an email.  Off: Select if no authentication is necessary when an email is sent.  On: When authentication is necessary an e-mail is sent, there are SMPT, POP before SMPT or both three options. AirLive OD-300CAM User’s Manual...
  • Page 43 SMTP server.  Subject: Type the subject/title of the e-Mail up to 64 characters. With respect to mail which is sent according to the IP notification. AirLive OD-300CAM User’s Manual...

  • Page 44: Security

    5.4 Security Click the folder of Security to display the sub folders including Account and HTTPS. AirLive OD-300CAM User’s Manual...
  • Page 45 The Operator mode can not only view the Live View but also control the PTZ (apply in speed dome).  The Viewer mode only can view the Live View.  Viewer Authentication: Allows any viewer direct access to Live View. AirLive OD-300CAM User’s Manual...
  • Page 46  HTTPS Connection Policy: Set HTTPS connection policy for different level of users.  To use the HTTPS encryption, please set up “Create self-signed certificate” for the first time you use the HTTPS function, and then set up the connection policy for different users. AirLive OD-300CAM User’s Manual...
  • Page 47 When enable HTTPS with RTSP on mode, the IP Camera only protect the setting such as username and password and do not protect video and audio. When enable HTTPS with RTSP off mode, the IP Camera will protect all setting including video and audio. AirLive OD-300CAM User’s Manual...

  • Page 48: Chapter6: Setting-Advance

    Chapter6: Setting-Advance Click the folder of Advance to display the sub folders including FTP client, SMTP, HTTP event, Alarm output, Schedule, Alarm input, Alarm buffer, Motion detection and System Log. AirLive OD-300CAM User’s Manual...

  • Page 49: Ftp Client

    FTP server. FTP client setting menu is composed of two tabs, General, Alarm sending and Periodical sending. AirLive OD-300CAM User’s Manual...
  • Page 50  Passive mode: Set whether you use the passive mode of FTP server or not when connecting to FTP server. Select On to connect to FTP server using the passive mode.  Attached file type: You can choose the attached file in JPEG or MPEG4 type. AirLive OD-300CAM User’s Manual...

  • Page 51: Alarm Sending

    Sequence number: A consecutive number of 10 digits between 0000000001 and 4294967295 and two fixed digits 00 are added to the Image file name.  Sequence number clear: Click Clear and the suffix of the sequence number returns to 1. AirLive OD-300CAM User’s Manual...
  • Page 52 Note: You can set motion detection at motion detection page. (Please go “Setting →Advance → Motion detection → Setting”). For more details, you can check Chapter 6.8. AirLive OD-300CAM User’s Manual...
  • Page 53 Note: You can set the alarm input function at alarm input page. (Please go “Setting →Advance → Alarm input → Setting”). For more details, you can check Chapter 6.6. AirLive OD-300CAM User’s Manual...
  • Page 54 Schedule：You can specify the period when the periodical sending is effective in the Schedule setting in the other section. Note: You can set schedule function at schedule page. (Please go “Setting → Advance → Schedule → Setting”). For more details, you can check Chapter 6.5. AirLive OD-300CAM User’s Manual...

  • Page 55: Periodical Sending

    Always: The periodical sending is always effective.  Schedule: You can specify the period when the periodical sending is effective in the schedule setting in the other section. Please check “Setting → Basic → Advance → Schedule → Setting.” AirLive OD-300CAM User’s Manual...

  • Page 56: Smtp

    The image file can also be sent periodically. E-Mail (SMTP) setting menu is composed of three tabs, General, Alarm sending and Periodical sending. AirLive OD-300CAM User’s Manual...
  • Page 57  Authentication: Select the authentication required when you send an email.  Off: Select if no authentication is necessary when an email is sent.  On: When authentication is necessary an e-mail is sent, select one of the authentication methods from the followings. AirLive OD-300CAM User’s Manual...
  • Page 58  Recipient e-mail address: Type the recipient e-Mail address up to 64 characters. You can specify up to three recipient E-mail addresses.  Administrator e-mail address: Type the Administrator e-Mail address up to 64 characters. This AirLive OD-300CAM User’s Manual...
  • Page 59 Alarm sending of the alarm tab is set to On, the characters standing for the sensor type added to the subject.  Message: Type the text of the E-mail up to 384 characters. (A line break is equivalent to 2 characters.) AirLive OD-300CAM User’s Manual...
  • Page 60 Sequence number: A consecutive number of 10 digits between 0000000001 and 4294967295 and two fixed digits 00 is added to the Image file name.  Sequence number clear: Click Clear and the suffix of the sequence number returns to 1. AirLive OD-300CAM User’s Manual...
  • Page 61 Note: You can set motion detection at motion detection page. (Please go “Setting →Advance → Motion detection → Setting”). For more details, you can check Chapter 6.8. AirLive OD-300CAM User’s Manual...
  • Page 62 Note: You can set the alarm input function at alarm input page. (Please go “Setting →Advance → Alarm input → Setting”). For more details, you can check Chapter 6.6. AirLive OD-300CAM User’s Manual...
  • Page 63 Please check“Basic → Advance →Schedule → Setting.” Note: You can set schedule function at schedule page. (Please go “Setting → Advance → Schedule → Setting”). For more details, you can check Chapter 6.5. AirLive OD-300CAM User’s Manual...
  • Page 64  Always: The periodical sending is always effective.  Schedule: You can specify the period when the periodical sending is effective in the schedule setting in the other section. Please check“Basic → Advance →Schedule → Setting.” AirLive OD-300CAM User’s Manual...

  • Page 65: Http Event

    HTTP server. HTTP client setting menu is composed of two tabs, General and Alarm sending. AirLive OD-300CAM User’s Manual...
  • Page 66 6.3.1 General  HTTP event: Set up the HTTP server URL, port, user id, password, and proxy server settings. For example: URL: 192.168.1.7/cgi-bin/operator/ptzset Note: The setting of URL should be the same as CGI AirLive OD-300CAM User’s Manual...
  • Page 67 6.3.2 Alarm sending Set to send the mail with connection to the alarm detection by the external sensor input or by the built-in motion detection function. Select On to send the image and audio file to HTTP server linked with the alarm detection. Alarm sending: Select On to set to send mail with connection to the alarm detection.
  • Page 68 Message: message will show up in the form of Message = PTZ down. If your target device didn’t support the parameter of message, you can’t see the message. So you can just take the message as a note. For example: PTZ down. AirLive OD-300CAM User’s Manual...
  • Page 69 Message: message will show up in the form of Message = PTZ down. If your target device didn’t support the parameter of message, you can’t see the message. So you can just take the message as a note. For example: PTZ down. AirLive OD-300CAM User’s Manual...
  • Page 70 Message: message will show up in the form of Message = PTZ down. If your target device didn’t support the parameter of message, you can’t see the message. So you can just take the message as a note. For example: PTZ down. AirLive OD-300CAM User’s Manual...

  • Page 71: Alarm Output

    When you click Alarm output on the Advance mode menu, the Alarm output setting menu appears. You can set in this menu to control the alarm out of I / O port on the rear of the device linked to the alarm detection and the timer. AirLive OD-300CAM User’s Manual...
  • Page 72  Alarm: Controls alarm output by synchronizing with an external sensor input or the built-in activity detection function.  Motion Detection: Click it on for using Motion Detection function as a sensor. You can set motion detection function at the motion detection function page. AirLive OD-300CAM User’s Manual...
  • Page 73 Note: You can set the alarm input function at alarm input page. (Please go “Setting → Advance → Alarm input → Setting”). For more details, you can check Chapter 6.6. AirLive OD-300CAM User’s Manual...
  • Page 74 Recording time of Pre-alarm period and Post-alarm period. The recording time is up to 5 seconds.  Schedule: You can specify the period when the periodical sending is effective in the schedule setting in the other section. Click Schedule and the setting menu for the effective period is displayed. AirLive OD-300CAM User’s Manual...

  • Page 75: Schedule

    Schedule to set Effective period and Schedule in FTP client setting menu, e-Mail (SMTP) setting menu, Alarm out setting menu and so on. Example: When setting e-Mail (SMTP) (the alarm sending) in the Schedule setting menu. AirLive OD-300CAM User’s Manual...
  • Page 76  Use the same time schedule every day: When this is checked, the Start time and End time set to Mon (Monday) are applied to all days. In this case, the Start time and End time of the other days than Mon (Monday) cannot be input. AirLive OD-300CAM User’s Manual...

  • Page 77: Alarm Input

    Sensor input 1: Click it on for using external sensor which is connected to sensor input1 of the camera I / O port.  Trigger condition: Select High signal output and Low signal output as your alarm. AirLive OD-300CAM User’s Manual...

  • Page 78: Alarm Buffer

    Post alarm period: Type it with recording time of the image/audio after the alarm detection. Note： The value of Recording capacity differs depending on Image size, Bitrate (for MPEG4) and Image quality (for MPEG4 and MJPEG) in the camera setting menu. AirLive OD-300CAM User’s Manual...

  • Page 79: Motion Detection

    There are three Motion Detection functions as sensors to set for different detecting zones. Each one has Threshold and Sensitivity inputs which you can adjust to specific zone sequentially. Motion Detection function can support to FTP, SMTP and Alarm output for capturing and sending images or starting alarm output. AirLive OD-300CAM User’s Manual...
  • Page 80  Motion Detection 3: Click it on for using Motion Detection 3 function as a sensor. You can adjust and move the detecting zone by using mouse. AirLive OD-300CAM User’s Manual...

  • Page 81: System Log

    The System Log function allows users to review any changes and events happened. The system starts logging automatically after started. 6.9.1 Setting  Enable remote log: Enables user to send the log data to a specified log server. AirLive OD-300CAM User’s Manual...

  • Page 82: Chapter7: Appendix

    640*480 1536 1500 1700 640*480 1536 640*480 1024 1000 640*480 1024 1000 640*480 640*480 1500 320*240 1536 320*240 1536 1600 320*240 1024 1000 320*240 1024 1000 320*240 320*240 160*120 1024 160*120 1024 160*120 160*120 160*120 160*120 AirLive OD-300CAM User’s Manual...
  • Page 83 Excellent 1600 640*480 Good 1600 640*480 Good 640*480 Medium 640*480 Medium 320*240 Excellent 1500 320*240 Excellent 320*240 Good 320*240 Good 320*240 Medium 160*120 Medium 160*120 Excellent 160*120 Excellent 160*120 Good 160*120 Good 160*120 Medium 160*120 Medium AirLive OD-300CAM User’s Manual...
  • Page 84 (AC) 50/60Hz of fluorescent light (or gaseous electric light). The fluorescent light changes constantly due to the strength and color of alternating current are base on the speed of 8.3ms. Thus, CCD must catch and calculate the correct white balance through DPS. Normally, CCD needs 100~150ms AirLive OD-300CAM User’s Manual...
  • Page 85 (0.1~0.15) to calculate white balance which is slower 8.5ms than alternating current. That is why color rolling is occurred. Resolution： Utilize auto Iris lens or lessen diaphragm to reduce the sensitivity of light. Utilize 24C electric current. AirLive OD-300CAM User’s Manual...
