VERMONT CASTINGS
INBUILT GAS BARBEQUE GRILL
USER MANUAL VCS5005BI
OWNERS INSTALLATION & OPERATING INSTRUCTIONS.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCS5005BI and is the answer not in the manual?

Questions and answers

Related Manuals for Vermont Castings VCS5005BI

Summary of Contents for Vermont Castings VCS5005BI

  • Page 1 VERMONT CASTINGS INBUILT GAS BARBEQUE GRILL USER MANUAL VCS5005BI OWNERS INSTALLATION & OPERATING INSTRUCTIONS. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Table Of Contents

    Congratulations on your purchase of this new Inbuilt Majestic barbeque. The following information is designed to assist you in the assembly, installation, operation, maintenance tips and trouble shooting and as well as some very important safety information. We are sure that you will have many years of enjoyable outdoor entertainment.

  • Page 3: Part 1: For Your Safety

    Part 1: For Your Safety For your safety do not operate this appliance before reading this instruction book. WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. For assistance or additional information consult with Raypak Australia, your Raypak distributor, qualified installer or accredited Rheem Australia Service agency WHAT TO DO IF YOU SMELL GAS?
  • Page 4 WARNING Barbeques must be used in accordance with the installation requirements of your local gas supply authority, or the appropriate installation code issued by the Australian Gas Association and the Australian Liquefied Petroleum Gas Association. Barbeques for use with bottled gas are labelled “Propane Gas” Barbeques for use with natural gas are labelled “Natural Gas”...

  • Page 5: Part 2: Installation Instructions

    Natural Gas Propane Gas Consumption 66 MJ/h 80 MJ/h Test Point Pressure 1 kPa 2.75 kPa Injector Diameters – 1.50 mm 1.02 mm Main Burners Injector Diameters – 2.10 1.10mm Rotisserie Burner Main Burner Aeration 4.5mm 6.35mm Rotisserie Burner 16mm 10mm Aeration Number of Injectors...
  • Page 6 c) In case of balconies, at least 20% of the total of the side, back and front wall areas shall be remain open and unrestricted.

  • Page 8: Clearances

    CLEARANCES This appliance must be installed on non combustible materials. This outdoor Barbeque must be installed in accordance with AS5601. Safe Use of LPG (Propane) Gas DANGER: Never install a propane cylinder that is more than 80 % full, as the contents may lack the adequate room for expansion when exposed to heat.

  • Page 9: Safe Use Of Natural

    Exposing a disconnected cylinder to heat could result in the venting of the propane vapour through the pressure relief valve, and the pooled vapour could result in a violent fire. Always confirm that all the openings in the cylinder compartment are free from any obstructions that would restrict the circulation of ventilation air.

  • Page 10: Test For Leaks

    Note: This unit is supplied with a gas regulator, securing bracket and screws which must be fitted during installation. Fig. 1 Fig. 1 Always promptly shut off the gas supply and immediately extinguish all flames if you smell gas. Contact your licensed plumber to rectify the gas leak.
  • Page 11 Warning: Never open the tank valve unless the grill is being prepared for use. This will prevent the pooling of Propane vapour. Always open the valve immediately before lighting the grill and always close it immediately after cooking has been completed. Burner Control Valve On the model VCS5005 Barbeque there are 5 independent control valves for the main burners and a separate control for the rotisserie burner.

  • Page 12: Turning Off The Burners

    Note Aeration Settings: Natural gas model; Main burner aeration to be set at 4.5 mm open .Rotisserie burner aeration to be set at 16 mm open Propane model main burner aeration to be set a 6.35 mm Rotisserie burner to be set at 10 mm open.
  • Page 13 WARNING Always monitor the grill carefully while cooking and turn down the flame level down (LOW) or (OFF) if flare ups intensify.

  • Page 15: Part 4: Care & Maintenance

    Part 4: Care & Maintenance...

  • Page 17: Part 5: Troubleshooting

    Part 5: Troubleshooting PROBLEM POTENTIAL CAUSE ACTION REQUIRED Burner will not Gas supply turned off Turn on gas supply and re-try light Out of Propane Confirm the flow of gas by smell or listening for the sound of the gas being emitted. Allow gas to clear before attempting to relight.
  • Page 18 resolve the problem, close your cylinder valve. Confirm that all burner control knobs are in the OFF position. Open the cylinder valve slowly (about 1 to 2 turns) and wait 5 seconds. Finally, turn a single burner ON and try relighting it.
  • Page 19 The electrode should be located 3 to 4 mm from the burner and positioned to spark to the edge of the gas port. If the spark gap is incorrect or the unit is not sparking properly call Rheem Service on 131 031. Electrode cracked Replace electrode.

  • Page 20: Part 6: Warranty

    RAYPAK/VERMONT CASTINGS BARBEQUE WARRANTY AUSTRALIA ONLY Rheem* will: a) Repair or, if necessary replace any Raypak barbeque model VCS5005BI b) Replace any component (or, if necessary, arrange the installation of a barbeque which falls within the warranty periods specified below, in...
  • Page 21 RAYPAK/VERMONT CASTINGS BARBEQUE WARRANTY AUSTRALIA ONLY WARRANTY CONDITIONS This warranty is applicable only to this barbeque manufactured from 1 May 2005. This barbeque must be installed in accordance with the Raypak barbeque installation instructions, supplied with the barbeque and in accordance with all relevant statutory and local requirements of the State in which the barbeque is installed.
  • Page 22 d) Where the barbeque is located in a position that does not comply with the Raypak barbeque installation instructions or relevant statutory requirements, causing the need for major dismantling or removal of cupboards, doors, walls or use special equipment to bring the barbeque to floor or ground level or to a serviceable position.
  • Page 23 MAJESTIC VCS5005 ASSEMBLY PROCEEDURES...
  • Page 24 GENERAL INFORMATION FRAMING DIMENSIONS...
  • Page 25 Fig 1 Non Combustible Clearances Reference 50 dia 1110 Fig 2 NOTE: This BBQ must be installed in an enclosure constructed from non-combustible material. Clearances See Fig 1 and Fig 2. Specifications Appliance specifications can be found on the data plate attached to the unit.
  • Page 29 VCS5005 ASSEMBLY DRAWING...
  • Page 30 VCS5005 PARTS LIST Distributed by Raypak Australia (Division of Rheem Australia Pty Ltd) 39 Koornang Rd Scoresby Vic 3179 Ph 03 9757 3333 Fax 03 9757 3350 ABN 65078 743 414...
