3

BATTERY PACKS

' ' Charging connections

D
Rapid charging with the BC-119L/BC-119+AD-89
q Insert the optional AD-89
the charging slot of the BC-119.
• The BC-119L comes preinstalled with the AD-89
ADAPTER
w Insert the battery pack, either by itself or attached to the trans-
ceiver, into the charger.
(See BC-119/L instructions.)
*NOTE: Put the Ni-Cd
battery adapter into the
AD-89 rear slot when
the BP-202 is attached
to the transceiver.
AC adapter
7
.
IC-4008E
DESKTOP CHARGER ADAPTER
BP-202
CHARGING
*
AD-89
BC-119
into
